- Page 1 SHOUL DOCK ™ LIGHTING SYSTEM...
- Page 2 TABLE OF CONTENTS & ABOUT SHOUL TABLE OF CONTENTS PACKAGE CONTENTS & WARNINGS CONFIGURATION CONSIDERATIONS 9-10 POWER BOX INSTALLATION 11-18 UNDERWATER LIGHT INSTALLATION 19-20 VERSICONTROL APP GUIDE & RESOURCES ® 21-22 MAINTENANCE & WARRANTY 23-24 GALLERY Scan QR code for product...
- Page 3 10' or 20' extension cords for a maximum 55' from the power box to a light. SHOUL lights are easily adaptable for several configurations, from a straight seawall to a long, two-sided dock.
- Page 4 SHOUL DOCK LIGHTING SYSTEM CONTENTS & WARNINGS PACKAGE CONTENTS Underwater Lights with 25' Cords Mounting Clips does not include screws QTY 4 QTY 8 Control/Power Box Attachment Straps, 72" each Small Cable Ties QTY 1 QTY 5 QTY 15 Extension Cords (purchased separately at ITCSHOPNOW.com) These waterproof cords are for outdoor use only in ambient temperatures below 50°C/122°F...
- Page 5 WARNINGS ∙ Product must be installed in accordance with the installation requirements ∙ For your safety, read and understand all instructions before starting installation ∙ NEVER open Power Box while plugged in to avoid a RISK OF ELECTRIC SHOCK ∙ Use an experienced electrician as needed for install or service ∙...
- Page 6 ∙ Measure and dry fit before beginning installation ∙ Be sure cord drop for lights places lights underwater at all times ∙ Additional extension cords may be needed: only use ITC SHOUL Light extensions ∙ Depending on your configuration there may be extra cord on the light.
- Page 7 LONG DOCK 35' - 55' Max. SEA WALL OR ONE-SIDED DOCK 70' - 110' Max. WARNING: DO NOT SUBMERGE CONNECTION POINTS!
- Page 8 Must use GFIC outlet ∙ 10' and 20' extensions may be purchased from ITC to extend the power cord from 25' to a max of 55' — extensions...
- Page 9 2. On back of Power Box, insert the mounting clips with the expandable end into the six receptacle holes (4 corners and each side) keeping the thin peg pointing up. Carefully tap the peg with a hammer to fully insert into the clip and secure clip to the box. Note: the top two clips should have the screw slot at the top, the side clips should be directed out, and the bottom clips with the slots positioned down.
- Page 10 Power Box and won’t interfere or tangle in any boat or vessel using dock ∙ Determine the mounting location of the SHOUL lights to ensure they will be submerged at all times, while the connection at the Power Box is not submerged ∙...
- Page 12 SHOUL DOCK LIGHTING SYSTEM UNDERWATER LIGHT INSTALLATION LIGHT FIXTURE CONNECTION TO POWER BOX ∙ DO NOT OPEN BOX: All light cords are prewired to easily attach to the Power Box from the outside ∙ DO NOT CONNECT THE POWER BOX to electricity until all install steps are complete ∙...
- Page 13 2. Align the inner prongs of the light fixture cord connectors with the inner receptacle on the Power Box. If orientation is correct, the prongs will slide in freely when inserted. The blue nut on the prongs will snap to seal when correctly seated. Do not force fit prongs.
- Page 14 SHOUL DOCK LIGHTING SYSTEM UNDERWATER LIGHT INSTALLATION ATTACHMENT OPTION 1: PLASTIC ATTACHMENT STRAPS 1. Slide plastic 2. Wrap the strap 3. Using pliers, tighten attachment straps around the pier/piling the plastic strap through the slot in and place light fixture...
- Page 15 4. Route the power 5. Carefully secure 6. When all cord and secure to excess cord away connections are the pier/piling using from high-traffic secure, locate the AC the provided cable areas (i.e. swimmers, cord/plug on the side ties and screws (not boats, and wildlife).
- Page 16 SHOUL DOCK LIGHTING SYSTEM UNDERWATER LIGHT INSTALLATION ATTACHMENT OPTION 2: LAG BOLTS OR SCREWS NOT PROVIDED 1. Hold the light approximately 6-12" below water line at a typical low tide for your area. 2. Drill pilot holes into the piling for the appropriate size of the screws (not included).
- Page 17 ATTACHMENT OPTION 3: PVC PIPE NOT PROVIDED SHOUL Dock Lighting System is designed to allow for mounting with 1-1/4" standard PCV Pipe (pipe not included). 1. Route power cord to Power Box, securing to dock as needed. DO NOT cut, shorten, or pinch the cord.GO TO PAGE 15 TO VIEW LIGHT FIXTURE CONNECTION TO POWER BOX.
- Page 18 ® GETTING STARTED Search “ITC VersiControl” in the App Store or Google Play Store and click install. Turn on the Bluetooth on your phone and open the app: it should automatically connect to the controller. All operational directions are on the app.
- Page 19 EXPLORE OUR RESOURCES VIEW ALL SHOUL™ DOCK LIGHTING PRODUCT DETAILS & INSTALL INSTRUCTIONS Located on our website: itcshopnow.com/ products/shoul-dock-lighting-system DOWNLOAD THE VERSICONTROL® APP Search: ITC VersiControl VERSICONTROL® APP: HOW TO USE & FREQUENTLY ASKED QUESTIONS Located in the App’s settings and here: itc-us.com/versicontrol-help-support...
- Page 20 SHOUL DOCK LIGHTING SYSTEM MAINTENANCE & WARRANTY MAINTENANCE Recommended to visually check for signs of undue heating (cord or component discoloration, damaged parts) or leakage (water or corrosion in interior of lights) at least once per year. LENS CARE For best results, the light’s lens should be kept clean and free of marine growth to ensure continued lighting performance.
- Page 21 WARRANTY ITC underwater lights are designed to provide years of reliable performance. However, should the need for replacement parts arise, they are available through ITC. CONTACT US Email us at support@itcshopnow.com or give us a call at 616.330.4497 or 616.396.1355 for consumer support.
- Page 22 IMAGE GALLERY...
- Page 24 INV #: 700-00230 CONTACT US 616.330.4497 itcshopnow.com support@itcshopnow.com...
