Groovy
Installation and maintenance / Instalación y mantenimiento
Before connecting the faucet to the water supply , flush the tubing
thoroughly to eliminate any residue /
Antes de conectar la grifería a la distribución de agua, purgue muy bien la cañería
a fin de eliminar partículas extrañas.
Roman tub faucet / Juego hidromasaje
FV210/F4 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the Groovy FV210/F4 and is the answer not in the manual?

Questions and answers

Related Manuals for FRANZ VIEGENER Groovy FV210/F4

Summary of Contents for FRANZ VIEGENER Groovy FV210/F4

  • Page 1 Groovy Installation and maintenance / Instalación y mantenimiento Before connecting the faucet to the water supply , flush the tubing thoroughly to eliminate any residue / Antes de conectar la grifería a la distribución de agua, purgue muy bien la cañería a fin de eliminar partículas extrañas.
  • Page 2 Before you start / Antes de comenzar Required installation tools / Herramientas necesarias para la instalación Provided / Provistas Not Provided / No Provistas Phillips screwdriver Destornillador Phillips Allen Wrench Llave Allen Adjustable wrench Adjustable inglesa Sealant tape Cinta de teflón...

  • Page 3: Installation/ Instalación

    Groovy Roman tub faucets Installation/ Instalación FV210/F4 Roman tub faucet Torque recommendation. Maximum aplicable torque 22 Nm Torque recommendation. Maximum aplicable torque Maximum 20 Nm aplicable torque 22 Nm 1 5/16" 1 3/8" 3/4" 3/4" 3/4"...
  • Page 4 Groovy Roman tub faucets Installation/ Instalación 90º...

  • Page 5: Handle Installation

    Groovy Roman tub faucets Installation/ Instalación Handle installation: OPTIONAL...
  • Page 6 Installation/ Instalación Handle installation/ Instalación del volante F4 - Groovy handle off position J3 - Edge handle (example)
  • Page 7 Installation/ Instalación Handle installation/ Instalación del volante...
  • Page 8 Edge Roman tub Faucets Installation/ Instalación Not included...
  • Page 9 Edge Roman tub Faucets Installation/ Instalación FV133/F4.0 (Optional / not included) Hand shower, diverter valve & complete handle 1 /2" min 9/16" max. 9/16" max. 5/8" 3/4"...
  • Page 10 Edge Roman tub Faucets Installation/ Instalación OPTIONAL...
  • Page 11 Edge Roman tub Faucets Installation/ Instalación J3 - Edge handle (example)
  • Page 12 Edge Roman tub Faucets Installation/ Instalación...
  • Page 13 Edge Roman tub Faucets Installation/ Instalación...
  • Page 14 Edge Roman tub Faucets Installation/ Instalación Not included...
  • Page 15 Notes...
  • Page 16 WARRANTY: For more information please visit https://franzviegener.com/warranty/ FO-FV210/F4 / July 2023...
