OPERATING INSTRUCTIONS
AND E-WARRANTY APPLICATION
Please Read Instructions Before Using Hot/Cold Water Dispenser
W28
THE WATERSTATION
GIVING US
$
EXTRA TIME
EXCESS SPACE
MORE SAVINGS
QUALITY WATER
WITH LOVED ONES
IN THE KITCHEN
THE SMART WAY
TO REJOICE WITH
INSTANTLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W28 and is the answer not in the manual?

Questions and answers

Related Manuals for Novita W28

Summary of Contents for Novita W28

  • Page 1 OPERATING INSTRUCTIONS AND E-WARRANTY APPLICATION Please Read Instructions Before Using Hot/Cold Water Dispenser THE WATERSTATION GIVING US EXTRA TIME EXCESS SPACE MORE SAVINGS QUALITY WATER WITH LOVED ONES IN THE KITCHEN THE SMART WAY TO REJOICE WITH INSTANTLY...

  • Page 2: Table Of Contents

    LIMITED WARRANTY TERMS & CONDITIONS LIMITED WARRANTY EXTENSION RETURN & REFUND POLICY This product includes: • novita Hot & Cold Water Dispenser W18 • Operating Instructions & e-Warranty Application (e-Copy) • Starter Guide • 12 Months HydroNano Filter Pack • 1 x Water Diverter •...

  • Page 3: Product Description

    PRODUCT DESCRIPTION EXTERIOR FRONT VIEW BACK VIEW INTERIOR INTERNAL VIEW Touch Panel Side Panel Ambience Light Dispensing Nozzle Front Panel/Filter Cover Removable Drip Tray Top Cover Back Panel Heating Switch Water Inlet Port Power Cord & Plug Filter 1: Sediment & Nano Carbon Filter Filter 2: Carbon Fibre &...

  • Page 4: Control Panel & Lcd Display Description

    CONTROL PANEL & LCD DISPLAY DESCRIPTION Hot Water Button Cold Water Button Volume Selection Button UV-C/Setting Button Reboil Button Water Dispensing/Room Temperature Water Button Water Volume Indicator Time/Setting Indicator Ambience Light Sensor HYDRONANO™ ULTRA FILTRATION SYSTEM HYDRONANO ™ 5-STAGE ULTRA FILTRATION SYSTEM FILTER 2 FILTER 1 STAGE 1 SEDIMENT FILTER...

  • Page 5: Installation

    It also does not cover/provide/include non-standard parts like water tap, washer, splitter and copper pipe that may be required. • For more information on novita installation and service maintenance packages, please email us at custcare1@novita.com.sg, UNIT INSTALLATION & SETTING UP 01.
  • Page 6 03. Depress and hold the water inlet port latch to remove the stopper plug. Connect water inlet hose into water inlet port and ensure they are fitted snugly to prevent water leakage. Water Inlet Port Stopper 1/4” Water Plug Inlet Hose 04.

  • Page 7: Using The Hot/Cold Water Dispenser

    06. To fill the cold water tank, press cold water button followed by dispense button until water dispenses from the nozzle. Rinse the brand-new filters by dispensing 3 litres of cold water. Rinsing helps to commission the filtration system to increase the surface area in contact with the water and to remove any trapped air bubbles. This helps to optimize and enhance the filtration efficiency.
  • Page 8 REBOILING 01. Press the reboil button to heat up the water to the desired reboiling temperature. 02. Press the reboil button again to deactivate the reboil function. • During the heating process, the heating element may generate slight noise and this is normal. •...
  • Page 9 SETTINGS During the settings adjustment, user may press button or leave the unit idle for 10 seconds to exit the settings. 01. TIME a. Press and hold the UV-C/setting button for 5 seconds, unit produces a buzzer and all indicators illuminate on the control panel.
  • Page 10 05. UV-C LED STERILIZATION a. Press and hold the UV-C/setting button for 5 seconds, unit produces a buzzer, and all indicators illuminate on the control panel. b. Press the UV-C/setting button five times consecutively to enter the UV-C LED sterilization setting. c.

  • Page 11: 12 Months/3,600 Litres Filter Replacement

    12 MONTHS/3,600 LITRES FILTER REPLACEMENT For optimum performance, it is recommended to replace the filters once every 12 months/3,600 litres of water, whichever comes first. The dispense button illuminates in red when the filter lifespan is left with 14 days/140 litres as reminder to standby a new set of filters for replacement.
  • Page 12 INSTALLING NEW FILTERS 01. Take out the new filters from the filter box. New Filter 02. Please take note of the filter 1 and 2 installation sequence. Align the arrow on the filter label to the centre of the filter connector head. 01 01 Centre Of The Filter Connector...

  • Page 13: Cleaning & Maintenance

    05. Reattach the front panel and drip tray onto the unit. 06. Turn on the water piping diverter. It is recommended to rinse through the brand-new filter before usage. Dispense and discard 3 litres of hot and cold water respectively. 3L Hot 3L Cold Water...

  • Page 14: Safety Precautions

    DO NOT handle the unit or the DO NOT use a damaged power the power cord to prevent safety power cord with wet hands. cord or plug. Contact novita hazards or damage to the unit. Customer Care Centre for replacement.

  • Page 15: Safety Instructions

    Always remember to MAINTAIN & REPLACE the filter in accordance to its stipulated maintenance or exhaustion date. Ensure that the filter & all parts of the novita hot/cold water dispenser are not cracked or damaged at all time. When damaged, the water purification process is compromised and the water might hence be unfit for consumption.

  • Page 16: Troubleshooting

    Power plug not connected properly or loose. • Ensure that power plug is connected snugly. • Power plug or cord is damaged. • Contact novita customer care centre. • Power cutoff. • Check power source & contact a qualified electrician if power cutoff is caused by abnormal electrical pressure or overloaded circuit.

  • Page 17: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions (W x D x H) 185 x 418 x 394 mm Net Weight 11.5 Kg Water Pressure Range 0.1 – 0.4 MPa Rated Power Consumption 580 Watts Heating Power Consumption 500 Watts Cooling Power Consumption 80Watts UV-C LED Power Consumption 0.8 Watts Voltage/Frequency 220 –...

  • Page 18: Novita Customer Service Guarantee

    S$40 two-ways, customer can choose to use our delivery service instead of bringing in the product themselves. Optional Loan Set* Knowing how inconvenient it can get when your product is sent for servicing or repair, novita lends a hand by offering you a temporary loan set at no charge.
  • Page 19 Product if found to be defective during the limited warranty period specified above. novita does not warrant uninterrupted or error-free operation of the product.

  • Page 20: Limited Warranty Extension

    • novita reserves all rights to update the Return & Refund Policy without prior notice. (T & C Updates Commission/Effective From 08 Dec 2023) • All information is accurate at the point of print. novita reserves all right to update the information without prior notice.
  • Page 22 COPYRIGHT © 2023 NOVITA SG DB/M/W28/V3/082023...
