Bioreba HOMEX 6 Instructions

Product Information
HOMEX 6 Instructions
Filling the rack
Insert 1 to 5 extraction bags in
the open rack.
Changing the rack
2
To change the rack, push the
knobs (2) at the two fixing-
screws and pull the screws out.
Inser t the rack and put the
screws back in position.
Maintenance, storage and corrosion protection
5
5
1/1
Version: 5 - 05.02.2024
Adaptations from last version: Minor change in maintenance, new QR code for video tutorial.
BIOREBA AG
www.bioreba.com
Christoph Merian-Ring 7
CH-4153 Reinach
Switzerland
Closing the rack
1
Close the rack by turning the
two clamping-screws (1) to fix
the bags in the homogenizing
position.
Removing the ball-bearing head
To replace or clean the ball head, first unscrew the side screw (3) and
then remove the cover. To completely remove the head, remove the
head locking screw (4). When reassembling the head, it is important
to insert the fixing screw (4) in the recess of the metal support. Scan
the QR code to watch a short video tutorial (starts at 0:49).
Immediately remove spills of extraction buffer with a humid soft cloth,
then wipe dry - in particular when buffer entered the ball-bearing head.
Lubrify the two gliding axes (5) daily with a soft cloth, wetted with oil or
by using an anti-corrosion protection spray. Check the holding-screws
of the motor and the rack and tighten them if necessary. Replace the
aluminium bars holding the bags when they look worn. They are made
of „soft" aluminium to prevent the ball-bearing head from damage.
HOMEX 6 contains parts which may rust. Store and operate the HOMEX
6 at a dry place to avoid corrosion.
Your Partner in Agro-Diagnostics
phone +41 61 712 11 25
fax +41 61 712 11 17
Homogenizing
Switch the motor on and homo-
genize the sample by gliding the
„ball-bearing head" over the
bags, using the handle.
3
Scan me.
Watch the tutorial on our YouTube channel.
admin@bioreba.ch
www.bioreba.com
4
