Installation, Operation and Maintenance Manual
TFC Reverse Osmosis Drinking Water System
IMPORTANT NOTICES:
This reverse osmosis system contains replaceable treatment components critical for effective performance.
It is the user's responsibility to, and the manufacturer strongly recommends that the user, periodically
test the product water to verify the system is performing satisfactorily. See the test kit(s) for sampling
instructions.
This system is acceptable for treatment of influent concentrations of no more than 27 mg/L nitrate and 3
mg/L nitrite in combination measured as N and is certified for nitrate/nitrite reduction only for water supplies
with a pressure of 280 kPa (40 psig) or greater.
This system conforms to NSF/ANSI Standard 58 for pentavalent arsenic reduction. See the Performance
Data Sheet Arsenic Facts section for an explanation of reduction performance.
DO NOT uSE wITh wATER ThAT IS MICRObIOlOgICAlly uNSAfE OR Of uNkNOwN quAlITy,
wIThOuT ADEquATE DISINfECTION bEfORE OR AfTER ThE SySTEM.
Systems certified for cyst reduction may be used on disinfected water that may contain filterable cysts.
AQPC-435
Tested and Certified by NSF International against
NSF/ANSI Standard 58 for the reduction of the claims
specified on the Performance Data Sheet.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aqua Systems PureChoice AQPC-435
Summary of Contents for Aqua Systems PureChoice AQPC-435
- Page 1 Installation, Operation and Maintenance Manual AQPC-435 TFC Reverse Osmosis Drinking Water System Tested and Certified by NSF International against NSF/ANSI Standard 58 for the reduction of the claims specified on the Performance Data Sheet. IMPORTANT NOTICES: This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility to, and the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing satisfactorily.
-
Page 2: Table Of Contents
TAblE Of CONTENTS Page SECTION I. INTRODuCTION ...................3 SECTION II. SPECIfICATIONS ................5 SECTION III. PREPARATION ..................6 A. Major System Components .............6 B. Tools Recommended for Installation ..........6 C. Site Selection For Major System Components .......6 SECTION IV. INSTAllATION STEPS ................7 A. -
Page 3: Introduction
SECTION I. INTRODuCTION environment by the water are measured as Total Your new Reverse Osmosis (R.O.) Drinking Water Dissolved Solids (TDS). In the Reverse Osmosis System uses a combination of filtration technologies process, dissolved minerals are separated from to reduce unwanted contaminants in a water supply. the incoming water (Feed Water) to produce The following steps combine to give you the best in the product water (the Permeate). - Page 4 OPTIONAl AqPC-435 bASEMENT INSTAllATION DIAgRAM Close-up of Manifold Dispensing Faucet See Page 10 nOte: FOr reFrigeratOr water Dispenser Or ice maKer hOOKup, tee intO 3/8" Blue tuBing tO prODuct Dispensing Faucet. (3/8” Blue) hOlDing tanK shutOFF ValVe (Open position) FlOOr tanK (3/8”...
-
Page 5: Specifications
SECTION II. SPECIfICATIONS TAblE A – quAlIfIED SySTEM PERfORMANCE Because the performance of an R.O. Membrane is highly dependent upon pressure, temperature and TDS, the following should be used for comparison purposes only. u.S. Metric Membrane Production 41-53 gpd 155–201 lpd Membrane TDS Reduction 96% minimum 96% minimum... -
Page 6: Preparation
SECTION III. PREPARATION 12. Teflon tape. 13. Wide masking tape or duct tape. A. Major System Components 14. Plastic tubing cutter. The following components comprise the R.O. 15. Extra plastic tubing. Drinking Water System. (Refer to Fig. 1 for general system layout.) 16. Low range air pressure gauge. •... -
Page 7: Installation Steps
3. R.O. Manifold Assembly–The manifold can 2a. Drilling a stainless steel sink: be installed on either the right or left side •Center punch the hole to provide a starting of the under–sink area or a cabinet. The point for the drill. right side is recommended because all the •Start with a smaller drill as a pilot, and then tubing will be to the back of the cabinet and drill a ½"... - Page 8 HOSE BARBS 3/8” QUICK CONNECT FITTING BLACK 1/4” POLYTUBE BLACK 3/8” POLYTUBE (TO DRAIN PORT (TO DRAIN CLAMP) ON RO SYSTEM) BLUE 3/8” POLYTUBE (PRODUCT OUTLET) 5. Connect the tubing to the Faucet. Push 3. Assemble the 1/8” Screws & Toggle Wings the Blue 3/8”...
-
Page 9: Feed Water Saddle Valve Installation
2b. To install on (hard) Steel or Brass Tubing fEED wATER SADDlE VAlVE supply line. •The supply line should now be drained. Use Cold Water Line a battery powered or properly grounded drill Saddle to avoid shock hazard. Reversible Back Plate •Drill a "... -
Page 10: Manifold Assembly Installation
2. Use a battery powered or properly grounded drill. Using the Clamp port as a drill guide, drill a " hole through the wall of the drain pipe. Do NOT penetrate the opposite side of the pipe. 3. Locate the "... -
Page 11: Position The Drinking Water Holding Tank And Make The Final Hose Connections
Firmly press in the tubing. The fittings will •Remove the plugs labeled “ACTIVATED CARBON” and “MEMBRANE” from the grab the tubing and hold and seal it in place. Make sure the tubing is pressed all the way underside of the manifold. To each of the in to create a pressure tight connection. -
Page 12: Operation And Maintenance
When the Faucet is first opened, expect air The recommended interval for changing the and carbon fines (very fine black powder) filters (not the R.O. Membrane) is every from the In–Line Activated Carbon Post 6 to 12 months. Typical T.F.C. Membrane life Filter to be rinsed out. -
Page 13: Changing The In-Line Activated Carbon Post Filter
IN–lINE ACTIVATED CARbON •Remove the Activated Carbon Prefilter POST fIlTER ASSEMbly Housing and empty. Remove the wrapping and install the Activated Carbon Prefilter. Dispensing Firmly tighten the Housing hand tight only. Faucet •Disconnect the yellow product water tubing that runs from the Holding Tank to the 3/8"... -
Page 14: Trouble Shooting Guide
SECTION VI. TROublE ShOOTINg guIDE Problem Possible Cause Solution Low quantity of Product Water Feed Water Saddle Valve is plugged or Open Valve or unclog. from Holding Tank closed. Clogged Sediment Prefilter or Activated Replace filters. Carbon Prefilter. Low water pressure Feed Water pressure must be above 40 psig. - Page 15 Problem Possible Cause Solution High Total Dissolved Solids (TDS) in The Product Water and Drain Water Correct plumbing. the Product Water (continued) lines are reversed. No drain flow, Drain Restrictor is Clear or replace Drain Restrictor. clogged. No drain flow, the drain orifice in Clear or replace Dispensing Faucet. the Dispensing Faucet is plugged.
-
Page 16: Exploded View And Parts List
EXPlODED VIEw & PARTS lIST 21..Nitrate/Nitrite Test Kit MADE IN USA... - Page 17 DRAwINg NO. PART NO. DESCRIPTION 1 ....S2009 ........ Self Tapping Screw 2 ....S2005 ........ ASO Cap 3 ....S2013 ........ ASO Cap O–Ring 4 ....S2011 ........ ASO Diaphragm – Large 5 ....S2007 ........ ASO Piston 6 ....S2006 ........ ASO Piston Ring 7 ....
- Page 18 NOTES:...
- Page 19 NOTES:...
- Page 20 7785 East US Highway 36 Form No. S1466-AS1 4/8/2009 Avon, Indiana 46123 U.S.A.
