- Page 1 MANUALE DI USO E INSTALLAZIONE USE MANUAL AND INSTALLATION Pompa di calore Heat Pump ATHENA A-07 A-07S A-11 A-11S A-13 A-13S A-15 A-15S MANUALE INSTALLAZIONE DBIS...
-
Page 2: Table Of Contents
ENGLISH CONTENTS Part I: General Information ............................1.1 Caution ................................1.2 Specification ............................... 1.3 Dimensions ................................. Part II Installation................................2.1 Transportation ..............................2.2 Installation site requirement ..........................2.3 Minimum distance to wall ..........................2.4 Installation guide ..............................2.5 Recommended hydraulic connection ......................... 2.6 Electrical Connection ............................ -
Page 3: Part I: General Information
Part I: General Information 1.1 Caution 1. Ensure proper operation on the unit, 2. The unit must be installed and repaired by qualified technician. 3. A leakage protection switch must be installed near the unit. 4. Do not use any damaged cables and switches to avoid any leakage. 5. - Page 4 1.2.1 Specification of Athena Pompa di calore DC Inverter aria-acqua trivalente A-07 A-11 A-13 A-15 Codice Potenza Nom. (min-max) 5.0 (2.0~5.6) 8.2 (3.2~9.0) 10.0 (4.2~11.2) 13.0 (5.3~14.3) Raffreddamento Puissance frigorifique Ass. elettrico Nom. (min-max) 1.78 (0.75~2.3) 2.87 (1.31~3.57) 3.57 (1.72~4.79) 4.56 (2.15~6.08) Cooling capacity Nominale...
- Page 5 1.2.2 Specification of Athena Pompa di calore DC Inverter aria-acqua trivalente A-07S A-11S A-13S A-15S Codice Set Potenza Nom. (min-max) 5.0 (2.0~5.6) 8.2 (3.2~9.0) 10.0 (4.2~11.2) 13.0 (5.3~14.3) Raffreddamento Puissance frigorifique Ass. elettrico Nom. (min-max) 1.78 (0.75~2.3) 2.87 (1.31~3.57) 3.57 (1.72~4.79) 4.56 (2.15~6.08) Cooling capacity Nominale...
-
Page 6: Dimensions
1.3 Dimensions A-13/A-13S A-11/A-11S A-07/A-07S... -
Page 7: Part Ii Installation
A-15/A-15S Part II Installation 2.1 Transportation Along transportation , don’t incline the unit more than 45 in any direction The unit in its packaging can be transported with a lift truck or hand truck. -
Page 8: Installation Site Requirement
2.2 Installation site requirement This unit is designed for outdoor installation, do not install it in an close space. Please consider the condition as following factors when selecting installation site. The installation site should be large enough and well ventilation. The installation site should be convenient for water drainage. - Page 9 Unità Interna 2.4 Routing the refrigerant lines The outdoor unit is pre-filled with refrigerant R410A. No additional filling is required for lines up to 5 m in length. Minimum line length : 3 m Maximum line length :12 m Max. height differential Indoor to outdoor unit : 10m Line lengths between 5 and 12 m must be topped up with an additional 60 g/m refrigerant R410A.
- Page 10 Indoor unit higher than outdoor unit...
- Page 11 2.5 Connecting and filling the refrigerant lines 1. Connect the copper pipe to indoor unit. 2. Wipe the quick connectors with clean cloth to prohibit dust and impurity entering the pipes. Align the centre of the pipe and fully screw in the angular nuts with finger.
- Page 12 3. Connect other side of copper pipe to outdoor unit. 4. A vacuum pump and manifold gauge are needed. Connect the pressure gauge to the vacuum pump. Use vacuum pump to remove the air from indoor unit and copper pipe.
- Page 13 5. When vacuuming the indoor unit and copper pipe, please do not turn on gas / liquid valve, otherwise refrigerant leakage. Vacuum the unit for at least 15 minutes till negative value shown on the pressure gauge, and close the manifold gauge. 6.
-
Page 14: Installation Guide
operation, charge additional R410a refrigerant with specified amount to the unit through the service connector on liquid valve. Be sure to charge the specified amount of refrigerant in liquid state to the liquid pipe. Since R410a is a mixed refrigerant, adding it in gas form may cause the refrigerant composition to change, preventing normal operation. - Page 15 Condensate drainage connector shockproof rubber pads 2.7.2 Design of the store tank in the system 1 - kW is the unit for cooling capacity, L is the unit for (G) minimum water flow volume in the formula. Comfortable type air conditioner G= cooling capacity×2.6L Process type cooling G= cooling capacity×7.4L...
- Page 16 When ambient temperature lower 5 running cooling mode must be charged antifreeze. Refer to upper parameters for the charged volume. Fouling factors The performance data given refer to conditions with clean evaporator plates (fouling factor=1). For different fouling factors, multiply the figures in the performance tables by the coefficient given in the following table.
- Page 17 anti-freezing protection when environment temperature > 2°C. 5) When failure in environment temperature sensor, if compressor stops for 30 minutes, then use coil temperature sensor to instead. 6) When failure in inlet water temperature sensor, then use outlet water temperature sensor to instead.
-
Page 19: Recommended Hydraulic Connection
2.8 Recommended hydraulic connection... - Page 20 2.8 Recommended hydraulic connection...
-
Page 21: Electrical Connection
2.9 Electrical Connection 1. Ensure proper operation on the unit to ensure security, the unit must be installed and repaired by qualified technician. 2. A leakage protection switch must be installed near the unit. 3. Do not use any damaged cable and switch. 4. -
Page 22: Trial Operation
2.10 Trial Operation The unit should only be operated by qualified technician. Please drain air inside hydraulic system before operation. The unit is designed according to the conditions as follows: the range of ambient temperature is -25 and the range of water pressure is 0.15 0.8Mpa. 2.10.1 Preparation The following items should be checked before startup: a. -
Page 23: Part Iii Control System
2.10.3 Caution When following happen during trial operation, please stop the unit immediately and cut off the power and contact with our authorized agent or maintenance technician. Fuse blown or protection activated frequently The wire and switches are heated abnormally Abnormal sounds coming from the unit Abnormal smell comes out of the unit. -
Page 24: Controller Introduction
3.2 Controller introduction Cooling Water pump Heating E-heater Lock the keys Defrosting Clock Compressor Timer on Timer off 3.3 Operation introduction Standby status - 5 -... - Page 25 Heating status Cooling status DHW status Heating+DHW status...
- Page 26 3.31 Description of control button On/Off button 1. When the screen is locked, press button for 5 seconds to unlock the screen; 2. In unlock status, press button for 1 second to switch on/off; 3. In other setting status, press button to back to main menu.
- Page 27 Table 1 Item Description Unit Range Remark -30 105 00 DHW tank temp 0 99 01 Frequency of compressor 02 Current of compressor 0 105 0 105 03 DC bus voltage 04 Temp of IPM module -30 105 0 105 05 AC voltage 0 105 06 AC current...
- Page 28 -30 140 23 Exhaust temp 24 Outdoor coil temp -30 105 -30 105 25 Outdoor environment temp -30 105 26 Buffer tank temp -30 105 27 Temp of after throttling -30 105 28 Inlet water temp -30 105 29 Outlet water temp -30 105 30 Air return temp 31 Multiple units working...
- Page 29 target return 0-10 overheat of main valve curve A in heating mode target return overheat of main valve 0-10 curve A in cooling mode Regulating cycle of main 20-150 valve Target air return overheat -10-20 of auxiliary valve Reserved 00-16 Reserved Reserved 20-90...
- Page 30 Timer on / off setting (can set only when unit is off) 1. In main menu, press button to enter timer 1 setting. 2. In timer 1 setting, press button again, hour of timer on flashes, press set the hour of timer on. 3.
-
Page 31: Part Iv Maintenance
Capacity test mode In ON status, press button simultaneously for 15 seconds to enter capacity test. And will exit when unit is off. Restore factory settings Press button simultaneously for 5 seconds to restore factory settings. Connector of three way valve control There is connector of three way valve control on the PCB. -
Page 32: Part V Trouble Shooting
power off and cover it with protective cover, Check it roundly before you start it again. 6. It is advised to use the phosphoric acid whose temperature is about 50 consistency is 15% to clean the heat exchanger of the unit. First start the circulation pump to clean it for 3 hours, and then flush it with tap water for three times. - Page 33 Outdoor DC fan Driving of DC fan is failure failure Inlet water temp The cable of the sensor Reconnect the cable of the sensor sensor failure open Retighten the probe Outlet temp or shout circuit Repair or replace the cable sensor failure The probe of the sensor fall Replace PCB...
- Page 34 failure DHW water tank sensor failure Main board EE Data error failure Driver board EE Data error failure current protection outdoor unit Current protection of compressor AC voltage too high / too low protection outdoor unit DC bus voltage too high / too low protection overheat protection...
- Page 35 according rated label. refrigerant leakage Replace the low pressure switch Electronic expansion valve Clean the evaporator is damaged Low pressure switch is Replace fan motor damaged Replace electronic expansion valve Fan motor is damaged Replace PCB PCB is damaged The evaporator are dirty Overheat Cooling coil temp is too high Check if the outdoor fan is dirty and...
- Page 36 Fault Condition Possible Causes Treatment Power fault Turn off the switch, check the Power source Bad connection to the power The unit doesn’t work Find the causes and renovate them Fuse blow Replace the fuse Lack water In the system Check the water make-up device and pump fill in with water...
- Page 37 Contactor destroyed Replace the Contactor Refrigerant leakage Leak hunting and fill in standard quantity Compressor works but not of refrigerant Compressor fault heating Replace the compressor Hydraulic switch destroyed Replace the switch Low water-flow protection Inadequate water-flow Clean the filter and discharge the air Too much refrigerant Draw off the superfluous refrigerant Excessive...
-
Page 38: Part Vi Wiring Diagram
Part VI Wiring Diagram A- - 11... - Page 39 A- - 13 A A -1 1 5...
-
Page 45: Disposal
Disposal Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging you health and well-being. - Page 46 ATHENA (A-15) ATHENA (A-13) ATHENA (A-11) ATHEN (A-15) ATHENA (A-13) ATHENA (A-11)
- Page 47 ATHENA (A-15) ATHENA (A-13) ATHENA (A-11) ATHENA (A-15) ATHENA (A-13) ATHENA (A-11)
