Height Adjustable Armrests
Assembly, Installation and Operating Instructions
Model Nos. 19ST and 29ST
NOTE: Check ALL parts for shipping damage. In case of shipping damage, DO NOT use. Contact
Carrier/Dealer for further instructions.
To ensure the safe and proper installation of the Height Adjustable Armrests, these
instructions must be followed:
DO NOT install this equipment without first reading and understanding this
instruction sheet. If you are unable to understand the Warnings, Cautions and
Instructions, contact a healthcare professional, dealer or technical personnel if
applicable before attempting to install this equipment. Otherwise, injury or damage
may occur.
Any worn or damaged hardware MUST be replaced.
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely.
Invacare products are specifically designed and manufactured for use in conjunction
with Invacare accessories. Accessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare products.
Installing Adjustable Height Armrests
Make sure the armrest release lever is in the locked position before using the wheel-
chair.
NOTE: For this procedure, refer to FIGURE 1 on page 2.
1. Push down on existing armrest to ensure it is fully seated in front and rear sockets.
NOTE: STEP 1 prevents the release buttons from hanging up on the sockets during removal.
2. Unlock the rear of the armrest by rotating the armrest release lever towards the inside
of the wheelchair.
3. Press in the armrest release button at the front of the armrest.
4. While pressing in the armrest release button, remove the armrest from the arm sockets
by pulling straight up.
5. Position the adjustable height armrest just above the front and rear arm sockets.
For more information regarding Invacare products, parts, and services,
Part No 1141501
SAVE THESE INSTRUCTIONS
Safety Summary
WARNING
WARNING
please visit www.invacare.com
1
