Summary of Contents for TECHFASS MREM 77 EISGRT-MF
- Page 1 MREM 77 EISGRT Reader module 13,56 MHz, 125 kHz...
- Page 2 Assembly in the installation boxes KU 68, LK 80. c. Variants KATALOGUE NUMBER PART NUMBER SYSTEM VARIANT RFID frequency 534771A2 MREM 77 EISGRT-MF APS mini Plus KU 68-1901 13,56 MHz 53477311 MREM 77 EISGRT-EM APS mini Plus KU 68-1901 125 kHz...
- Page 3 e. Block diagram Full door control, standalone case ▪ Bus system case with web control & administration...
-
Page 4: Table Of Contents
Content Technical parameters ....................5 Electrical parameters ....................5 Communication interface .................... 5 Mechanical parameters ....................5 Assembly ........................6 Connection of MREM 77 E / F plug-able terminal block ..........6 Installation instructions ....................7 Wiring diagram ......................8 Door control by RFID medium .................. -
Page 5: Technical Parameters
Dimensions D, h D 73,5; h 43,5 Inside installation box KU68-1901 Mechanical mounting Or surface installation box LK 80 Colour Grey Material Plastic Environmental class Indoor device general -10 ÷ + 55 Temperature range www.techfass.com RFID reader module MREM 77... -
Page 6: Assembly
Example: The reader module is able to control the door standalone or as part of the APS mini Plus bus system. In addition to the power supply, the module contains, 2 inputs, 1 input / output, alert output, wiegand input / output, RS 485 and relay. www.techfass.com RFID reader module MREM 77... -
Page 7: Installation Instructions
If a 125 kHz reader is used, it is necessary to take into account another 125 kHz reader in direct range - for example when checking the door on both sides. In this case, the readers may interfere with each other. In the techfass system, it is possible to use the so-called synchronization of reading between the reader and the reading module, which then do not interfere with each other. -
Page 8: Wiring Diagram
Wiring diagram 2: Up to 32 modules can be connected to one line of the APS mini Plus system and thus manage all doors centrally. A REP 485 repeater can be used for star connection. www.techfass.com RFID reader module MREM 77... -
Page 9: Rfid Reading
Mobile phones equipped with NFC technology, OS Android 4.4 Kit Kat (or higher) can be used for identification (replaces the usual RFID card). You have to download TF Mobile ID application and follow its manual. The TF Mobile ID application is available for free download on Google Play. www.techfass.com RFID reader module MREM 77... -
Page 10: Reading At 125 Khz
The dual variant of the device allows reading media according to 3.1 and 3.2 at the same time. ® ® MIFARE a MIFARE Classic are registrated trade marks of NXP B.V. ® Android je registred trade mark of Google LLC. www.techfass.com RFID reader module MREM 77... -
Page 11: Settings
If we want to set the reader module MREM 77 E / F, e.g. its HW address or configure its parameters, we must connect it to the computer and control software. Physical connection is possible using the device via USB APSUSB https://www.techfass.com/cs/produkty/102/produkt/1216/apsusb via LAN APSLAN https://www.techfass.com/cs/produkty/102/produkt/94/apslan Alternatively, from anywhere with a web browser using CON 110.IP... -
Page 12: Meaning Of The Led Indicator
ID media reading Alternation Address setting mode / Red / green flashing Red / green RS 485 system bus test Continuously lit, flashing Programming mode Yellow Short flashing, period 1 s Door lock release indication www.techfass.com RFID reader module MREM 77... -
Page 13: Configurable Parameters
* Valid for standard output mode (lock control). Not valid for change of state option. ** In WebHit, the time shift is done automatically according to the selected time zone. *** Online authorization function is not available yet in WebHit. www.techfass.com RFID reader module MREM 77... -
Page 14: Operating Modes
WIO 22 module to its Wiegand output, we place WIO in a safe place, eg in a rack / cabinet or from the inside above the door, from where it already controls the lock. The WIO module must first be paired with the MREM 77 reader module. https://www.techfass.com/cs/produkty/102/produkt/402/wio-22 www.techfass.com... -
Page 15: External Reader With Wiegand Output
Facility code 0x01 + 16 data bits Facility code 0x01 + 16 data bits (MSB) (MSB) (MSB) 56 data bits (MSB) 56 data bits (MSB) 56 data bits, reversed (LSB) 56 data bits, reversed (LSB) www.techfass.com RFID reader module MREM 77... -
Page 16: Function
It is possible to set a date for each ID at which the ID expires and will no longer be valid. The expiration is evaluated every time the data in the RTC module changes and when new access rights are loaded. ! Note: This feature is currently only available on desktop applications. www.techfass.com RFID reader module MREM 77... -
Page 17: Antipassback Function (Apb)
Alerts are reported as follows: ▪ In software, by system bus (alerts 1, 2, 3, 4, 5) ▪ Acoustic (alerts 1, 2, 3, 4) ▪ Activating the alert output (alerts 1, 2, 3, 5) www.techfass.com RFID reader module MREM 77... - Page 18 The module itself is ready for the connection of the tamper, for possible installation it is necessary to share the intended cover and agree in advance by contacting support@techfass.cz. The "Violation" alarm state is generated by activating the Tamper signal by opening the cover of the reader module, or by changing the state of the 2nd or 3rd input in the tamper configuration.
-
Page 19: Simplified Access Rights Model
One by one, read the cards About seconds after for inserting: the reader goes which are to be granted inserting the last card the into programming mode. access. reader module goes back into standard operating mode. www.techfass.com RFID reader module MREM 77... - Page 20 ID used in right after the ID used in into standard operating precious step, read precious step, read mode. programming card programming card deleting. inserting. Pic.5 c): Deleting cards “above or below” www.techfass.com RFID reader module MREM 77...
- Page 21 2, which is available, and using the procedure from chapter 7.10.3 – Read + (inserting) programming card, then 5x + (inserting) programming card again, then card 2, and finally + (inserting) programming card again. Register the change in your table. www.techfass.com RFID reader module MREM 77...
- Page 22 A new card is always inserted at the position after the last inserted card. In case of deleting all cards using the procedure described in chapter 7.10.4, it is necessary to create a new filing table. www.techfass.com RFID reader module MREM 77...
-
Page 23: Other
The manufacturer TECH FASS ltd. declares, that the product follows legal requirements and fulfils necessary European directives. The declaration of conformity document can be downloaded from our web site: https://www.techfass.com/en/download/11/conformity-declaration 8.3 Electrical waste According to WEEE directive (2012/19/EU), this product cannot be disposed of as unsorted municipal domestic waste and has to be returned to recycling center after its lifetime is over. - Page 24 TECH FASS s.r.o. Věštínská 1611/19, Praha...
