ASUS RT-AC66u Router Setup
Guide – UFB
Bigpipe Setup Guide for ASUS
RT-AC66u Router (UFB)
UFB internet connection setup
You'll need this stuff, which should be packaged with the
router:
Figure 1. The router's backside
Figure 2. LAN cable (also called Ethernet cable)
Advertisement
Related Manuals for Asus RT-AC66u
Summary of Contents for Asus RT-AC66u
- Page 1 ASUS RT-AC66u Router Setup Guide – UFB Bigpipe Setup Guide for ASUS RT-AC66u Router (UFB) UFB internet connection setup You’ll need this stuff, which should be packaged with the router: Figure 1. The router’s backside Figure 2. LAN cable (also called Ethernet cable)
- Page 2 Figure 3. The underside of the ONT (Chorus will install this) Please follow these instructions to set up your ASUS RT- A66u Router for Bigpipe’s UFB plan. – Attach the router’s aerials, plug it in, and power it on. Plug one end of an Ethernet cable (see figure 2) into the blue port (see figure 1) and the other end into the first port (GE1) of the ONT (see figure 3).
- Page 3 ASUS WiFi network. You should not need to give a password. -Please open a web browser e.g Chrome, Firefox or Safari. Once you have, please type 192.168.1.1 into the address bar and click enter. -Please click on Skip Setup Wizard –...
- Page 4 –Important: If you’re connected by wireless, you will now need to connect to the new wireless / WiFi network that you created to continue. Use the username and password you just created. Once you have done so, click Next. -From the left menu click on WAN...
- Page 5 -Please change the settings to match the ones below -Under Account Setting, set both your User Name and Password to Bigpipe -Leave the rest of the settings at their defaults and click Apply...
- Page 6 Great, you should now be able to connect to the internet! If you can not then please restart your router. If that still doesn’t work, check that you’ve followed this guide correctly, and if you’re still having trouble after that, please feel free to contact our online support team.
