SENTINEL H23 SWING GATE
Mechanical Installation Instructions
(0717)

Advertisement

loading
Need help?

Need help?

Do you have a question about the SENTINEL H23 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rotech SENTINEL H23

  • Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment T: +61 7 3205 1123 www.rotech.com.au e: info@rotech.com.au SENTINEL H23 SWING GATE Mechanical Installation Instructions (0717)
  • Page 2 RECOMMENDATIONS REGARDING THE INSTALLATION AND MAINTENANCE BOOKLET THIS BOOKLET IS INTENDED SOLELY FOR PROFESSIONALLY QUALIFIED INSTALLERS THIS INSTALLATION AND MAINTENANCE BOOKLET IS AN INTEGRAL PART OF THE PRODUCT AND MUST BE GIVEN TO THE USER. KEEP THIS INSTALLATION AND MAINTENANCE BOOKLET TOGETHER WITH ALL THE INFORMATIVE MATERIAL SYMBOLS USED IN THE BOOKLET Referred to information that must be read for your own safety and that of others and to avoid damage to property.
  • Page 3 STANDARD SYSTEM BH23 RANGE 1) Automatism BH23 5) Antenna 2) Control unit 6) External photocell 7) Internal photocell 3) Key selector 8) Stop for open position 4) Flashing light...
  • Page 4 INSTRUCTIONS BRUSHLESS MOTOR FOR SWING GATES SERIES BH23 INSTRUCTIONS FOR POSITIONING AND MOUNTING THE PRELIMINARY CHECKS PRIOR TO INSTALLATION BRACKETS FIG.1 AND 2 Check that the gate has the necessary requirements to be automated Take the measurements A and B for mounting the main bracket (part 1- The gate structure must be solid and suitable 1) and mark on the gatepost, also in relation to the maximum required 2- The hinges must be in good condition and well greased...
  • Page 5 INSTALLATION OF THE ACTUATOR Proceed with mounting the actuator as shown in fig. 3 Caution: the actuator may be installed on the right or the left in the position shown in fig.3. Position the actuator inside of the main bracket (1) insert the 2 bolts (2) and secure. Assemble and install the articulated arms as shown in fig.4. FIG.
  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS FIG. 1 4x2.5 GATE STOPS FOR OPEN AND CLOSE POSITIONS SERIES BH23 FIG. 2 LEFT MOTOR GATE OPEN GATE CLOSED...
  • Page 7 DECLARATION OF CONFORMITY The undersigned, representing the following manufacturer Roger Technology Via Botticelli 8 31021 Bonisiolo di Mogliano V.to (TV) DECLARES that the equipment described below: Description: Swing gates automation Model: H23 Is in conformity with the legislative provisions that transpose the following directives: •Directive 89/336/EEC (EMC Directive) and subsequent amendments •Directive 73/23/EEC (Low Voltage Directive) and subsequent amendments And has been designed and manufactured to all the following standards or technical...
