- Page 1 MREP 82 MTM RFID reader module with keypad www.techfass.com RFID reader module with keypad MREP 82 MTM...
- Page 2 Introduction The reader module MREP 82 MTM (dual reader 13.56 MHz & 125 kHz with capacitive keypad) has an integrated lock controller for full one door access control. It is intended either for connection on the APS mini Plus communication bus or for autonomous operation.
- Page 3 Function overview Customizable solution for any customer’s flat Main entrance www.techfass.com RFID reader module with keypad MREP 82 MTM...
- Page 4 The MREP 82 MTM reader module can be used as a standalone or as a part of modular MTM entry panel. One chassis, two independent systems – MREP 82 MTM as a part of access control bus APS mini Plus & audio / video bus for camera unit, each has its own cabling.
- Page 5 • MREP 82 MTM modules connected to the APS mini Plus bus and TECH FASS cloud, control & administration from a web interface (online service WebHit) on a mobile phone. • ‘‘Star connection‘‘? Use the bus repeaters REP 485. •...
-
Page 6: Table Of Contents
Electrical parameters ....................8 Communication interface .................... 8 Mechanical parameters ....................8 Assembly ........................9 Cable connection of MREP 82 MTM ................9 Cables........................10 System bus ....................... 10 RFID radio signal ...................... 10 Meaning of LED bar indicator ................... 11 RFID reading ...................... -
Page 7: Mechanical Design
1 Mechanical design 1.1 Wall mounted MREP 82 MTM can be mounted on the wall either as a standalone one-module design or as a part of a multi-module design. The outline dimensions of MTMSP1M: 140 x 135 x 64 mm. -
Page 8: Technical Parameters
Silver, brushed aluminium Material Plastic, aluminium Environment class General outdoor equipment IV – outdoor general device, Temperature range -25 ÷ +70 IP code IP 54 IK code IK 07 cable 2 x 0,4 www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 9: Assembly
3 Assembly 3.1 Cable connection of MREP 82 MTM The cable of MREP 82 MTM contents 12 wires with following functions: MREP 82 MTM NUMBER COLOR WIRE DESCRIPTION WHERE IT LEADS (EXAMPLE) Pink OUT 2; 60 V, 2 A, open drain... -
Page 10: Cables
If an 125 kHz reader is used, it is necessary to take into account another 125 kHz reader in direct range - for example when checking the door on both sides. In this case, the readers may interfere with each other. In the techfass system, it is possible to use the so-called synchronization of reading between the reader and the reading module, which then do not interfere with each other. -
Page 11: Meaning Of Led Bar Indicator
Address setting mode / Red / green flashing Red / green RS 485 system bus test Continuously lit, flashing Programming mode Yellow Short flashing, period 1 s Door lock release indication www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 12: Rfid Reading
For the frequency 13,56 MHz, the format and length options of the so-called "card serial number" can be set according to the table above. Similarly for the TF Mobile ID mobile application. www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 13: Reading At 125 Khz
The dual variant of the device allows reading media according to 3.1 and 3.2 at the same time. ® ® MIFARE a MIFARE Classic are registered trademarks owned by NXP B.V. ® Android is registered trademark owned by Google LLC. www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 14: Wiring Diagram
Plug the ethernet cable into the cloud connector and to the LAN network with internet access. • Bring the power supply to the reader module and the cloud connector. • Open cloud.techfass.com in your browser from any device connected to the internet. www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 15: Standalone Unit
In this case, the reader module is independent on the entry panel, it is placed just in one module chassis as shown in chapter 1. It can operate autonomously or as part of the APS mini Plus system. Basic operation of the reader module MREP 82 MTM. 5.2.1 Bell output connection (OUT 2) - Page 16 + Full door control by eACS, battery backup for eACS, good for more pro installations - Two power supplies needed, exit button & home receiver events cannot be distinguished in event archive www.techfass.com RFID reader module with keypad MREP 82 MTM...
- Page 17 MTM audio / video unit (depends on the chosen topology of modular MTM entry panel). This means that the bell button, which is a part of MREP 82 MTM module is not necessary. Anyway, you can connect OUT 2 of the reader module and program the MTM audio / video unit inputs the way, that it will ring as well on the dedicated home receiver assigned to call button 1 or call button 2.
-
Page 18: Settings
If we plan to install just one standalone MREP 82 MTM, then APS Reader application and USB converter is fair enough. If we are going to install some system, where MREP 82 MTM will be placed on the RS 485 bus with several other modules (several HW addresses), we recommend to set the system on the table at home and use web interface to set all necessary parameters. -
Page 19: Change Of Hw Address
“ID code”, select the HW address you would like to have and press Start. Now take the ID media and show it to the appropriate MREP 82 MTM reader module. After that this reader module will have set HW address. -
Page 20: Configurable Parameters
Press 'Connect' at the top of the blue menu ▪ Press "Set" (the selected HW address is set) 6.4 Configurable parameters When the HW address is set, we can configure the parameters of MREP 82 MTM written below. 6.4.1 Door control Lock control Standard... - Page 21 Off On Events archive saving options 4 Input 2 On event saving Off On 5 Output 1 Off event saving Off On 6 Output 1 On event saving Off On default settings www.techfass.com RFID reader module with keypad MREP 82 MTM...
- Page 22 Off On 2 Key press Off On Wake up options 3 Attaching the ID media to the Entry reader Off On 4 Key press on the Entry keypad Off On default settings www.techfass.com RFID reader module with keypad MREP 82 MTM...
-
Page 23: Operating Mode
In this case, it is advisable to install the module in a safe zone or where the greater safety is not needed. For unsecured zones, we recommend to connect MREP 82 MTM to the WIO 22 module to its Wiegand output. WIO 22 is a DIN rail relay module, which is placed on the secured place, e.g. -
Page 24: Standard With Entry Reader
Facility code 0x01 + 16 data bits (MSB) (MSB) Facility code 0x01 + 16 data bits (MSB) 56 data bits (MSB) 56 data bits (MSB) 56 data bits, reversed (LSB) 56 data bits, reversed (LSB) www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 25: Functions
If the reader module reads the ID card during the "Door open" function via the communication line (in online mode) and if the read ID is not valid, it is signaled by an acoustic signal "invalid ID" regardless of the configuration of the acoustic lock release message. www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 26: Permanent Lock Release Based On Valid Time Schedule
The function activation logic on each port is configurable. The function is activated if at least one of the ports is active and set as disable. The module in the disabled state exhibits the following behavior: ▪ Users with set time schedule cannot trigger the door open function if it is disabled www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 27: Alerts And Their Signaling
Alarm ID with a flag occurs when a card (ID) with flag is read. 8.9.6 Reading ID in time of alert Reading a valid ID has no effect on the alarm conditions themselves. It is terminated with a valid ID www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 28: Offline Setting (Programming) Mode
Please visit the following link to view more information: When inserting cards using programming cards, it is not possible to work with time schedules, so the cards are still valid. www.techfass.com RFID reader module with keypad MREP 82 MTM... -
Page 29: Other
9.3 Electrical waste According to WEEE directive (2012/19/EU), this product cannot be disposed of as unsorted municipal domestic waste and has to be returned to recycling center after its lifetime is over. www.techfass.com RFID reader module with keypad MREP 82 MTM... - Page 30 TECH FASS s.r.o. Věštínská 1611/19, Praha...
