Rotech Sentinel B17 Installation Instructions Manual

Sliding gate operator
Hide thumbs

Advertisement

Quick Links

Download this manual
Vehicle Access Control
Pedestrian Access Control
Safety & Security Equipment
T: +61 7 3205 1123
www.rotech.com.au
e: info@rotech.com.au
Sentinel B17 Sliding Gate Operator
Installation Instructions
(V03/22)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sentinel B17 and is the answer not in the manual?

Questions and answers

Related Manuals for Rotech Sentinel B17

Summary of Contents for Rotech Sentinel B17

  • Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment T: +61 7 3205 1123 www.rotech.com.au e: info@rotech.com.au Sentinel B17 Sliding Gate Operator Installation Instructions (V03/22)
  • Page 2 BULL.PI (Optional)
  • Page 3 MIN =120 mm MAX = 140 mm MIN = 10 mm MAX = 20 mm...
  • Page 4 ≈1 mm K Max 35 mm 3 mm 74 mm BULL 17 OMI.S 35 mm 63 mm (optional MLS)
  • Page 6 15AT 250Vac BRAKE RESISTOR 24 Vdc 0.5A SERVICE LIGHT PHOTO TEST (fig.15) OPEN/CLOSE CON1 /BAR OPEN II°Ch. Radio Safety BAR JP1 BAR JP1 BAR Open Close BAR N.C. BAR 8K2...
  • Page 7 PHOTOTEST OPEN PHOTOTEST CLOSE TST1:ON TST2:ON OPEN MAX 16A 250Vac LOGIC MINV MINV:On SCA 24Vac OPEN AUX: 0 MINV:Off OPEN SERVICE LIGHT Aux: 1 MAX 16A MAX 16A 250Vac 250Vac OPEN SCA 24Vac Service Light AUX: 0 230V BAR LOGIC=ON OPEN Aux: 1 MAX 16A...
  • Page 8 Display OFF Power ON Firmware Ver. (3s) v1. 0 0 8888 Diagnostic tped tsmo IBCA tsmc fsto fstc sldo ltca sldc pho1 pho2 tst1 seav tst2 sear minv Horm tacc tdec nMan spin...
  • Page 9 Nman 0012 3456 MACI 2 Cycle AUTO PUSH OPEN/CLOSE RE-ENTER CODE 0000 9000 9C5a conf CODE YAK 25 BISON 35 BULL 15OMI 230Vac BULL 15OMAI 115Vac _ _ _ _ _ _ Display OFF Legenda Premere simultaneamente (+) e (-) / Press simultaneously keys (+) and (-) Premere il tasto (-) / Press key (-) / Die Taste (-) drücken Gleichzeitig (+) und (-) drücken / Presser simultanément (+) et (-) Appuyez sur la touche (-) / Presionar la tecla (-) / Wcisnąć...

  • Page 10: Quick Programming

    INDEX 1) GENERAL FEATURES .................21 10.2) HOW TO CHECK CONNECTIONS ............. 23 2)GENERAL INFORMATION ................21 11) PROGRAMMING ..................23 3) TECHNICAL DATA ..................21 12) TO ACCESS PROGRAMMING ..............23 4) INSTALLATION OF THE FOUNDATION PLATE ..........21 12.1) RUN SELF-LEARNING AND ANTI-CRUSHING DEVICE SETTING ..23 5) RACK FIXING .....................22 13) PARAMETERS, LOGIC AND SPECIAL FUNCTIONS ........24 6) LIMIT STOP FLASK POSITIONING (SEE FIG.10) ...........22...

  • Page 11: Wire Diagram

    2 Installation with adjustment in height on the already existing base in concrete (Fig.3). By using the plate as drilling template, drill 4 holes, and insert the Ø 10mm steel screw anchors for threaded bars. Tighten the 4 threaded bars, M10/120mm, and anchor the screw anchors by tightening the nuts “B” to floor with the corresponding washers. With reference to Fig.
  • Page 12 Common Common for limit switch. Closing Limit Switch CLOSING limit switch input (N.C. contact) Opening Limit Switch OPENING limit switch input (N.C. contact) Sensing edge contact input Resistive safety edge (8K2): JP1 "BAR" closed Mechanical safety edge (N.C.): JP1 "BAR" open Sensing safety edge The intervention of the safety edge stops the movement of the gate and reverses for approximately 3s.
  • Page 13 13) PARAMETERS, LOGIC AND SPECIAL FUNCTIONS The tables below describe the individual functions available in the control unit. PARAMETERS (PAR) MENU FUNCTION MIN-MAX-(Default) MEMO Automatic closure time. It is activated only with “TCA” logics :ON 1-240-(40s) At the end of the preset time, the control unit starts a new closing operation. The passage left open by the door/gate leaf during the partial opening controlled by the Tped pedestrian inoput, is adjusted.
  • Page 14 LOGIC (LOG) MENU FUNCTION ON-OFF-(Default) MEMO Enables or disables automatic closing On: automatic closing enabled (ON) Off: automatic closing disabled Enables or disables multi-flat function. On: multi-flat function enabled. The step-by-step and perdestrian commands have no effect (OFF) during the opening phase. Off: multi-flat function disabled.
  • Page 15 NUMBER OF CYCLES (Nman) The number of cycles (open+close) completed by the system is displayed. When the push-button <PG> is pressed once, the first 4 digits are displayed, if the push-button is pressed once more, the last 4 digits are displayed. E.g.
  • Page 16 Before meeting the SWX (SWO) stop limit switch, braking preset by TSM time will start. Braking leads the gate/door from standard speed (FSTSO/FSTSC) to braking speed, adjusted by SLDS parameter. The TDEC time sets how rapidly the gate/door should reach the braking speed. The TDEC time is theoretical by reason of the fact that as soon as the speed reaches the value preset by SLDS, braking at constant speed starts until reaching the SWC (SWO) limit switch.
  • Page 17 16) ERROR MESSAGES Some messages that are displayed in the event of malfunctions are shown hereunder: Error N.O inputs (autoset) If the error occurs during self-learning, check the PP/PED/OPEN/CLOSE inputs. STOP error (autoset) STOP intervention during the autoset. Err1 Error, photocells (Autotest) PHOTO/PHOTC intervention during the autoset.

  • Page 18: Maintenance

    19) MAINTENANCE The following table is used to record maintenance operations, improvement or repair works carried out by the expert engineer. Stamp Date _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Engineer's Signature _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Description of operation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 19 BULL User’s handbook Safety measures • Do not stand within the gate movement area. • Children must not play with controls and near the gate. • In the event of malfunctions, do not attempt to repair the failure but contact the specialised personnel. Manual and emergency manoeuvre In the event of power failure or malfunction, to manually operate the gate proceed as follows: •...
  • Page 20 BULL 17 OMI BULL 17 OMAI Ref. Note 230 V Code 115 V Code 9688344 9688349 9688348 9688348 9688319 9688319 9686337 9686337 9686694 9686694 9686032 9686032 9686335 9686335 9688317 9688317 9688270 9688270 9688102 9688102 BULL_S 9686329 9686329 9688335 9688335 9688336 9688336 9688318 9688318...
  • Page 21 Dichiarazione di Conformità UE (DoC) UE Declaration of Conformity (DoC) Manufacturer's name: Automatismi Benincà SpA Nome del produttore: Automatismi Benincà SpA Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Indirizzo: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Telephone: +39 0444 751030 Email address: sales@beninca.it Telefono: +39 0444 751030 Indirizzo e-mail: sales@beninca.it Person authorised to draft the technical documentation:...
  • Page 22 Declaración CE de conformidad (DoC) Deklaracja zgodności CE (DoC) Nombre del productor: Automatismi Benincà SpA Nazwa producenta: Automatismi Benincà SpA Dirección: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Adres: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Teléfono: +39 0444 751030 Dirección de correo electrónico: sales@beninca.it Telefon: +39 0444 751030 Adres e-mail: sales@beninca.it Persona autorizada a producir la documentación técnica:...
  • Page 24 AUTOMATISMI BENINCÀ SpA - Via Capitello, 45 - 36066 Sandrigo (VI) - Tel. 0444 751030 r.a. - Fax 0444 759728...

This manual is also suitable for:

Bull 17 omiBull 17 omai
