Pavone Systems DAT 700 Series Installation Manual page 4

... read more
Analog Voltage Output
Resolution
Calibration
Impedances
Linearity
Temperature drift
Current Analog Output
Resolution
Calibration
Impedances
Linearity
Temperature drift
Microcontroller
Data memory
Compliance with Regulations
The following are the symbols used in the manual to call the reader's attention:
Warning! This operation must be performed by trained personnel.
Pay special attention to the following directions.
Further information.
•
The procedures below, must be carried out by trained personnel.
•
All connections should be made with the instrument turned off.
The following information covers all the functions included in the OPTIMATION tools,
present on the various models.
Page 4
TECHNICAL FEATURES
Voltage: ± 10 V / ± 5 V
16 bits
Digital from buttons
minimum 10KW
0.03% of full scale
0.002% of full scale / °C
Current: 0 ÷ 20 mA / 4 ÷ 20 mA
16 bits
Digital from buttons
maximum 300W
0.03% of full scale
0.002% of full scale / °C
32-bit ARM Cortex M0+, 256KB Flash reprogrammable on-board
by USB.
32 Kbytes + optional Aliby memory (1MByte)
EN61000-6-2, EN61000-6-3 for EMC
EN61010-1 for Electrical Safety
SYMBOLOGY
INSTRUMENT NAMEPLATE
It is important to communicate this data in case of inquiries or indications
regarding the instrument combined with the program number and version that
are on the cover of the manual and are displayed when the instrument is
turned on.
WARNINGS
DAT700: Installation of the instrument
