Connecting Cables to M/Connect
Bridge Cable
1
Plug the bridge cable from the hub into the corresponding port
on the underdesk dock, ensuring that the plug is fully inserted
into the housing. ①
Upstream Cable
1
Plug one end of the upstream cable into the
corresponding port on the underdesk dock, ensuring
that the plug is fully inserted into the housing. ②
2
Bring the rest of the cable up to the work surface
and insert into the cable retainer by firmly pressing
down. ③
NOTE: To move the cable retainer to the opposite
side, follow the steps for "Replacing the M/Connect
Hub (pg. 13)" to remove the hub, then the cable
retainer can be taken out and switched to the other
side ④
③
②
④
①
