  • Page 1 MOD : E7/F26A7-N Production code : DIFRBE77A 06/2023...
  • Page 2 FRBE74T / 74A FRBE94T / 94A FRBE77T / 77A FRBE98T / 98A FRBE74AD / 77AD FRE94A2V FRE94A / 98A FRBE74AHP FRBE94TD / 94AD FRE74T2V / 74A2V FRBE98TD / 98AD FRE74T / 74A FRBE94HP FRE77T / 77A FRIGGITRICE MANUALE DI INSTALLAZIONE E USO...

  • Page 3: Table Of Contents

    FRYER INSTALLATIONS AND USE INSTRUCTIONS TABLE OF CONTENTS 1-2. GENERAL AND SAFETY 6. REPLACING COMPONENTS INFORMATION 7. INSTRUCTIONS FOR USE 3. POSITIONING AND HANDLING 8. MAINTENANCE 4. POWER SUPPLY CONNECTIONS 9. WASTE DISPOSAL 5. OPERATIONS 10. TECHNICAL DATA / IMAGES FOR COMMISSIONING tal abilities) are prohibited from DESCRIPTION...

  • Page 4: General And Safety Information

    ling, servicing, repairing and Obligation to use a pro- scrapping the appliance. tective helmet. “Heterogeneous” Opera- Obligation to use safety tor (Operator with limited shoes. skills and tasks). Person authorised and employed to ope- Other indications. Indica- rate the appliance with guards tions to implement the cor- active, capable of performing rect procedure, non-com-...
  • Page 5 GENERAL AND SAFETY INFORMATION KEEPING THE DOCUMENT / This systems, safety valves, etc.) foreseen document and the rest of the contents by legislation in force in the country of of the envelope, are an integral part of installation; the initial supply. It must therefore be •...
  • Page 6 GENERAL AND SAFETY INFORMATION The appliance must be installed in a su- chines. Damage occurred in transit or itable place, namely, one which allows due to incorrect installation or mainte- normal running, routine and extraordi- nance can’t be considered. Guarantee nary maintenance operations.
  • Page 7 GENERAL AND SAFETY INFORMATION Every technical change has Connect the appliance if pre- an effect on the operation or sent, in the sequence of the safety of the appliance and water, then to the gas network. En- must therefore be performed by te- sure there are no leaks then proce- chnical personnel of the manufactu- ed with the connections to the mains.
  • Page 8 GENERAL AND SAFETY INFORMATION The appliance must be includ- Prohibition for the homogene- ed in an “Equipotential” ground ous operator to perform any discharge system. type of operation (mainte- nance and/or other) without having Drainage of the appliance must first read the entire documentation. be conveyed into the grey wa- The information con- ter discharge network in an...
  • Page 9 GENERAL AND SAFETY INFORMATION such a person; relating to lifting equipment. • Exposed person: any person that is found wholly or partly in a dange- INDICATION ON RESIDUAL rous zone. RISK / Even though the rules for “good manufacturing practice” and Maintain a minimum distance the provisions of law which regulate from the appliance when oper-...

  • Page 10: Positioning And Handling

    POSITIONING AND HANDLING containing substances which risk the appliance increased by 20%. exploding; • using food in closed containers Follow the directions on the (such as jars and cans), if they are packaging and/or on the same not suitable for the purpose. appliance before handling.
  • Page 11 POSITIONING AND HANDLING 2. Remove the protective material used non-abrasive sponge. for packaging; Afterwards rinse the cooking chamber 3. Lift the appliance as necessary and with drinking water. remove the pallet; Let the liquid containing detergent 4. Place the appliance on the ground; and/or other impurities flow off into the 5.

  • Page 12: Power Supply Connections

    POSITIONING AND HANDLING or insulating treatments. remaining equipment. To place the equipment adherent each INTRODUCTION TERMINAL other perfectly (part G). Level the equi- (OPTIONAL) see SECT. IMAGES pment as described above (detail E). - REF. c) / In order to introduce the Insert the screws in their housings and terminal, position it and fix it with the lock the two structures with the locking...
  • Page 13 POWER SUPPLY CONNECTIONS whole building turns out to be under IMAGES - REF. d) If necessary, remove the terminal safety conditions, also in case a light- box protection panel located on the ning should hit the building. back of the machine. Before proceeding with the opera- tions, see “General safety info”.

  • Page 14: Operations For Commissioning

    OPERATIONS FOR COMMISSIONING nal fumes/vapour extraction; Checking GENERAL WARNINGS and monitoring of the protection panels Operators have a duty to fami- (all the panels must be fitted correctly). liarise themselves adequately, using this manual before per- DESCRIPTION OF STOP MODES forming any intervention, adopting Generally, in stoppage condi- the specific safety requirements to...

  • Page 15: Replacing Components

    OPERATIONS FOR COMMISSIONING Proceed with the operations described as indicated below: in “Starting production”. 1. Use lukewarm water with a bit of soap to clean the parts; In order to free air in the pipes, 2. Rinse the parts thoroughly, wi- open the network lock, turn the thout using pressurised and/or direct knob of the appliance while pressing it...

  • Page 16: Instructions For Use

    INSTRUCTIONS FOR USE LOCATION OF MAIN COMPO- Before proceeding see “Daily NENTS - SEE SECT. IMAGES - activation” REF. f). The layout of the figures is purely indicative and can vary. Start the appliance only after ha- 1. Switch-on knob / 2. Indicator light ving filled the cooking compart- / 3.
  • Page 17 INSTRUCTIONS FOR USE 1. Turn the Functions Knob to the When using grease (lard or the Temperature symbol (Fig. 1A), the likes) in the solid state, the ther- green LED indicates a heating phase mostat must be set at minimum to al- (Fig.
  • Page 18 INSTRUCTIONS FOR USE Shaking Time (basket) / 4. Load com- the Functions Knob to “Zero” (Fig. 1E). pensation (lowest cooking temperatu- - CANCEL PROGRAM / To activate re / Fig. 1D). this option: 1. Turn the Functions Knob To save the program, press the to the Programs symbol (Fig.
  • Page 19 INSTRUCTIONS FOR USE MOD. -HP to cool off. lume is 2,6 liters (1 tank). / 700 : The maximum load is 2.5 kg and the Top version / Insert the extension Expansion volume is 15 liters / MOD. pipe supplied into the oil drain ROTATIVE 2V 900: The maximum load pipe as far as it will go (Fig.
  • Page 20 MAINTENANCE steel, glass and enamel). OBLIGATIONS - PROHIBITIONS - ADVICE Carefully read the indications car- Before proceeding see chapters ried on the labels of the products 2 and 5 used. Wear protective equipment suitable for the operations to be perfor- If the appliance is connected to a med (see the protective equipment car- flue, the exhaust pipe must be...
  • Page 21 MAINTENANCE (see burnt oil drainage procedure). cooking compartment. Empty oil from the 4. When these operations have been cooking compartment (see burnt oil done successfully, close the drainage drain procedure). gate valve. Carefully dry all exposed 1.Turn the heating coil 90° by hand to surfaces with a non-abrasive cloth.

  • Page 22: Maintenance

    MAINTENANCE mains and shut all the supply valves. ration of correct operation of the applian- Then contact authorized customer ser- ce entails executing operations for which vice. the generic operator is not qualified. If the supply cable should be da- The authorized maintenance tech- maged, contact authorized cu- nician intervenes when the generic...
  • Page 23 MAINTENANCE FAULT POSSIBLE CAUSE INTERVENTION The fryer does not heats No power supply Check power supply inlet • • Safety thermostat Contact authorized techni- • • Heating element broken cal assistance • Contactor switch broken • Working thermostat • broken Heating element not •...

  • Page 24: Waste Disposal

    WASTE DISPOSAL Before commencing dismant- ling of the appliance, ensure DEACTIVATION AND around the appliance a space SCRAPPING OF APPLIANCE that is large enough and arranged Obligation of disposing of ma- in such a way as to allow all move- terials using the legislative ments without risk.
  • Page 25 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG CODICE - CODE - CODE - CÓDIGO - KOD - КОД - KODE N° 200775 EDIZIONE - EDITION - EDITION - EDICIÓN - AUSGABE Rev. 4 - 10/2022 - EDIÇÃO - WYDANIE - EDITIE - UTGAVE - UTGÅVA- KIA- DÁS TIPO DI DOCUMENTO - TYPE OF DOCUMENT - TYPE DE...
  • Page 26 5,25 14x34x21 7,5+7,5 FRE94A2V 5x2,5 +5,25 30x40x24 3x10 FRE94A 30x40x24 18+18 FRE98A 16+16 3x10 31x61x29 19,5 FRBE94AHP 22,5 24x34x21 FRBE74T 5x2,5 22,6 24x34x21 12+12 FRBE77T 3x10 5,25 14x34x20 FRE74T2V 5x2,5 +5,25 28x34x20 5x2,5 22,6 FRE74T 28x34x20 12+12 FRE77T...
  • Page 27 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG ON TOP / ON CUPBOARD MOD. TILTING 700 262.5 262.5 93.5 93.5 262.5 93.5 262.5 93.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5 56.5...
  • Page 28 ON TOP / ON CUPBOARD MOD. TILTING HP 700 56.5 56.5 MOD. ROTATIVE 700 56.5 56.5 IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 4 -...
  • Page 29 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG ON TOP / ON CUPBOARD MOD. ROTATIVE 700 56.5 56.5 56.5 56.5 56.5 56.5 56.5 IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 5 -...
  • Page 30 MOD. TILTING 900 311.5 88.5 311.5 88.5 311.5 88.5 311.5 88.5 56.5 56.5 311.5 88.5 311.5 88.5 311.5 88.5 311.5 88.5 311.5 88.5 311.5 88.5 311.5 311.5 88.5 88.5 56.5 56.5 MOD. ROTATIVE 900 56.5 56.5 311.5 311.5 88.5 88.5 311.5 311.5 88.5...
  • Page 31 MOD. TILTING HP 900 IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 7 -...
  • Page 32 BROWN BLACK BLUE DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG SCHEMA ELETTRICO - WIRING DIAGRAM FR(B)E7... 380-415 3N ~ DEUTSCH ITALIANO FRANCAIS ENGLISH BROWN MICROINTERRUTTIRE ENDMIKROSCHALTER MICROCONTACT HEATIGN ELEMENTS BLACK RESISTENZE RESISTANCE MICRO SWITCH ROHRHEIZKORPER MORSETTIERA TERMINAL BLOCK KLEMMENLEISTE...
  • Page 33 FRBE7...HP / FRBE...D 380-415 3N ~ BROWN BLACK BLUE BLACK BROWN MICRO SWITCH POSITION FRBE74AHP/ FRBE9...D WHITE (15 kW ELECTRIC) FRG94AHP (22 kW GAS) 110 Ohm FRBE74AD (9 kW CONTROL CARD CONFIGURATION ELECTRIC) FRG74AHP (16 kW GAS) ELECTRIC FRYER GAS FRYER DEUTSCH ITALIANO FRANCAIS...
  • Page 34 LAMPE VERTE LAMPADA VERDE GREEN LAMP GRUENE LAMP LAMPE ORANGE ORANGE LAMP ORANGE LAMP LAMPADA ARANCIONE ACC1 FEUERZEUG ACC1-ACC2 ACCENDITORE BRIQUET LIGHTER EVG1-EVG2 ELETTROVALVOLA GAS ELECTROVANNE GAS SOLENOID GAS MAGNET GAS DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG T1-T2 THERMOSTAT ARBEITEN TERMOSTATO...
  • Page 35 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG SCHEMA ELETTRICO - WIRING DIAGRAM FR(B)E94HP IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 11 -...
  • Page 36 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG INSTALLAZIONE / INSTALLATION ! OBBLIGO MONTAGGIO PORTE ! MANDATORY DOOR ASSEMBLY ! MONTAGE OBLIGATOIRE DES PORTES ! MONTAJE OBLIGATORIO DE LAS PUERTAS ! VERPFLICHTUNG TÜRENMONTAGE ! MONTAGEM OBRIGATÓRIA DAS PORTAS ! VERPLICHTE MONTAGE VAN DE DEUREN ! OBOWIĄZKOWY MONTAŻ...
  • Page 37 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG A: FASI 220/240 V ~ 1N 50-60 HZ B: FASI 220/240 V ~ 3 50-60 HZ C: FASI 380/415 V ~ 3N 50-60 HZ Fig. 10 Fig. 11 Fig.
  • Page 38 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG USO / USER FRBE... FRE... FRBE... AD FRBE... AHP IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 14 -...
  • Page 39 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG Fig. Fig. 3/4 MAX Fig. Fig. Fig. Fig. IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 15 -...
  • Page 40 Fig. 1 Fig. 7 CLICK! Fig. 2 Fig.8 Fig. 9 Fig.10 MODELLI / MODELS FRBE9... / FRBE74AHP Fig. 3 Fig.11 Fig. 4 Fig.12 IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 16 -...
  • Page 41 DA TI TECNICI / IMMAGINI / TECHNICAL DA T A / IMG MODELLO / MODEL FRBE94AHP Fig. 5 Fig. 5 Fig. 6 Fig. 6 Fig. 1 Fig. 1 Fig. 2 Fig. 2 Fig. T° IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - 17 -...
