Block Control - DCCconcepts Super Panel Setup

Super Panel is an extremely powerful piece of hardware and we will never be able to document
all the possibles uses of the product. Over the next 4 manuals we will endeavour to show sample
programming for various solutions. With a little bit of thinking they can be used as a starting point
for other projects you may think of.
In these guides we will endeavour to show you a step by step guide to some practical uses of the
Super Panel.
These will include, in separate volumes:
Point Motor Control
Signal Control
Locomotive Control

Block Control

At the end of each sample we will include a complete parts list of everything we used. Please note,
this is by no means the only components you could use, and the benefit of the Super Panel is its
ability to interface with various types of switches and components.
Once you have programmed a few different switch types, controlling various point motors you will
see the process is straight forward and logical.
It is always advisable to write out before hand, using the sheets at the end of the Super Panel User
Guide, each step you are going to program. This way, you shouldn't miss out any crucial steps in
your command structure.
In all these guides we will presume the Super Panel is configured correctly for the operation you
wish to undertake. For example, the CAB address is correct and the range of inputs is specified.
If you are unsure about any of these initial step up commands, please revisit the Super Panel User
Guide and re-read the relevant pages.
You can download the full Super Panel User Guide here:
Or you can download the manual by entering this link:
www.dccconcepts.com/manual/superpanel-full-user-guide
DCCconcepts Super Panel Point Motor Control Manual V1.0 March 2024
