- Page 1 WREM 81 MTM(VR) RFID reader 13,56 MHz, 125 kHz...
- Page 2 Introduction RFID reader WREM 81 MTM(VR) with wiegand output, reads media at 125 kHz (EM Marin) and is designed for connection to control modules and door controllers of the APS mini Plus or APS 400 system, or to third party controllers. The reader is equipped with a configurable WIEGAND data output usable with most third party systems.
- Page 3 Block diagram The WREM 81 MTM(VR) reader is a module for a modular MTM entry panel. MTM entry panel itself is part of the home intercom system, it has its own power supply and bus for receivers. WREM 81 MTM(VR) has its own cabling, configuration bus and wiegand interface for door controller or APS mini Plus or APS 400 reader module or third party wiegand controller.
- Page 4 • The reader can be configured via the RS 485 bus using the APSUSB converter and the program APS Reader.
-
Page 5: Table Of Contents
Electrical parameters ....................6 Communication interface .................... 6 Mechanical parameters ....................6 Assembly ........................7 Cable connection of WREM 81 MTM(VR) ..............7 Installation instructions ....................8 RFID reading ......................9 Reading at 125 kHz ....................9 Wiegand output configuration ..................9 Wiring diagram ....................... -
Page 6: Technical Parameters
Service data bus RS 485 Wiegand output Wiegand Formats 26, 32, 42, 44, 56 bits 1.3 Mechanical parameters PARAMETER WREM 81 MTM WREM 81 MTMVR JEDNOTKA Weight Dimensions l x w x h 137,5 x 136 x 64 (34) Mounting Wall-mounted or recessed Color &... -
Page 7: Assembly
2 Assembly 2.1 Cable connection of WREM 81 MTM(VR) Cable of WREM 81 MTM(VR) contents 12 wires with following functions: WREM 81 MTM(VR) NUMBER COLOR DESCRIPTION WHERE TO CONNECT (example) Purple Do not connect Blue Power GND Power supply GND Power Vin 8 ÷... -
Page 8: Installation Instructions
2.2.1 Reader installation The WREM 81 MTM(VR) reader is already delivered in the MTMRFID module. It contains short 0,4 m long wires. Check for any voltage drop on the supply wires so that it is not below Vin min. Use a separate pair of UTP cable (if used) for each Wiegand signal, do not connect the W0 and W1 signals together in one twisted pair. -
Page 9: Rfid Reading
The device read media on a frequency of 125 kHz like EM Marin (e.g. EM4200, EM4305). Next example of supported media technology is Jablotron ID. 125 kHz settings possibilities: Default settings for 125 kHz. 3.2 Wiegand output configuration WREM 81 MTM(VR) www.techfass.com RFID reader... -
Page 10: Wiring Diagram
APS Reader. ▪ FIGURE B: Connection WREM 81 MTM(VR) to the wiegand door controller The Wiegand output of the reader is connected to the Wiegand input of the door controller, eg MWGD 82 or MWGD 46. Do not pull the wiegand interface W0, W1 in one twisted pair of UTP cable, use two, one pair for each signal. - Page 11 FIGURE C: As part of a multi-module MTM entry panel, simply connect the 4 wires of the reader module. When connecting the WREM 81 MTM(VR) to the MTM entry panel, you can use your own access control system power supply. Connect the wiegand interface & power supply (minimum), and if possible, the signal for LED and buzzer control and bring the RS 485 wires to an accessible place for possible update fw or configuration.
-
Page 12: Settings
Standard em marin & TF ID ▪ Jablotron ID *Default settings: all enabled. ID Length 125 kHz bits * Default settings: 40 bits format. Wiegand output format settings 125 kHz bits Data *Default settings: 42 bits format. WREM 81 MTM(VR) www.techfass.com RFID reader... - Page 13 Facility code 0x01 + 16 data bits Facility code 0x01 + 16 data bits (MSB) (MSB) (MSB) 56 data bits (MSB) 56 data bits (MSB) 56 data bits, reversed (LSB) 56 data bits, reversed (LSB) www.techfass.com RFID reader WREM 81 MTM(VR)
-
Page 14: Other
European directives. The declaration of conformity document can be downloaded from our web site: https://www.techfass.com/en/download/11/conformity-declaration 6.3 Electrical waste According to WEEE directive (2012/19/EU), this product cannot be disposed of as unsorted municipal domestic waste and has to be returned to recycling center after its lifetime is over. WREM 81 MTM(VR) www.techfass.com RFID reader... - Page 15 TECH FASS s.r.o. Věštínská 1611/19, Praha...
