VR8304M Intermittent Pilot
Combination Gas Control

APPLICATION

These intermittent pilot gas controls are used in gas-
fired appliances with capacities up to 300 feet
1 inch wc pressure drop [8.5 meters
on natural gas. They include a manual valve, two
automatic operators, pressure regulator, and a pilot
adjustment. See Table 1 for temperature range and
regulator type. The VR8304M setup for natural gas
includes a 393691 LP conversion kit. The kit contains a
new cap screw, pressure regulator adjustment screw, a
tapered spring, and a conversion label. The control must
be equipped with a standard servo pressure regulator.
Body Pattern:
Straight-through body pattern.
Size (Inlet x Outlet)
1/2 in. x 1/2 in.
1/2 in. x 3/4 in.
3/4 in. x 3/4 in.
a
Capacity based on 1000 Btu/ft
0.64 specific gravity natural gas at 0.25 kPa pressure drop).
Use conversion factors in Table 3 to convert capacities
for other gases.
Table 3. Gas Capacity Conversion Factors.
Gas Specific Gravity
Manufactured
Mixed
Propane
3
3
/hour at 0.25 kPa]
Capacity at 1 in. wc
Pressure Drop
240 cfh (6.8 cmh)
270 cfh (7.6 cmh)
300 cfh (8.5 cmh)
3
, 0.64 specific gravity natural gas at 1 in. wc pressure drop (37.3 MJ/m
Multiply Listed
Capacity By
0.60 0.516
0.70 0.765
1.53 1.62
Inlet x Outlet Sizes Available:
1/2 x 1/2 in., 1/2 x 3/4 in., and 3/4 x 3/4 in.(factory-
installed inlet flange).
/hour at
Adapters:
Adapters available for 1/2 and 3/4 in. straight and angle
connections. Refer to Table 4.
Electrical Ratings:
Voltage and Frequency: 24 Vac, 60 Hz.
Current Draw: 0.70 A.
Table 1. Temperature Range and Regulator Type.
Model
Number
VR8304M
Table 2. Capacity
Minimum Regulated
a
Capacity
30 cfh (0.8 cmh)
30 cfh (0.8 cmh)
30 cfh (0.8 cmh)
Table 4. Adapter (Flange) Part Numbers.
Inlet/Outlet
Pipe Size
1/2 in. NPT
3/4 in. NPT
a
Flange kits include one flange with attached O-ring
and four mounting screws.
Approvals:
American Gas Association Design Certificate:
UP-70-69A.
Canadian Gas Association Design Certificate:
UP-70-69A.
Australian Gas Association Design Certificate:
4214.
DELTA C: P-70-42A19.
Installation INSTRUCTIONS
Ambient Temperature
Range
-40 °F to +175 °F
-40 °C to +79 °C
Maximum Regulated
340 cfh (9.6 cmh)
370 cfh (10.5 cmh)
415 cfh (11.8 cmh)
Part Number
Flange Without Hex
Type Wrench
Straight 393690-6
Elbow 393690-3
Straight 393690-4
Elbow 393690-5
Regulator Type
Standard-
opening
Capacity
3
,
a
With Hex
Wrench
393690-16
393690-13
393690-14
393690-15
69-0662-02
