Akytec PR200 Manual

WARNING
Installation may only be performed when the relay and all
connected devices are powered off.
Voltage on the terminals can be dangerous!
CAUTION
It is necessary to observe the polarity while connecting 24V DC
power supply! Voltage reversal can damage the device.
CAUTION
Installation and maintenance may only be carried out by
specialist personnel using the correct tools!
NOTICE
It is recommended to configure and program the device prior to
installation and wiring.
1. Ordering information
2. Specifications
Table 1 General specification
Parameter
230.1.X
230 (94...264) V AC;
Power supply
Power consumption 10 VA
Galvanic isolation
—
Integrated voltage
source
—
Galvanic isolation
IP Code
Dimensions
Mounting
Weight
Table 2 Digital inputs
Parameter
Input voltage
Input voltage, max.
HIGH level
LOW level
Pulse length, min.
Response time, max.
Galvanic isolation against
other circuits
Table 3 Analog inputs
Parameter
ADC resolution
Input signal
Input resistance (for 0-10 V)
Shunt resistance
(for 4-20 mA)
Basic error
Temperature influence
HIGH/LOW threshold
(adjustable in ALP)
LOW/HIGH threshold
(adjustable in ALP)
Pulse length, min.
Signal frequency, max.
Table 4 Digital outputs
Parameter
Type
AC
Switching capacity
DC
PR200_3-EN-125853-1.4
© All rights reserved. Subject to technical changes and misprints.
Supply voltage
230 – 230 (94...264) V AC
24 – 24 (19...30) V DC
I/O
1 – 8 DI, 6 DO
2 – 8 DI, 4 AI, 8 DO, 2 AO (4-20 mA)
4 – 8 DI, 4 AI, 8 DO, 2 AO (0-10 V)
Interfaces
0 – none
1 – RS485
2 – 2 × RS485
Value
230.2/4.X 24.1.X
24 (19...30) V DC
50 (47...63) Hz
17 VA 10 W
2830 V
24±3 V DC,
—
100 mA
—
1780 V
IP20
123 × 108 × 58 mm
DIN rail (35 mm)
approx. 600 g
Value
230.X.X
230 V AC
264 V AC
159...264 V /
8.5...30 V / 2...15 mA
0.75...1.5 mA
0...40 V / 0...0.5 mA -3...+5 V / 0...15 mA
50 ms
100 ms
2830 V
Value
12 bit
Analog mode
0-10 V, 4-20 mA, 0-4 kΩ
61 kΩ
121 Ω
±0.5 %
±0.5 % / 10 °C
Digital mode
1...8 V
2...9 V
5 ms
100 Hz
Value
relay (NO)
5 A, 250 V AC (resistive load)
3 A, 30 V DC
PR200
Programmable relay
Load current at 5 V DC, min.
Service life,
electrical
Galvanic isolation against
other circuits
Galvanic isolation between
output groups
Table 5 Analog outputs
Output signal
External voltage supply
Basic error, max.
Temperature influence
Inductive load, max
(for 4-20 mA)
Signal conversion time
DAC resolution
Galvanic isolation against
other circuit
3. Operating conditions
The device is designed for natural convection cooling.
The following environmental conditions must be observed:
• clean, dry and controlled environment, low dust level
• closed non-hazardous areas, free of corrosive or flammable gases
Table 6 Operating conditions
Condition
Ambient temperature
Transportation and storage
Relative humidity
24.2/4.X
Attitude
IP code
EMC immunity
10 W
EMC emission
1780 V
4. Installation
—
—
24.X.X
24 V DC
30 V DC
2 ms
30 ms
Installation:
1. Place the device on a DIN rail as shown in Fig. 2.
2. Press the device firmly against the DIN rail in the direction of arrow 2
until the latch locks.
3. Wire the device using the supplied terminal blocks.
Removing:
1. Take off the terminal blocks without disconnecting wires.
2. Insert a screwdriver into the eyelet of the slide interlock.
3. Loosen the slide interlock and then remove the relay from the DIN rail.
PR200 is equipped with plug-in terminal blocks which enable quick
replacement of the device without disconnecting the existing wiring.
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany
Parameter
AC
DC
Parameter
4-20 mA (X.2.X), 0-10 V (X.4.X)
up to 80 % (at +25 °C, non-condencing)
up to 2000 m above sea level
conforms to IEC 61000-6-2
conforms to IEC 61000-6-4
Fig. 1 – Dimensions
Fig. 2 – Installation
Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
Value
10 mA
200,000 switching cycles
100,000 switching cycles
2830 V, in groups of 2
1780 V
Value
15...30 V
±0.5%
±0.05% / 10°C
50 μH
100 ms
10 bit
2830 V
Permissible range
-20...+55 °C
IP20
