1.5 Components of the interior

1 Ground connector
2 Antenna-interfaces
3 USB-interface sockets, type USB 3.1
4 DC voltage connectors first pair
5 DC voltage connectors second pair
6 Brass tube with male thread in- and outside of the box
7 RS-232-interface male-plugs
8 RJ45-interface socket
9 Appliance plug with integrated fuses F1 & F2 and switch S1
10 230 V AC power outlet
1 2
Illustration 2: Inner view MSB-0403
