Peavey ED-100 Operating Manual

iPW
OPERATING GUIDE
WARMING
TO PREVENT ELECTRICAL SHOCK
OR FIRE HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOIS¬
TURE. BEFORE USING THIS APPLIANCE
READ BACK COVER FOP FURTHER
WARNINGS.
0
•
GENERAL DESCRIPTION
The ED- 100 is a self-contained amplification system which features inputs, equalization, and monitor
capability specifically designed for use with electronic drums. The ED-100 will deliver 65 watts RMS into its
heavy-duty 15" Scorpion® speaker. Peavey design engineers have also included a special constant-directivity
horn for faithful reproduction of high frequency signals. To protect the speakers and to prevent clipping
distortion, the ED-100 features Peavey's patented DDT" compression circuitry.
Since the ED-100 has been designed specifically for use with electronic drum systems, it offers many features
not found on other amplification systems. Independent monitor mixing, four-band active EQ. and complete
effects patching capability allow the drummer to realize maximum potential from today's electronic drum
systems.
The ED-100 is built to withstand the rigors of a night-after-night touring environment. The cabinet is con¬
structed of%" wood and is covered with the heaviest available 34 oz. Tolex®. Ruggedness isenhanced by the use
of heavy steel corners and a steel-reinforced carrying handle. Internally, the ED-100features chassis construc¬
tion of heat treated aluminum alloy and utilizes the finest components available
Although the ED-i00 incorporates many sophisticated features, its operation is relatively simple. In order to
quickly familiarize yourself with the ED-100, and to avoid potontially hazardous or damaging situations, ploaso
read this operating guide carefully and completely and keep it handy for future reference
