A note about our
online installation instructions:
Most Modern Fan Co. products have been in our assortment for several
years or longer. As we continually work to improve product performance
and user experience, we occasionally introduce subtle (and sometimes
dynamic) product changes. These can affect the steps associated with
assembly and installation of our products depending on when a fan
was produced.
The instructions posted here are intended to represent our most current
product versions and configurations and the associated installation
steps. If your fan or parts of your fan do not appear to match what is
included here, please contact customer service for guidance and support
in identifying which version of a fan you may have and provision of the
associated installation instructions which correspond to that version.
If in doubt, or if you have any questions at all related to assembly,
installation or operation of your fan, please contact us!
The Modern Fan Company, Inc.
709 Washington Street, Ashland, Oregon 97520
tel 541-482-8545, toll free 888-588-3267
info@modernfan.com
modernfan.com
Advertisement
Related Manuals for The Modern Fan Company Pensi DC
Summary of Contents for The Modern Fan Company Pensi DC
- Page 1 If in doubt, or if you have any questions at all related to assembly, installation or operation of your fan, please contact us! The Modern Fan Company, Inc. 709 Washington Street, Ashland, Oregon 97520 tel 541-482-8545, toll free 888-588-3267 info@modernfan.com...
-
Page 2: Table Of Contents
Pensi DC Installation Instructions and Owners Manual Models: PEN–XX–XX–XX–XX(X)–XX Net Weight of Fan: 16.0 lbs (7.3 kgs) V2024/02 Please read and save these instructions. If you have any questions while installing your fan, call us first! Customer Service Monday–Friday, 8am–4pm... -
Page 3: Safety Instructions And Warnings
Safety Instructions and Warnings Please read all safety instructions prior to installing your ceiling fan and save this document for future reference. If you are in doubt with any of the information provided, we recommend that you consult or hire a qualified electrician to install your outlet box and ceiling fan. If you have any questions or difficulty installing your fan, call Modern Fan Co customer service at (888) 588-3267. - Page 4 Installation Preparation Fan Location WARNING Make sure the installation site you choose allows Minimum of the fan blades to rotate without any obstruction. 7 feet (2.1m) Allow a minimum clearance of 7 feet (2.1 meters) from the floor to the blades and 30 inches (76 cm) from the wall to the end of the blades.
-
Page 5: Fan Installation
Fan Installation Tools Needed A stepladder, Phillips head screwdriver, small crescent wrench and a Instructions wire stripper IMPORTANT: The included canopy receiver must be installed and paired with the wall or remote control components (see page 10). Third party fan controls may not be used with this product. - Page 6 Electrical supply wires should remain accessible through the center hole in mounting plate. Note: The Pensi DC fan is suitable for installation on flat ceilings only. If using an optional, longer down rod, dismantle standard down rod assembly as follows:...
- Page 7 Fan Installation (continued) Using blade screws from hardware package, secure blades to rotor arms. Suspend fan from mounting plate using security cable loop (on mounting plate) and suspension hook (on inside edge of fan canopy). suspension hook security cable suspended fan...
-
Page 8: Control Installation And Wiring
See Pages 2-3 Circuit Breaker WARNING POWER OFF Identify control components from control package(s). In addition to a receiving unit, your fan may have been ordered with a wall control (transmitter), a handheld remote control (transmitter) or both. wall clip handset receiving switch... - Page 9 See Pages 2-3 Circuit Breaker Fan Installation WARNING POWER OFF (continued) Insert receiving unit into the top of the fan body and make wire connections according to wire colors, labels and diagram in Step 6. All ground wires must be connected as shown in diagram. If ordered, install wall control into wall box.
- Page 10 If installing optional light kit, screw begin by identifying all parts. pack Then follow steps (a) through (d), socket otherwise, proceed to Step 10. LED lamp (bulb) connect wire leads attach socket to fan insert GU10 base install threaded from fan to socket with three screws LED lamp/bulb bottom tube...
- Page 11 Fan Installation See Pages 2-3 Circuit Breaker (continued) WARNING POWER OFF Control Pairing Wall controls and remote handsets communicate with the canopy receiver using radio frequency transmission. Each device (wall control and remote handset) is factory set to a unique channel to avoid unwanted interference with other fans installed nearby. A receiver can be paired with up to two devices (wall control + remote handset or two remote handsets).
- Page 12 Fan and Light Operation This fan operates with a micro-controller (enclosed in the canopy receiver) which regulates fan speed, fan direction and light function. After sending any operational command to your fan, wait several seconds before re-sending the same command or sending a new command.
-
Page 13: Troubleshooting
Troubleshooting Please read all installation instructions carefully. After reviewing the following troubleshooting tips, if you are unable to solve a problem with the installation or operation of you fan, please contact customer service for additional assistance. I M P ORTA NT : Do not return a fan or fan parts without first contacting us for troubleshooting assistance. - Page 14 Fan wobbles... • Make sure hanging bracket and mounting hardware at ceiling is secure and firmly fastened. • Be sure ridge in hanging bracket is seated in the half-ball slot. • Check that stopper screw (or stopper pin) and set screws are firmly tightened where down rod is attached to the fan body.
-
Page 15: Maintenance
Maintenance See Pages 2-3 Circuit Breaker WARNING POWER OFF Before servicing or cleaning your fan, switch power off at service panel and lock the service disconnecting means to prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such a tag, to the service panel. -
Page 16: Warranty
Lifetime Limited Warranty All products manufactured and sold by The Modern Fan Co. meet the highest industry standards. We use only the finest materials and production processes resulting in quality ceiling fans backed by the following warranty: Motors (dry locations): .......................Lifetime Motors (damp locations): .................... - Page 17 The Modern Fan Company, Inc. 709 Washington Street, Ashland, Oregon 97520 tel 541-482-8545, toll free 888-588-3267 info@modernfan.com modernfan.com V2024/02...
