- Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment t: +61 07 3205 1123 www.rotech.com.au e: info@rotech.com.au Sentinel MB24 Articulated Arm Swing Gate Operator v02/23 Installation Instructions Please read these instructions fully before installing...
- Page 2 Technical data MBE24 MB24V Power supply 230 Vac Motor feed 24 Vdc 24 Vdc Power drawn 160 W 160 W Current drawn 0,76 A 6,2A Torque 180 Nm 180 Nm Noise level <70 dB <70 dB Operating time at 90° 10 s (1) 10 s (1) Door leaf max.
- Page 3 Articulated bracket Bracket Fig.2...
- Page 4 Fixing bracket Screw M8x65 UNI 5737 Self locking nut M8 UNI 7473 Fig.3 Fig.4...
- Page 5 Customized key C Lever L Fig.5...
- Page 6 Cover MBE24V SWC2 (17) SWO2 (16) COM (13) M2 (3,4) Cover Cables MB24V Fig.6...
- Page 7 Lower cam Upper cam Microswitch Open. Open. Lower cam Upper cam Close. Close. Upper cam Lower cam Inside. MB24 MBE24 Open. Open. Left Right Fig.7...
- Page 8 Legend: 1 Ratio-motor MBE24V 2 Ratio-motor MB24V 3 Photo-electric cells FTC/FTM 4 Key selector CH 5 Mechanical stop 6 Blinker LAMP 7 Aerial AW 8 Articulated arm with brackets BA...
-
Page 9: General Notes
Warning • Before installation, carefully read the instructions hereunder. • It is strictly forbidden to use the item MB24V/MBE24V for applications other than the intended uses de- scribed in these instructions. • Instruct the user on how to use the system. Introduction Thank you for choosing our MB24V/MBE24V ratiomotor. - Page 10 7. Positioning the articulated arm BA (Fig.4) - Release the gear motor (see paragraph “Emergency manual operation”) - Insert pin P in the hole of the motor shaft A - Join arm B1 to arm B2 and lock them by means of pin T1 and lock ring S1 - Fix the arms to the motor shaft A and lock them by means of nut D by inserting washer R and ring N - Hook the arm to bracket SN and lock it by means of pin T1 and release ring S1.
- Page 11 Description Pos. Code. 9686930 Cover Motor 9686811 Screw 9686326 Limit stop 9686934 9686935 Microswitches Shaft 9686936 Output shaft 9686937 9686812 Transformer Control unit 9686927 Gasket 9686944 9686941 Release lever Cover 9686942 9686943 Cover...
-
Page 12: Maintenance
User’s handbook MB24V MBE24V Customized key C Lever L Safety rules • Do not stand in the movement area of the door. • Do not let children play with controls and near the door. • Should operating faults occur, do not attempt to repair the fault but call a qualified technician. Manual and emergency operation To manually open or close the door in case of power failure or faults, two solutions are possible: •... -
Page 13: Ce Declaration Of Conformity
CE Declaration of Conformity Declaration in accordance with Directives 2004/108/CE(EMC); 2006/95/CE(LVD); 2006/42/CE(MD) Annex II, part B The Manufacturer: AUTOMATISMI BENINCÀ SPA Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italy Declares that the product: Electromechanical actuator 24V DC for swing gates, model: MB24V - MBE24V conforms with the requirements of the following EU Directives: •...
