T1 and E1 Line Cards
Models 8995-B2 and 8997-B2
Installation and User's Guide
Document Number 8990-A2-GN10-20
March 2005
Contents
.......................................................................................................... 13
................................................................................................. 16
................................................................................................... 22
.....................................................................
...................................................................................
..................................................................................... 10
.................................................................... 10
.......................................................................................... 12
................................................................................... 16
......................................................................... 18
................................................................................ 21
..................................................................................... 22
.................................................
................................................................
1
...................................... 22
2
4
5
7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8995 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paradyne 8995

  • Page 1: Table Of Contents

    T1 and E1 Line Cards Models 8995-B2 and 8997-B2 Installation and User’s Guide Document Number 8990-A2-GN10-20 March 2005 Contents Software and Firmware License Agreement Product Documentation Online T1 and E1 Line Cards Description Application Examples Installation Overview ... 10 Installing T1 and E1 Line Cards Front Panel LEDs ...
  • Page 2: Software And Firmware License Agreement

    Software and Firmware License Agreement ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT. IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE...
  • Page 3 5. Except for the Product warranty contained in the manual, the Software is provided “AS IS” and in its present state and condition and Paradyne makes no other warranty whatsoever with respect to the Product purchased by you. THIS AGREEMENT EXPRESSLY EXCLUDES ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, OR ORAL OR WRITTEN, INCLUDING WITHOUT LIMITATION: Any warranty that the Software is error-free, will operate uninterrupted in your...
  • Page 4: Product Documentation Online

    Product Documentation Online Complete documentation for this product is available at www.paradyne.com. Select Support → Technical Manuals. Document Number Document Title 8400-A2-GB20 Shelf Concentration and Processing (SCP) Card with ATM Uplink User’s Guide 8400-A2-GB21 Shelf Concentration and Processing (SCP) Card with IP Uplink User’s Guide 8400-A2-GZ40 Shelf Concentration and Processing (SCP) Card Installation...
  • Page 5: T1 And E1 Line Cards Description

    T1 and E1 Line Cards Description The Models 8995 and 8997 line cards can be used in any 8620 or 8820 Broadband Loop Carrier (BLC) managed by a Shelf Concentration and Processing (SCP) card. Physical Description Each 8995 or 8997 access line card connects through one 50-position Telco connector (RJ48M) on the rear of the chassis.
  • Page 6 — SCP card network interface — SCP card oscillator CES Features CES features include support for: 24 CES Interworking Functions (IWFs) per port (8995) or 31 CES IWFs per port (8997) CAS – Robbed Bit Signaling (8995) or Bit Oriented Signaling (8997)
  • Page 7: Application Examples

    Application Examples Applications for the 8995 and 8997 line cards include subtending T1/E1 ATM or IMA devices, deploying ATM over T1 or E1, deploying ATM over T1 through Digital Loop Carriers (DLCs), and transmitting voice over broadband. Subtending ATM or IMA Devices...
  • Page 8 Deploying ATM Over T1 or E1 Through DLCs Figure 3, broadband service is deployed to customers for whom IDSL is inadequate or prohibitively expensive. Figure 3. ATM Over T1 or E1 Through DLCs Voice Over T1 or E1 ATM Figure 4 shows voice services implemented using ATM over standard T1 or E1 lines.
  • Page 9 Voice Over T1 or E1 CES Figure 5 shows voice services implemented using Circuit Emulation Services (CES) over standard T1 or E1 lines. Figure 5. Voice Over T1 or E1 CES...
  • Page 10: Installation Overview

    Installation Overview Installation and configuration of the T1 or E1 Line Card consists of: ❑ Obtain the applicable cable; refer to ❑ Make sure the BLC is installed and power is supplied to the chassis. ❑ Install the card in the BLC. ❑...
  • Page 11 3. Holding the T1 or E1 Line Card with the component side facing up (8620 BLC) or facing right (8820 BLC), insert it into the card guides. CAUTION: Do not force the unit into the slot. This could damage the backplane connectors.
  • Page 12: Front Panel Leds

    Alrm Test ATM BUS T1 PORT 1–8 (8995) E1 PORT (8997) * Pulsing: LED turns off momentarily once per second. Fast Blinking: LED turns off and on in equal duration 4 times per second. LED is . . . * Indicating .
  • Page 13: Cabling

    Cabling The following cables are used with this product: Model 8995 or Model 8997 using 120 Ohm outputs: Feature Number 8026-F1-001, which terminates in eight 8-pin modular jacks. See Number 8026-F1-001 Pin Assignments, on page Model 8997 using 75 Ohm outputs: Feature Number 8027-F1-001, which terminates in 16 BNC jacks.
  • Page 14 5. Secure the other end of the Telco 50-pin cable by tightening the captive pan-head screw. 6. If a ferrite choke is included with your T1 or E1 card, install it on the cable as close as possible to the chassis. If the choke fits loosely on the cable, hold it in place with a cable tie.
  • Page 15 4. Insert the bottom edge of the locking pivot bracket inside the lower edge of the rear panel cutout next to that connector. Rear Panel Receptacle on Backplane Cutout 5. Align the two connectors. 6. Rotate the connector until it is fully seated. 7.
  • Page 16: Logging In To The Blc

    Logging In to the BLC To access the web interface: Procedure 1. Open your web browser. (Internet Explorer Version 6 or above is recommended.) 2. Type http:// and the IP address of the SCP card into the Address field of your browser window.
  • Page 17 — Downstream Profile ➔ ➔ Configuration T1/E1 Ports — Circuit Name — Line Type — Line Build Out — Line Equalization — Timing — Port Status Configuration ➔ IMA ➔ Groups — Group Status — Frame Length — Minimum Links Configuration ➔...
  • Page 18: Connector Pin Assignments

    Connector Pin Assignments Table 1 lists connector pin assignments for the Model 8995 T1 IMA line card, and the Model 8997 E1 line card when used with modular connectors for a 120-ohm E1 connection. Table 2 lists connector pin assignments for the Model 8997 when used with BNC connectors for a 75-ohm E1 connection.
  • Page 19 Table 1. Feature Number 8026-F1-001 Pin Assignments (2 of 2) DS1 or 120 Ohm 50-Position Telco E1 Port Connector Pinouts Port 6 Port 7 Port 8 Table 2. Feature Number 8027-F1-001 Pin Assignments (1 of 2) 75 Ohm E1 Port Function Port 1 Data In...
  • Page 20 Table 2. Feature Number 8027-F1-001 Pin Assignments (2 of 2) 75 Ohm E1 Port Function Port 3 Data In Data Out Port 4 Data In Data Out Port 5 Data In Data Out Port 6 Data In Data Out Port 7 Data In Data Out Port 8...
  • Page 21: Technical Specifications

    Technical Specifications Table 3. Models 8996 and 8997 Technical Specifications Specifications Size Weight Approvals Safety Certifications Power Power Dissipation Physical Environment Operating temperature Storage temperature Relative humidity Shock and vibration T1 and E1 Specifications Number of ports Connector Type Standards Supported Frame Formats Line Type Data Rates Supported...
  • Page 22: Warranty, Sales, Service, And Training Information

    Warranty, Sales, Service, and Training Information Contact your local sales representative, service representative, or distributor directly for any help needed. For additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor locations, or Paradyne worldwide office locations, use one of the following methods: Internet: Visit the Paradyne World Wide Web site at www.paradyne.com.
