Summary of Contents for Furniture of America Hillsview CM3916PC-PK
- Page 4 Align the seat (#2) with the pre-drilled holes of the backrest with legs (#1). II. Prepare 2 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#C) and then the flat washer (#E) onto that SAME bolt (#C), in that order. Insert the bolt assemblies through the pre-drilled holes in the center of the seat (#2).
- Page 5 I. Align the front right leg (#3R) and left leg (#3L) to the seat (#2). II. Prepare 4 bolt assemblies by FIRST inserting the lock washer (#D) onto the bolt (#B) then the flat washer (#E) onto the SAME bolt (#B), in that order. Insert the bolt assemblies through the pre-drilled holes in the corners of the seat (#2) and secure those bolts using the Allen wrench (#F).
