Page 1: Table Of Contents
TECHNICAL MANUAL Sparklike Laser Integrated ™ Table of Contents Technical specifications Maintenance Instructions Specifications Daily Operation Instructions Safety Guide Troubleshooting General Description General Service and Maintenance Operation Instructions Sparklike technology since 2000... -
Page 2: Technical Specifications
The results are stored to a hard drive and can be transferred to an external system. The operation of the Sparklike Laser Integrated will be linked to the insulating glass line cycle and operation. -
Page 3: Safety Guide
Equipment is designed to be used with the protection covers and operating the equipment with the protection covers removed is strictly forbidden. Do not open or remove any of the protective covers inside the electrical cabinet without consulting Sparklike service for instructions. Electrical couplings should not be modified without consulting the device supplier, modifying couplings in an incorrect manner might lead to device failure and imminent danger for the operator of the device. -
Page 4: General Description
4. GENERAL DESCRIPTION General description, main parts General view (isometric general view) Picture 1: Isometric front side view Protective covers User interface Main switches Safety mains switch Electrical cabin Electrical connection point Flushing gas connection point Picture 2: Isometric rear view: 8. -
Page 5: Operation Instructions
Double glass thickness of the glass and the space between the measurement is set as a default for Sparklike Laser glasses as well as the total thickness of the IGU. You analyzer, this can be observed from the “Double will get this reading whilst your gas concentration IG”... - Page 6 5.1.2 User interface – Settings Page “Measurement time” (2) drop-down box indicates the time to collect data from one cavity. This can With automatic measurement manual presets are be adjusted between 2–5 seconds. The default time not used/needed. is 5 seconds. Longer measurement time is advised The Settings Page of the software entails the for greater accuracy.
- Page 7 Settings page Presets Measuring time Measuring count Low and High limits Results tab 5.1.3 Software – Test Page normal for the signal peaks to drift in use a little The Test Page of the software provides the laser bit. The device functions within normal parameters temperature and current check function.
-
Page 8: Maintenance Instructions
6. MAINTENANCE INSTRUCTIONS Maintenance of the Y and Z movers. In picture 3 lubrication nozzles L1 – L6 are shown, which are used for lubricating the bearings on the movers. Picture 3: isometric inside view Z-movement home sensor Lubrication points L1: Z-movement center sledge L2: Z-movement rear sledge L3: Z-movement front sledge... - Page 9 “Self-check” test in the “Settings” page for gas concentration inside the measuring head. This ensures the correct operation of Sparklike Laser. To ensure the quality of the measurements it is recommendable that the operator checks the oxygen concentration regularly.
- Page 10 Self-check test) the button labeled “Measure” Sparklike Laser is a gas fill analyzer; however, it can be pressed in the “Main page” of the device measures the oxygen absorption peaks from the software.
- Page 11 Save and close the file. cabinet. Stop and restart the Sparklike Application to use the new settings values. NOTE: It is important to perform the shutdown like with any common computer using the windows 7.5 Understanding the results...
-
Page 12: Troubleshooting
10-15min and then run the I&R test. If the problem Other causes for this error might include a faulty persists, please contact Sparklike service for further DAQ card (in very rare cases) or that the USB cable connecting the DAQ card to the onboard computer assistance. - Page 13 If that does not help, shut down the Windows, and wait 20 seconds before Sparklike Laser is a gas fill analyzer that works restarting the device. by measuring the oxygen inside the glazing unit. To ensure correct readings, oxygen needs to be...
-
Page 14: General Service And Maintenance
9.2 Technical support using remote connection Sparklike can offer remote technical support using TeamViewer application. Connect your device to the Internet using an Ethernet cable. The Ethernet connector is in the connector panel inside the electrical cabinet. Please contact Sparklike service@ sparklike.com to open the remote connection for... - Page 15 Like any measuring device, Sparklike Laser Integrated™ requires annual calibration and maintenance to keep accuracy and reliability. Check Sparklike web page for more information. SPARKLIKE OY www.sparklike.com Helsinki, Finland 10/2023...
