Summary of Contents for Mediana HeartOn T16
- Page 1 OPERATOR’S MANUAL HeartOn T16 AED Trainer Manufacturer Mediana Co., Ltd 132 Donghwagongdan-ro, Munmak-eup, Wonju-si, Gangwon-do, Korea Tel: (82) 2 542 3375 (82) 33 742 5400 Fax: (82) 2 542 7447 (82) 33 742 5483 Part Number: A7705-3 Revised Date: 2023-05...
- Page 2 This page is intentionally left blank.
-
Page 3: Table Of Contents
Contents Configuration of AED Trainer ........................5 Features of AED Trainer ..........................5 Description of the AED Trainer ........................7 Top and Right Panel Components ......................7 Rear Panel Components ........................... 7 Action Icon ..............................9 Remote Control ............................11 Battery Operation ............................ - Page 4 Figure 1. HeartOn T16: Top and Right Panel Components ..............7 Figure 2. HeartOn T16: Rear Panel Components ................7 Figure 3. HeartOn T16 Action Icon (Left: Chest type, Right: Icon type) ..........9 Figure 4. AED Trainer Remote Control ....................11 Figure 5.
-
Page 5: Configuration Of Aed Trainer
The AED trainer is pre-configured with 10 standard scenarios that simulate realistic sudden cardiac arrest episodes and 3 custom scenarios which can be changed by user. ⚫ The Semi-Automatic or Fully-Automatic can be switched by pressing the MEDIANA OPTION button on the remote control. ⚫... - Page 6 This page is intentionally left blank.
-
Page 7: Description Of The Aed Trainer
Description of the AED Trainer Top and Right Panel Components <Chest Type> <Icon Type> Figure 1. HeartOn T16: Top and Right Panel Components Rear Panel Components <With a Battery> <Without a Battery> Figure 2. HeartOn T16: Rear Panel Components... -
Page 8: Table 1. Hearton T16 Panel Components
Table 1. HeartOn T16 Panel Components Select language User can select the desired language among three different button languages by pushing the select language button. Pad connector Pad connector links the pads. Cover is used to protect the action icon, the patient mode switch... -
Page 9: Action Icon
Action Icon Figure 3. HeartOn T16 Action Icon (Left: Chest type, Right: Icon type) Table 2. HeartOn T16 Voice Prompt Action icon Voice prompt If the pad is not inserted, you will hear the voice prompt: • “Plug in pads. Insert connector firmly.”... - Page 10 Action icon Voice prompt Fully-Automatic: • “Shock will be delivered.” • “Do not touch the patient.” • “Three, Two, One.” • “Shock delivered.” or “Shock cancelled.” When the electric shock is delivered, you will hear the voice prompts: (1) CPR Feedback option is disabled: •...
-
Page 11: Remote Control
Remote Control Figure 4. AED Trainer Remote Control... -
Page 12: Table 3. Aed Trainer Remote Control
Non-shockable rhythm scenario play button Poor pad condition recovery button Shock cancellation condition button Poor pad condition button Not used in HeartOn T16 Battery condition change button Error condition button Resumption button Freeze button MEDIANA OPTION button for Semi-Automatic and Fully- Automatic switching. -
Page 13: Battery Operation
Battery Operation Note: The AED trainer and battery charge pack should be combined to operate the AED trainer. Charging the Battery To charge the internal rechargeable battery of the AED trainer, follow the procedures below. 1. Connect the DC adapter to the DC port. 2. -
Page 14: Battery Status Indication
Battery Status Indication The battery status icon in the status indicator indicates the battery condition. Refer to Table 4. Table 4. The AED Trainer Battery Status Icon Battery Status Icons Indication Battery Status Battery status icon Fully charged with DC flashes adapter connected In use (Not fully... - Page 15 Resume the audible activity from the point at which it was paused. Pause all audible activity in the AED trainer. Control the electric shock. The Semi-Automatic or Fully-Automatic can be switched by pressing the MEDIANA OPTION button on the remote control.
-
Page 16: Standard Scenario
Standard Scenario The standard scenario is configured with 10 scenarios based on basic scenario; Shockable Rhythm and Non-Shockable Rhythm and can be selected by using the remote control. Refer to Table 5 and Table 6 for more information about each scenario. Table 5. -
Page 17: Table 6. Standard Scenario
Table 6. Standard Scenario Standard Scenario Description A. Shockable Rhythm Scenario x 1 B. Non-Shockable Rhythm Scenario x 1 A. Shockable Rhythm Scenario x 3 B. Non-Shockable Rhythm Scenario x 1 *Poor pad condition A. Shockable Rhythm Scenario x 1 B. -
Page 18: Custom Scenario
Preparation for changing the custom scenario The following items are required to change the custom scenario. 1. Micro SD card 2. AED trainer software (custom scenario program: for HeartOn T16) 3. PC including as below specifications or more: • Windows XP(SP3) •... -
Page 19: Figure 6. Hearton T16 Update File Builder Window
Changing the custom scenario 1. Open the AED trainer software, “HeartOn T16 Update File Builder.exe”, to change the custom scenario. Figure 6. HeartOn T16 Update File Builder Window... -
Page 20: Figure 7. Custom Scenario Setting Window 1
2. Click the Custom Scenario Tab and set the Custom Scenario value. Figure 7. Custom Scenario Setting Window 1... -
Page 21: Figure 8. Custom Scenario Setting Window 2
Figure 8. Custom Scenario Setting Window 2 4. Confirm the “T16 Custom Scenario Update.MUF” file is created in the path where the “HeartOn T16 Update File Builder.exe” file is located. Figure 9. “T16 Custom Scenario Update.MUF” file... -
Page 22: Figure 10. Connecting The Micro Sd Card
AED trainer. If all procedures are conducted properly, the AED trainer will automatically perform the update. Figure 11. HeartOn T16 Action Icon (Left: Chest type, Right: Icon type) ⓑ~ⓔ twice in one second interval to inform Note: The AED trainer flashes the action icon the user update is ongoing. -
Page 23: Figure 12. Custom Scenario Buttons
7. When the update is completed, turn on the AED trainer and then confirm the setting of the custom scenario by pressing the Play Button on the remote control. Figure 12. Custom Scenario Buttons... -
Page 24: Cpr Feedback Module
CPR Feedback Module CPR Feedback Module helps the user can perform CPR effectively when the CPR Feedback Module is connected to the AED trainer. In case of using the CPR Feedback Module, follow the steps below to conduct CPR. 1. Refer to Figure 13, connect the pads connector to the CPR Feedback Module. Figure 13. - Page 25 In case of CPR with the CPR Feedback Module, depending on the pressing speed and strength you will hear the complex voice prompts: • “Press slower and softer.” CPR feedback: compression rate is too fast and compression depth is too deep. Do chest compression in accordance with the beep sound and decrease the strength.
-
Page 26: Maintenance
Do not clean the AED trainer with abrasive materials, cleaners or solvents. Specification Characteristic ⚫ Name: AED (Automatic External Defibrillator) Trainer ⚫ Model: HeartOn T16-D, HeartOn T16-G ⚫ Power 1) DC 10.8V / 3400mAh, 3cell Li-ion rechargeable Battery 2) DC 15V / 1500mA, DC adapter ⚫... -
Page 27: List Of Components
List of Components Standard Accessories HeartOn T16 (including internal battery) Remote Control Training pads cable (excluding the CPR Feedback) Training Pads (can be used about 100 times) Operator’s Manual DC Adapter Optional Accessories Micro SD card AED Trainer Software CPR Feedback Module...
