  • Page 1 U12004 | Operating Manual...
  • Page 2 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 1. Safety 2. Machine Layout 2.1 Front Panel Layout 2.2 Rear Panel Layout 3. Package Contents 4. Setup: Mounting The Water Cooler 5. Setup: Using The Water Cooler 6. Troubleshooting Guide...

  • Page 3: Machine Operating Safety

    RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 1. Safety Welding and cutting equipment can be dangerous to both the operator and people in or near the surrounding working area if the equipment is not correctly operated. Equipment must only be used under the strict and comprehensive observance of all relevant safety regulations.

  • Page 4: Gas Cylinders

    RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL Fire hazard • Welding/cutting on closed containers, such as tanks, drums, or pipes, can cause them to explode. Flying sparks from the welding/cutting arc, hot workpiece, and hot equipment can cause fires and burns. Accidental contact of the electrode to metal objects can cause sparks, explosion, overheating, or fire.

  • Page 5: Maintenance

    Selection of Coolant: Only use clean, pure, and anti-corrosive coolant for the machine, such as UNIMIG Coolant. Coolants containing impurities or corrosive substances can lead to machine damage, leakage, and operational abnormalities. It is recommended to use welding coolant for optimal performance.

  • Page 6: Machine Layout

    RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 2. Machine Layout 2.1 Front Panel Layout 1. Screw Cap For Coolant Container 2. Coolant Return Connection (Red) 3. Coolant Flow Connection (Blue) 4. Machine Status Lights Power LED ii. Over-temperature LED iii. Water Flow Error LED 5.

  • Page 7: Package Contents

    RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 3. Package Contents RAZOR TIG 200 AC/DC Water Cooler Mounting Bracket...
  • Page 8 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 4. Setup: Mounting The Water Cooler 1. Remove the 4 screws from the top plate of the water 2. Place the mounting bracket on top of the water cooler cooler unit. unit. 3. Fasten the previously removed screws into the 4.
  • Page 9 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 5. Place the RAZOR TIG 200 AC/DC on top of the 6. Fasten the previously removed screws into the secured mounting bracket. corresponding holes on the mounting bracket to secure it to the water cooler unit.
  • Page 10 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 5. Setup: Using The Water Cooler 1. Unscrew the screw cap for coolant container. 2. Pour coolant into the inlet until it reaches the 'FULL' marker on the coolant viewing window. The maximum coolant capacity of this water cooler is 3.5L.
  • Page 11 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 5. Connect the power plug into the water cooler power 6. Once the machine is powered on and set up for outlet on the back of the RAZOR TIG 200 AC/DC. welding, push the water cooler button on the RAZOR...

  • Page 12: Troubleshooting Guide

    RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 6. Troubleshooting Guide 6.1 Power light does not light up, water pump does not work, water does not flow in the water pipe, and fan does not work. 1. Check Power Connection: Inspect whether the power line is correctly connected. Ensure a secure connection to the power source.
  • Page 13 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL 6.6 Power light lights up, water pump works properly, water flows in the water pipe, and fan works properly. Temperature warning light lights up. 1. Check Operating Power: Inspect if the operating power exceeds the cooling power. Do not exceed the recommended cooling power limits.
  • Page 14 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL NOTES...
  • Page 15 RAZOR TIG 200 AC/DC WATER COOLER OPERATING MANUAL NOTES...
  • Page 16 PH: (02) 9780 4200 PH: (07) 3333 2855 PH: (03) 8682 9911 PH: (08) 6363 5111 FAX: (02) 9780 4210 FAX: (07) 3274 5829 FAX: (03) 9333 7867 FAX: (08) 9417 4781 EMAIL: sales@unimig.com.au EMAIL: qld@unimig.com.au EMAIL: sales@unimig.com.au EMAIL: wasales@unimig.com.au...
