- Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment t: +61 07 3205 1123 www.rotech.com.au e: info@rotech.com.au Sentinel BOB50 Linear Swing Gate Operator v03/23 Installation Instructions Please read these instructions fully before installing...
-
Page 2: Overall Dimensions
Overall dimensions... - Page 3 Fig. 1a Fig. 1b 90° 110° M = +20mm / K = -10mm Max Opening Opening time Max wing dimensions max. (kg) 25” 38” 4,5* * It is advisable to use an electric lock 34” 4,5* 30”...
- Page 4 or bolt on Weld mounting brackets Grease Level. or bolt on Weld mounting brackets...
- Page 5 Position 2 (PG11) Position 1 (PG13,5)
- Page 6 Encoder ENCODER signal ENCODER positive ENCODER negative Black wire Red wire...
-
Page 7: Wire Diagram
Wire diagram Legenda: Motoreducer BOB5024 Photo-electric cells FTC/FTM Key selector CH/TO.KEY (external) or digital keyboard Flash-light LAMPI24 Electronic board BRAIN24. The power cables must be kept separated from the auxiliary cables. For cable length lower than 5m, use a cable 2x2.5sqmm. For cable length from 5 to 10 m use a cable 2x4sqmm. -
Page 8: Ec Declaration Of Conformity
EC Declaration of Conformity Manufacturer: Automatismi Benincà SpA. Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Herewith declares that: the operator for hinged gates model BOB5024 / BOB5024E. is complying with provisions set forth by the following other EC Directive: - DIRECTIVE 2004/108/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 15 December 2004, on the harmonisation of the laws of Member States relating to electromagnetic compatibility and which cancels Directive 89/336/EEC, according to the... - Page 9 Introduction Connections 1) The special plate P (Fig. 4) allows for using a link for herein. sheath or cable gland PG11, or PG13,5. Once the type of cable gland is applied to the plate, fix the item for applications different from those indicated latter to the adaptor cover by means of screws V.
- Page 10 BOB5024 User’s handbook for the user ITALIANO Norme di sicurezza Safety rules bambini giochino con i comandi o in prossimità delle ante. tecnico specializzato. but call a qualified technician. Manual and emergency operation In the event of power failure or fault, to manually open and close nte procedere come segue: o di protezione del meccanismo di sblocco (fig.
- Page 11 n° Description Cod. Plastic cover 9686630 BOB5024 / BOB5024E Release lever 9686631 Unblock. group 9686632 Blister 9686633 Motor 9686643 Upper cover 9686635 Gear 9686636 Worm screw 9686637 Lock with pin 9686638 Lower cover 9686639 Limit stop 9686640 (Only BOB 524) Locks 9686641 Wormscrew supp.
