Firehawk FHB10 Manual

6. Screw the pattress to ceiling using the fixings provided. You may also
use two half-moon shaped and double sided fixing pads available from
Fireblitz.
7. Alternatively, you may use any proprietary builders fixing adhesive
normally used to fix skirting boards and other light building
components to walls etc.
NOTE: Be sparing with any adhesives used on the back of the radio
pattress to avoid excess adhesive squeezing through holes onto the
circuit board. When using adhesive pads or adhesives make sure
the surfaces are flake free, clean, dry and flat. Take care to use all
appropriate Health and Safety precautions when fixing the pattress
and alarm to their surface - in particular use appropriate access
equipment, protect yourself from dust and wear eye protection.
Do not change any components of the system for those made by other
manufacturers. Up to 15 alarms may be paired to the system.
WARNING: The electronic test button provides a full test of the
alarms functionality. Do not try to test the alarm using either heat
smoke or naked flame as damage will occur.
6. TESTING THE SYSTEM
Test the full system using the test button of the alarms and or Control Unit
for the Hearing Impaired System if fitted.
Press the test button on each alarm and wait for the other alarms to sound
before testing all other alarms in the same way. The alarm should sound
three times with a flashing red light then stop. Allow at least 5 seconds after
a successful test before testing the next one. After testing check that the
green light flashes approximately every minute. Test the alarm once a week
to ensure correct operation.
The Radio Interlinked System is now ready for use.
Do not change any components of the system for those made by other
manufacturers. Up to 15 alarms may be paired to the system.
WARNING: The electronic test button provides a full test of the
alarms functionality. Do not try to test the alarm using either heat
smoke or naked flame as damage will occur.
7. USER INFORMATION
Protect your Home Against Fire
Contact your local Fire Service for a home safety check, this information is
free and will identify potential fire hazards in and around your home. Make
sure all occupants of the home know what a fire alarm sounds like. Prove
and practise a fire escape plan and arrange a suitable and safe assembly
point.
What to Do if the Alarms Sound
Alarms sounds are as follows:
Full alarm indicating Repeating series of 3 beeps every
smoke and fire 4 seconds with flashing light
\ Low Battery Single beep every minute
Test button jammed One beep every 11 seconds
Fault Double beep every minute
Ensure everyone leaves the building as soon as possible.
Do not run.
• Do not stop to collect belongs.
• If it is safe to do so, close all windows and doors as you escape to prevent
the spread of fire.
• Smoke is the main cause of death from fire. If trapped inside the building,
cover your mouth, conserve breath and crawl to safety.
Do not silence a fire alarm until you know the cause of the alarm
and when all occupants are safely outside the building.
Silencing an alarm
Do not silence a smoke alarm until you are certain there is no fire. The fire
alarm that has detected a fire will be flashing its red light in the centre of
the test button once every second, all other alarms in the system will just
be sounding.
To silence the fire alarm system, press the test button on any alarm in that
system. If one alarm continues to sound, it will be the one that has detected
a fire. Check for a fire in its area and for its flashing red light. ONLY if you
are certain there is no fire, press its test button to silence it. If you are not
certain, evacuate the property and call your fire and rescue service on 999.
A regular program of fire alarm maintenance will help to keep your alarm in
good working order.
• Test the alarm monthly making sure that all interconnected alarms in the
system sound within 10 seconds.
• Vacuum the alarms every six months and wipe them with a damp cloth.
• Do not paint the alarm.
A smoke alarm is a sensitive life-saving device. The life of this alarm can
be significantly reduced by adverse environments, incorrect location and
a failure to regularly clean and maintain it according to the instructions.
Incorrect location and a lack of reasonable care may also cause it to
malfunction and will invalidate the warranty.
The batteries in the FHB10-RF are intended to last 10 years – they are
non-replaceable. At the end of its life the alarm will beep once every
minute for a minimum of one month. The life of the battery can be
significantly shortened by periods of storage or use in temperatures below
5°C or above 30°C. It will also be shortened by frequent or extended
periods in full alarm often caused by conditions such as cigarette smoke,
steam, aerosol spray and condensation. In these circumstances the
warranty will be void. If this happens at night you can press the test button
to silence the battery warning for 10 hours. Replace the alarm as soon as
possible.
Problems are indicated in five ways;
1. The alarm beeps twice every minute indicating a malfunction.
2. The alarm beeps once every minute indicating a low battery.
3. The full alarm sounds for no reason. (A repeating series of three beeps
with flashing light)
4. The alarm does not sound when pressing the test button.
5. The test button light remains steadily on or off. (i.e. does not flash
approximately once every minute, when the unit is not in alarm)
Inspect for obvious damage. Check that the alarm has been installed
in accordance with the instructions. In the case of repeated nuisance
alarms, check that it is free from dust, cobwebs and external
contamination from such things as cigarette smoke, drying paint, spray
from household aerosols and steam that will ultimately shorten the life
of the alarm and invalidate the warranty.
If this does not correct the problem, do NOT attempt to repair. There are no
user serviceable parts internally. If the smoke alarm is within the warranty
period and terms, indicate the nature of the problem and return the unit
with proof of purchase to the address at the end of this manual. Units
beyond warranty cannot be economically repaired..
••• ••• ••• •••
Fireblitz guarantees to you, as a purchaser, that the enclosed fire alarm will
be free from defects in material, workmanship or design under normal use
• • • •
and service for a period of 7 years. This Guarantee are not assignable. Our
• • • • liability to you, under this guarantee is limited to repairing or replacing any
part which we find to be defective in material, workmanship or design, free
•• •• •• ••
of charge to the customer, upon sending the alarm with proof of date of
purchase, postage paid to Fireblitz Extinguisher Ltd, Units 15/17 Manford
Industrial Estate, Manor Road, Erith, Kent DAB 2AJ. The terms of this
guarantee will not apply in the following circumstances:
• If the alarm has been modified, dismantled, contaminated, damaged,
neglected or otherwise abused or altered following the date of purchase,
• If it fails to operate due to incorrect siting, installation or maintenance
• Damage caused by failure to abide by the instructions supplied.
It is specifically drawn to the users attention that substantial periods in
alarm will shorten alarm life, during which time the fire alarm will have
provided valuable protection; no Claim under the guarantee will be
entertained. The liability of Fireblitz Ltd, arising from the sale of this alarm
or under the terms of this guarantee shall not in any case exceed the cost
of replacement of the alarm. In no case, shall Fireblitz Ltd be liable for
consequential loss or damage resulting from the failure of the alarm or the
breach of this or any other guarantee, express or implied or for damage
caused by failure to abide by the instructions supplied.
This guarantee does not affect your statutory rights.
8. ALARM MAINTENANCE
9. TROUBLE SHOOTING
10. PRODUCT WARRANTY
Fireblitz Extinguisher Ltd.
Units 15-17 Manford Industrial Estate,
Manor Road. Erith, Kent DA8 2AJ
Telephone: 01322 342238
TECHNICAL HELPLINE 0800 008 6568
Text on 07885 831239
Email: customerservices@fireblitz.co.uk
Fireblitz Extinguisher Ltd
FHB10
BS EN 14604:2005
KM 623822
23
2797 CPR 706070
23
0086 CPR 746977
Smoke Alarm
7
YEAR
Warranty
FHB10-RF
LONG-LIFE ALARM BS EN 14604:2005 2797 CPR 706070
KM 623822
BATTERY SILENCE
READ AND RETAIN THIS USER MANUAL
MANUAL
0086 CPR 746977
