- Page 1 WREM 82 MTM(VR) RFID reader 13,56 MHz, 125 kHz...
- Page 2 Introduction RFID reader WREM 82 MTM(VR) with wiegand output, reads media at 125 kHz (EM ® Marin) & 13.56 MHz, (MIFARE , NFC)) and is designed for connection to control modules and door controllers of the APS mini Plus or APS 400 system, or to third party controllers.
- Page 3 Block diagram The WREM 82 MTM(VR) reader is a module for a modular MTM entry panel. MTM entry panel itself is part of the home intercom system, it has its own power supply and bus for receivers. WREM 82 MTM(VR) has its own cabling, configuration bus and wiegand interface for door controller or APS mini Plus or APS 400 reader module or third party wiegand controller.
- Page 4 • The reader can be configured via the RS 485 bus using the APSUSB converter and the program APS Reader.
-
Page 5: Table Of Contents
Electrical parameters ....................6 Communication interface .................... 6 Mechanical parameters ....................6 Assembly ........................7 Cable connection of WREM 82 MTM(VR) ..............7 Installation instructions ....................8 RFID reading ......................9 Reading at 13,56 MHz ....................9 Reading at 125 kHz ....................10 Dual reading at 13,56 MHz &125 kHz .............. -
Page 6: Technical Parameters
Service data bus RS 485 Wiegand output Wiegand Formats 26, 32, 42, 44, 56 bits 1.3 Mechanical parameters PARAMETER WREM 82 MTM WREM 82 MTMVR JEDNOTKA Weight Dimensions l x w x h 137,5 x 136 x 64 (34) Mounting Wall-mounted or recessed Color &... -
Page 7: Assembly
2 Assembly 2.1 Cable connection of WREM 82 MTM(VR) Cable of WREM 82 MTM(VR) contents 12 wires with following functions: WREM 82 MTM(VR) NUMBER COLOR DESCRIPTION WHERE TO CONNECT (example) Pink Do not connect Purple Do not connect Blue GND power... -
Page 8: Installation Instructions
2.2.1 Reader installation The WREM 82 MTM(VR) reader is already delivered in the MTMRFID module. It contains short 0,4 m long wires. Check for any voltage drop on the supply wires so that it is not below Vin min. Use a separate pair of UTP cable (if used) for each Wiegand signal, do not connect the W0 and W1 signals together in one twisted pair. -
Page 9: Rfid Reading
RFID card). You have to download TF Mobile ID application and follow its manual. The TF Mobile ID application is available for free download on Google Play. ® ® jsou registrované obchodní značky NXP B.V. MIFARE a MIFARE Classic ® je registrovaná obchodní značka Google LLC. Android WREM 82 MTM(VR) www.techfass.com RFID reader... -
Page 10: Reading At 125 Khz
Default settings for 125 kHz. 3.3 Dual reading at 13,56 MHz &125 kHz The dual variant of the device allows reading media according to 3.1 and 3.2 at the same time. 3.4 Wiegand output configuration www.techfass.com RFID reader WREM 82 MTM(VR) -
Page 11: Wiring Diagram
APS Reader. ▪ FIGURE B: Connection WREM 82 MTM(VR) to the wiegand door controller The Wiegand output of the reader is connected to the Wiegand input of the door controller, eg MWGD 82 or MWGD 46. Do not pull the wiegand interface W0, W1 in one twisted pair of UTP cable, use two, one pair for each signal. - Page 12 FIGURE C: As part of a multi-module MTM entry panel, simply connect the 4 wires of the reader module. When connecting the WREM 82 MTM(VR) to the MTM entry panel, you can use your own access control system power supply. Connect the wiegand interface & power supply (minimum), and if possible, the signal for LED and buzzer control and bring the RS 485 wires to an accessible place for possible update fw or configuration.
-
Page 13: Settings
Standard em marin & TF ID ▪ Jablotron ID *Default settings: all enabled. ID Length 125 kHz bits * Default settings: 40 bits format. Wiegand output format settings 125 kHz bits Data *Default settings: 42 bits format. WREM 82 MTM(VR) www.techfass.com RFID reader... - Page 14 Facility code 0x01 + 16 data bits Facility code 0x01 + 16 data bits (MSB) (MSB) (MSB) 56 data bits (MSB) 56 data bits (MSB) 56 data bits, reversed (LSB) 56 data bits, reversed (LSB) www.techfass.com RFID reader WREM 82 MTM(VR)
-
Page 15: Other
European directives. The declaration of conformity document can be downloaded from our web site: https://www.techfass.com/en/download/11/conformity-declaration 6.3 Electrical waste According to WEEE directive (2012/19/EU), this product cannot be disposed of as unsorted municipal domestic waste and has to be returned to recycling center after its lifetime is over. WREM 82 MTM(VR) www.techfass.com RFID reader... - Page 16 TECH FASS s.r.o. Věštínská 1611/19, Praha...
