Nerea
Installation and maintenance / Instalación y mantenimiento
Before connecting the faucet to the water supply, flush the tubing
thoroughly to eliminate any residue /
Antes de conectar la grifería a la distribución de agua, purgue muy bien la cañería
a fin de eliminar partículas extrañas.
FV182/59-59P-59K-59D-59R-59V
Single handle lavatory set with soft touch drain/Monocomando de cocina con sopapa soft touch
FV181.01/59-59P-59K-59D-59R-59V
Short vessel height, single handle lavatory set, knurled cylinder handle with push down drain assembly (no lift rod) /
Monocomando para lavatorios vessel bajos, con volante cilíndrico moleteado y desagüe “push down”
FV181.02/59-59P-59K-59D-59R-59V
Large vessel height, single handle lavatory set, knurled cylinder handle,with push-down pop-up drain assembly (no lift rod)/
Monocomando para lavatorios vessel altos, con volante cilíndrico moleteado y desagüe “push down”.
Advertisement
Related Manuals for FRANZ VIEGENER Nerea
Summary of Contents for FRANZ VIEGENER Nerea
- Page 1 Nerea Installation and maintenance / Instalación y mantenimiento Before connecting the faucet to the water supply, flush the tubing thoroughly to eliminate any residue / Antes de conectar la grifería a la distribución de agua, purgue muy bien la cañería a fin de eliminar partículas extrañas.
- Page 2 Before you start / Antes de comenzar Required installation tools / Herramientas necesarias para la instalación Provided / Provistas Not Provided / No Provistas Aerator Tool Phillips screwdriver Aireador Destornillador Phillips Allen Wrench Channelock Llave Allen Llave pico de loro Sealant Tape Teflón...
- Page 3 Exploded view / Vista explotada FV182/59P FV182/59K FV182/59D FV182/59 FV181.01/59P FV181.01/59K FV181.01/59D FV181.01/59 FV181.02/59P FV181.02/59K FV181.02/59D FV181.02/59 FV182/59V FV182/59R FV181.01/59V FV181.01/59R FV181.02/59V FV181.02/59R Soft touch drain Sopapa soft touch (Use only with Aaerator Usar solo en: Aireador FV181.01/59 Aaerator tool FV181.01/59P Aireador FV181.01/59K...
- Page 4 Measures / Medidas FV181.02/59 FV181.02/59D FV181.02/59P FV181.02/59R FV181.02/59K FV181.02/59V 6" (152,4mm) FV181.01/59 FV181.01/59D FV181.01/59P FV181.01/59R FV181.01/59K FV181.01/59V 6" (152,4mm) FV182/59 FV182/59D FV182/59P FV182/59R FV182/59K FV182/59V 4 1/2" (114,3mm) 1 5/16" 1 5/16" 1 5/16" 2" 2" (34,33mm) (33,34mm) (33,34mm) (50,8mm) (50,8mm) 2"...
- Page 5 Installation / Instalación Flow rate / Caudal Flow Table Tabla de caudal R 70 Temperature Rate Flow Rate Caudal Temperatura Cold Caliente Fria 40 50 90 100 Pressure (PSI) Presión...
- Page 6 Installation / Instalación Single handle installation / Instalación de monocomando...
- Page 7 Installation / Instalación Flexible connector installation / Instalación de flexible NOT INCLUDED NO INCLUÍDO...
- Page 8 Installation / Instalación Drain installation / Instalación de sopapa FV182/59-59P-59K-59R-59D-59V...
- Page 9 Installation / Instalación OPEN CLOSED POSITION POSITION Cerrado Abierto Subjection-Set. Cojunto de sujecion...
- Page 10 Installation / Instalación Drain installation / Instalación de sopapa FV181.01/59-59P-59K-59R-59D-59V / FV181.02/59-59P-59K-59R-59D-59V...
- Page 11 Installation / Instalación Finished installation / Instalación finalizada...
- Page 12 4000 Porett Drive - Gurnee, IL, 60031-USA. about this line. www.franzviegener.com Follow us on social media! FRANZ VIEGENER reserve the right to make revisions without notice in the design of faucets and bathroom accessories or in packaging. FOLLFV182/59 / July, 2023.
