S I N G L E G A S M O N I T O R
INSTRUCTION MANUAL
Read and understand instructions before use.
For use with Oxygen (O2), Carbon Monoxide (CO),
Hydrogen Sulfide (H2S), Hydrogen Cyanide (HCN)
⚠
WARNING: To prevent ignition of flammable or
⚠
WARNING: To reduce the risk of ignition of a
⚠
AVERTISSEMENT: Pour réduire le risque d'allumage
2812
Ex ia IIC T4 (-20°C ≤ T
IP65
ATEX Cert. No.: TRAC 09 ATEX 11195X
EMC Directive (2004/108/EC)
EN 61000-4-2:1995, EN 61000-4-3:2002, EN 55011:2007
MET
®
C
US
LISTING NO: E112902
combustible atmospheres, disconnect
power before servicing.
flammable atmosphere, batteries must
only be changed in an area known to
be nonflammable.
d'une atmosphere inflammable, des
batteries doivent seulement étre
changées dans un secteur connu pour
étre inflammables.
II 1 G
to ≤ 50°C)
amb
complies with
UL 913
Class 1, Groups A, B, C & D
CSA 22.2 NO. 157
Exia, Temp code: T4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SENSIT Technologies P100
Summary of Contents for SENSIT Technologies P100
- Page 1 S I N G L E G A S M O N I T O R INSTRUCTION MANUAL Read and understand instructions before use. For use with Oxygen (O2), Carbon Monoxide (CO), Hydrogen Sulfide (H2S), Hydrogen Cyanide (HCN) ⚠ WARNING: To prevent ignition of flammable or combustible atmospheres, disconnect power before servicing.
-
Page 2: Safety Information
SAFETY INFORMATION ⚠ IMPORTANT: Read and understand this manual prior to use. ⚠ IMPORTANT: Oxygen instruments will show high readings for up to 30 minutes if taken from warm air to cold temperatures and vice-versa. For best results let them “soak”... -
Page 3: General Description
Balloon T Assembly for Bump Test, SCAL100-D, SCAL100-N, Calibration Kits, Regulators, Download Kit GENERAL DESCRIPTION The SENSIT P100 is an exceptionally rugged personal gas monitor. ® is available in single gas configurations only. Preset alarms P100 provide visual, audible and vibration alerts for low and high alarm conditions. -
Page 4: Physical Specifications
Durable belt clip PRODUCT FEATURES is constructed of durable ABS plastic. The top SENSIT P100 ® housing is additionally protected with a shock absorbing material to protect the instrument from the rigors of field use. The front of the instrument has an opening for the sensor and... - Page 5 Two buttons operate the instrument. The left button is for power while the right is for zeroing and performing calibration. Multiple LED’s beneath the frosted area create a very bright warning even in bright sunlight. The instrument is mounted using a sturdy suspender clip on the back of the instrument.
-
Page 6: Function Indicators
RESOLUTION RANGE 0.1% 1ppm 0-999* 1ppm 0-100 0.1ppm 0-30 0.1ppm 0-20 *Extended Range available up to 2000ppm. ALARMS has two basic styles of alarm. Low Alarms SENSIT P100 ® activate at two second intervals while High Alarms activate at one... - Page 7 Turn the instrument on and wait for the working display to illuminate. Apply an approved concentration of gas to the sensor area using the P100 calibration adapter. The flow should be 200-400 cc/min. The alarm should occur in less than 20 seconds.
-
Page 8: Adjust Date/Time
(The P100 will force the user to update the time if it is invalid during startup.) P100 will show “Pin”. Press and release either button to show “900”. Press right button to increase the number to 925. Number will roll- over to 900 when it exceeds 998. -
Page 9: Alarm Adjustment
12. P100 shows “Hr” until either button is pressed and released 13. P100 shows the current hour in the 24-Hour format (no AM/ PM selection) 14. The number can be increased by pressing the right button and will roll-over to 00 if it exceeds 23. Adjust to desired “Hr”... - Page 10 The flow should be 200-400 cc/min. 2. Push and hold the Zero button until the display reads “GAS”. 3. Attach the P100 calibration adapter. 4. Start the gas flow. 5. Push and release the Zero button. A changing number will...
- Page 11 CAL icon on the display. Press the power button to acknowl- edge. (Retry calibration). If the acknowledgement has not been performed, the P100 will return to the working display after 30 seconds. 8. Successful calibration will be logged as an Alarm event in the log.
-
Page 12: Operation And Use
OPERATION AND USE Press the ON button to start the instrument in an area known to be gas free and with normal oxygen content. The following will display as a normal start up sequence: 1. Activate all segments and icons 2. - Page 13 A manual zeroing should only be done in an atmosphere known to be gas free and containing normal oxygen levels. Press the ZERO button for 2-3 seconds and release. All segments of the display will flash followed by the working display. Exposure to gas in excess of sensors range specifications will result in “OL”...
- Page 14 Sensit Technologies LLC has met its national obligations to the EU WEEE Directive. Sensit Technologies LLC has also elected to join WEEE Compliance Schemes in some countries to help manage customer returns at end-of-life.
-
Page 15: Warranty And Repair Policy
WARRANTY AND REPAIR POLICY Your is warranted to be free from defects in materials SENSIT P100 ® and workmanship for a period of 2 years after purchase (excluding calibration). If within the warranty period, your instrument should become inoperative from such defects, the unit will be repaired or replaced at our option.
