APPENDIX
Controls
VOLUME control; A/D INPUT level control; Mode select buttons: PLAY,
UTIL (UTILITY), MODE, EDIT, EFFECT, EQ; other buttons: MUTE/SOLO,
ENTER, EXIT, PART q , SELECT w , VALUE q ; data dial;
POWER button
Jacks and Terminals
Front panel: PHONES jack (1/4"), A/D INPUT 1, 2 jacks (1/4"),
Rear panel: INDIVIDUAL OUTPUT 1, 2 jacks; OUTPUT R, L/MONO jacks
(Right, Left/Mono); DC IN jack; TO HOST terminal; HOST SELECT switch;
MIDI IN A/B, MIDI OUT, and MIDI THRU terminals
Computer/MIDI Interface
Direct connection to host computer port (RS-232C, RS-422) with optional
cables (CCJ-PC1, CCJ-PC1, CCJ-MAC); MIDI terminals allow connection to
MIDI sequencer or MIDI controller
Data Transfer (Baud) Rate
MIDI — 31,250 bps (bits per second)
Mac — 31,250 bps
PC-1 — 31,250 bps
PC-2 — 38,400 bps
Power Supply
Yamaha PA-3B AC Adaptor (included)
Dimensions (W
483 229 44 mm (19" 9"
Weight
2.4 kg (5 lbs., 5 oz.)
Included Accessories
Owner's Manual, Yamaha PA-3B AC Adaptor
150
D H)
1-3/4")
* Specifications subject to change without notice.
