Hotwirer 6341/6342 Symmetric DSL Routers
Installation Instructions
Document Number 6341-A2-GN10-00
February 2000
Contents
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste of
surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select Library
Select the following document:
6371-A2-GB20
Hotwire DSL Routers User's Guide
To request a paper copy of a Paradyne document:
H
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
H
Outside the U.S.A., call 1-727-530-8623
Product-Related Documents
Document Number Document Title
8000-A2-GB26
8000-A2-GB27
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Manuals
Hotwire MVL, RADSL, and Packet SDSL Cards, Models
8310/8312, 8510/8373/8374, and 8343/8344, User's Guide
Hotwire Network Design Guide: Bridged Model
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
Hotwire DSL and MVL Systems.
1
2
3
4
6
7
12
14
19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hotwire 6341 and is the answer not in the manual?

Questions and answers

Related Manuals for Paradyne Hotwire 6341

Summary of Contents for Paradyne Hotwire 6341

  • Page 1: Table Of Contents

    Installing the DSL Access Wiring Connecting to the DSL Access Wiring Installing the Hotwire 6341/6342 SDSL Router Troubleshooting ...........

  • Page 2: Hotwire 6341/6342 Sdsl Routers Overview

    Hotwire 6341 SDSL Router with one Ethernet port Hotwire 6342 SDSL Router with a four-port Ethernet hub Both the Hotwire 6341 and the Hotwire 6342 SDSL Routers operate as an IP router connecting a DSL link to an Ethernet network. The Hotwire SDSL packet-based system provides high-speed Internet or corporate LAN access over traditional twisted-pair copper telephone wiring.

  • Page 3: Wiring And Cables Needed

    CAT5 wiring must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm). A straight-through or crossover Ethernet cable is used. Refer to Installing the Hotwire 6341/6342 SDSL Router on page 7 for cabling details. Customer Premises (CP)

  • Page 4: Installing The Dsl Access Wiring

    Optional Cable The Hotwire 6341/6342 SDSL Routers are typically configured remotely by the service provider. The following optional cabling and adapter are only used with this product to configure the router locally: Console cabling: Straight-through cable with 8-pin non-keyed modular plugs (Part No.
  • Page 5 2. Disconnect the DSL access pair from the local loop. A punchdown block is used in the following example. Punchdown Block Demarcation Point Access from Local Loop 3. Locate the DSL pair of T1/R1 connectors on the customer premises side of the NID or punchdown block.

  • Page 6: Connecting To The Dsl Access Wiring

    Connecting to the DSL Access Wiring The Hotwire 6341 or 6342 SDSL Router connects to the local loop via wiring from the demarcation point to an RJ11 wall jack. The DSL twisted-pair wiring from the local loop terminates at a new or existing wall jack. It may be necessary to install a standard single RJ11 jack or replace a single jack with a double RJ11 jack.

  • Page 7: Installing The Hotwire 6341/6342 Sdsl Router

    Installing the Hotwire 6341/6342 SDSL Router Place the Hotwire 6341/6342 SDSL Router on a flat surface with clearance for the rear connectors. NOTE: The following illustrations show the Hotwire 6342 SDSL Router with a 4-port Ethernet hub. The Hotwire 6341 SDSL Router is identical except that it has one Ethernet port.
  • Page 8 If you are installing the Hotwire 6342 SDSL Router, go to page 9. For a 6341 SDSL router, use a straight-through cable to connect the other end to an Ethernet hub. Do not connect a straight-through cable to the external hub’s UPLINK connection (this connection requires a crossover cable).
  • Page 9 If you are installing the Hotwire 6341 SDSL Router, go to page 8. For a 6342 SDSL router, use a straight-through cable to connect the other end to a PC with an Ethernet Network Interface Card (NIC) installed. -and/or- Use an Ethernet crossover cable to connect the other end to an external hub.
  • Page 10 800 MA Transformer 99-16585 The Hotwire 6341/6342 SDSL Router hardware installation is now complete. When the power cord is installed, the SDSL router goes through a power-on self-test. Power-On When power is applied, the Hotwire 6341/6342 SDSL Router performs self-diagnostics and the PWR LED is on.

  • Page 11: Status Leds

    The TST LED is on during the power-on self-test and during a test initiated by the service provider. The SDSL router is establishing the active DSL link. The LED blinks on and off about five times per second. The DSL link is now active and ready to transmit and receive data.

  • Page 12: Troubleshooting

    PC is connected and powered on. Verify that the correct straight-through or crossover cable is installed. Refer to Installing the Hotwire 6341/6342 SDSL Router on page 7. PWR LED is off. Check that the power cord is securely installed on both ends.

  • Page 13: Local Console Access

    Increasing the Number of End-User Systems The Hotwire 6341/6342 SDSL Router can support differing numbers of end-user systems depending on the functions that are enabled and traffic loading. Typical configurations will provide support for up to 32, 64, or 256 hosts (end-user systems).

  • Page 14: Cables & Connectors

    DSL Ring DSL Tip 5 & 6 Not used The Console connector uses 8-pin non-keyed modular plugs and a DB9 adapter. See Hotwire 6341/6342 SDSL Router Configuration Setup on page 13. RJ45 8-Pin Connector Pin # Circuit Not used Signal Ground...
  • Page 15 The Ethernet interface connector uses an 8-pin, non-keyed modular plug. Use shielded twisted-pair CAT5 or better cables. — To connect to 6341 SDSL router to an Ethernet hub or a 6342 SDSL router to a PC with an Ethernet NIC card installed, use the straight-through connection.
  • Page 16 Optional Hotwire 6341/6342 SDSL Router Wall Placement The Hotwire 6341/6342 SDSL Router is designed for tabletop placement. The SDSL router can also be mounted on a wall. To mount the SDSL router, you will need: Three slotted-head #6 self-threading screws with molly bolts...
  • Page 17 SDSL Router Hardware Template 5.43" Front (LEDs) 7.55" To Bottom Hole 98-16171...
  • Page 18 Model 6341/6342 SDSL Router Technical Specifications Item Height x Width x Depth Weight External Power Supply Class 2 Transformer normal service input voltage range Unit Power Consumption Approvals FCC Part 15 CISPR 22 Safety Certifications Physical Environment Operating temperature Storage temperature...

  • Page 19: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.

  • Page 20: Notice To Users Of The Canadian Telephone Network

    Canada EMI Warnings WARNING: To Users of Digital Apparatus in Canada: This Class B digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la classe B respecte toutes les exigences du règlement sur le matérial brouilleur du Canada. Notice to Users of the Canadian Telephone Network The Industry Canada label identifies certified equipment.

  • Page 21: Declaration Of Conformity

    Trade Name: Hotwire Model Number: 6341-A1-200 & 6342-A1-200 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 22 Japan Notices This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference. Install and use the equipment according to the instruction manual.

  • Page 23: Document Feedback

    Warranty, Sales, Service, and Training Information Contact your local sales representative, service representative, or distributor directly for any help needed. For additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor locations, or Paradyne worldwide office locations, use one of the following methods: Internet: Visit the Paradyne World Wide Web site at www.paradyne.com.
