For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3911BN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev:18-01-16
Advertisement
Related Manuals for Furniture of America CM3911BN
Summary of Contents for Furniture of America CM3911BN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3911BN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Chair Back Bolt Ø5/16" x 3" #2 x 1pc #B x 4pcs Cushion Seat Bolt Ø5/16"...
- Page 4 Exploded View DO NOT FULLY TIGHTEN ALL BOLTS UNTIL ASSEMBLY IS COMPLETED. Align seat (#2) to the holes of the bench back (#1), then secure by using bolts (#C) with washers (#D,E). #C x 2pcs #D x 2pcs #E x 2pcs Page 4 of 6...
- Page 5 Secure corner holes of seat (#2) to bench back (#1) by using bolts (#A) with washers (#D,E). #A x 4pcs #D x 4pcs #E x 4pcs Align front legs (#3R/L) to the holes of the seat (#2), then align stretchers (#5R/L) to the gaps of the bench back (#1) and front legs (#3R/L).
- Page 6 Align front leg (#4) to the holes of the seat (#2), then align stretcher (#6) to the gaps of the bench back (#1) and front leg (#4). Secure front legs (#4) by using bolts (#C) with washers (#D,E). #C x 2pcs #D x 2pcs #E x 2pcs #F x 6pcs...
