  • Page 1 HEAT PUMP for swimming pool water Installation and user manual heating & cooling HP1700 GREEN INVERTER P & Version: 01/2023 – Smart Life HP 2100 GREEN INVERTER P & HP2700 GREEN INVERTER P COMPACT & SPLIT...

  • Page 2: Table Of Contents

    P a g e 2 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Thank you for purchasing Microwell swimming pool heat pump. Before you use this device, it is necessary to carefully read the entire Installation and user manual.
  • Page 3 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 3 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Failure solution and code ......................

  • Page 4: Introduction

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 4 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 1.

  • Page 5: Package Checking

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 5 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Package checking...

  • Page 6: Electrical Safety

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 6 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 operations contradictory to this Installation and user manual may lead to an injury or property...
  • Page 7 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 7 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 packaging.

  • Page 8: Handling Precautions

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 8 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Vacuumize completely before welding.

  • Page 9: Transportation

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 9 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 working in perfect order.

  • Page 10: Technical Specification

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 1 0 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 3.

  • Page 11: Swimming Pool Water Parameters

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 1 1 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Operating condition and range:...

  • Page 12: Heat Pump Dimensions

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 1 2 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Heat pump dimensions...

  • Page 13: Installation Reminder

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 1 3 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Installation reminder...

  • Page 14: Accessories

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 1 4 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Accessories...
  • Page 15 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 1 5 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Electric wiring Diagram...
  • Page 16 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 1 6 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Note: The above data is adapted to power cord ≤...
  • Page 17 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 1 7 / 4 4 V e r s i o n : 0 1 / 2 0 2 3...
  • Page 18 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 1 8 / 4 4 V e r s i o n : 0 1 / 2 0 2 3...
  • Page 19 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 1 9 / 4 4 V e r s i o n : 0 1 / 2 0 2 3...
  • Page 20 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 2 0 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Water pump control and timer connection...

  • Page 21: Connection To Pv

    This section is for all users or applications where photovoltaic panels are installed and used as energy source. Your Microwell heat pump is equipped with PV Ready solution enabling you to minimize your energy bill by powering your heat pump from photovoltaic energy source. You have several options how to operate your heat pump: 1.Maximum comfort –...
  • Page 22 If the power keeps on being low, then the heat pump will be turned off. It is save to operate your Microwell heat pump in this way. Please note that even in the case PV panels generate enough power, your heat pump may be off and not working.

  • Page 23: Regulation

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 2 3 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 4.

  • Page 24: Operation Instruction

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 2 4 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Operation Instruction...
  • Page 25 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 2 5 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 e.
  • Page 26 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 2 6 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Parameter Table...

  • Page 27: Testing

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 2 7 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Running status checking table...
  • Page 28 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 2 8 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 center.

  • Page 29: Wifi Operation

    V e r s i o n : 0 1 / 2 0 2 3 5. WIFI OPERATION By downloading and using this application You accept that Microwell, spol. s.r.o. is a third- party application broker and is not responsible for any technical conditions of its use.
  • Page 30 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 3 0 / 4 4 V e r s i o n : 0 1 / 2 0 2 3...
  • Page 31 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 3 1 / 4 4 V e r s i o n : 0 1 / 2 0 2 3...

  • Page 32: Trouble Shooting For Common Faults

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 3 2 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 6.
  • Page 33 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 3 3 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Protection &...

  • Page 34: Maintanance & Warranty

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 3 4 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Cooling plate overheat protection...

  • Page 35: Split - Connection And Installation

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 3 5 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 8.

  • Page 36: Refrigerant Circuit Connection

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n V e r s i o n : 0 1 / 2 0 2 3 P a g e 3 6 / 4 4 Refrigerant circuit connection...

  • Page 37: Flaring Work

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 3 7 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Outside diameter...
  • Page 38 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 3 8 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Warranty does not cover any product, property or personal damages or...
  • Page 39 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 3 9 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Air purging with vacuum pump...

  • Page 40: Water Unit Dimensions

    I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 4 0 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Water unit dimensions...

  • Page 41: Warranty

    H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 4 1 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Warranty...
  • Page 42 I n s t a l l a t i o n a n d u s e r m a n u a l H P 1 7 0 0 / H P 2 1 0 0 / 2 7 0 0 G r e e n P a g e 4 2 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Notes:...
  • Page 43 H P 1 7 0 0 / 2 1 0 0 / 2 7 0 0 G r e e n I n s t a l l a t i o n a n d u s e r m a n u a l P a g e 4 3 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Notes:...
  • Page 44 P a g e 4 4 / 4 4 V e r s i o n : 0 1 / 2 0 2 3 Distributed by: Manufacturer: MICROWELL, spol. s r.o. SNP 2018/42, 927 01 Sala, Slovakia tel.: +421/31/702 0540 fax: +421/31/702 0542 e-mail: microwell@microwell.sk...
