- Page 1 AQRO 2200LE Commercial Reverse Osmosis System Dual TDS Meter 2 ® Installation, Operation, 7785 E. US Hwy. 36 and Service Manual Avon, IN 46123 (317) 272-3000 • (800) 447-5582 © 2007 New Aqua LLC...
- Page 2 Maintenance Manual Osmosis System Introduction The AQRO 2200LE reverse osmosis system is designed to provide high quality water from well and municipal sources for use in applications requiring large volumes of product water. This manual is designed primarily for use by the water treatment pro- fessional and / or equipment installer who is already familiar with RO sys- tem installation and sound plumbing practices.
-
Page 3: Application Guidelines
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Application Guidelines The performance of the AQRO is in direct proportion to the characteris- tics of the feed water. When sizing and installing a reverse osmosis system it is important to test and record the pressure, temperature, and the TDS of the feed water as these are factors that will affect the production of the sys- tem. -
Page 4: Operating Specifications
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Operating Parameters (con't) Operating Specifications Membrane Type Typical Rejection > 96% 40 - 100° F Feed Temperature 110 - 120 psi System Pressure Production (gal/day)* up to 2200 * Rated membrane production is based on industry standards of 60 psi., 77° F, and 500 ppm TDS feed water. -
Page 5: Installation Procedure
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Installation Procedure Front View 1/2" Product water connection (Beind small flowmeter at top) 3/4" Drain water connection (Beind large flowmeter at top) Dual TDS Meter 2 3/4" Feed water connection (Inlet of pre filter) Use a ball valve or a gate valve on this... - Page 6 Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Installation Procedure (con't) Top View Product Drain 3/4" Concentrate connection 1/2" Permeate connection (Beind large flowmeter at top) (Beind small flowmeter at top) To Drain To Storage Tank 3/4" Feed water connection (Inlet of pre filter) Use a ball valve or a gate valve on this...
-
Page 7: Feedwater Connection
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Installation Procedure (con't) Inspect the area that the AQRO system will be installed. Note where the feed and drain connections will be, also where the storage tank(s) will set. Then place the AQRO in a suitable place that is easily accesible for service. Note that drinking water applications require the addition of a post filter after the storage tank sized to the requirements of the product service flow. - Page 8 Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Installation Procedure (con't) Product Water Connection Connect 1/2" tubing to the permeate connection on the AQRO system and run to the storage tank. Position the fitting entering the storage tank on top of the tank in a location that will prevent the flow from falling directly on top of the float.
-
Page 9: Start-Up Procedure
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Start Up Procedure Check that all piping connections have been made. Slowly open the feedwater valve and allow the pre filter and tubig to pres- surize. When fully pressurized, open the feed water valve fully. Plug the electrical cord in to a 115 volt outlet (or the float connection). -
Page 10: Maintenance
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Maintenance Regular maintenance is essential to the performance and longevity of the AQRO system. The maintenance consists of changing the pre filter, changing the post filter if equiped with a cartridge type, and sanitizing the system. Con- tact your dealer for information in detemining the frequency of maintenance. - Page 11 Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Maintenance (Con't) Postfilter Replacement (if equipped) If the AQRO is installed with a post filter, contact the dealer for the proce- dures and intervals to maintain the post filter. ® ©...
-
Page 12: Parts Diagram
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Parts Diagram Dual TDS Meter 2 ® © 2007 New Aqua LLC • 7785 E US Hwy 36 • Avon, In. 46123... -
Page 13: Parts List
Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Parts List Ref No. Part No Item Description 04303075 Aluminum RO Frame 22470050 Inlet Solenoid 3/4" NC 115v. 01120001 3/4" #20 Filter Housing 01220113 5 Micron Filter 20" 23001150 Low Pressure Switch 21241200 1/2 HP Centrifugal Pump/Motor 08080087... - Page 14 Commercial Reverse Installation, Operation, and AQRO Maintenance Manual Osmosis System Notes: ® © 2007 New Aqua LLC • 7785 E US Hwy 36 • Avon, In. 46123...
-
Page 15: Warranty
This warranty becomes effective on the installation date of the covered system. Should a malfunction occur, contact Aqua Systems or an authorized dealer. War- ranty Returns must be accompanied by a copy of the original sales order showing the dealers name and the purchasers name and address.
