MTS-No.: 27894-01

1.6 Starting up and operating

Before using the Shielding Box following connections have to be done:
Ground-connection
The Shielding Box has to be grounded expertly at the ground connector (look at
illustration 1, position 1). A cable with a conductor cross-section of minimum 1.5 mm²
has to be used.
Power supply
The power supply voltage range of the Shielding Box is 100 V - 240 V at
50 Hz / 60 Hz at connector X2 (look at illustration 2, position 9).
Interface connection
In order to control inner units, fitting data cables have to be connected. With attention
to the wiring table (see appendix) and the manual of inner units it is the users choice
how to contact the inner units.
Attention:
Attention:
At the Shielding Box no display elements are present. The only control element
represents the main switch which turns the 230 V power off or on.
The RJ45-interface is filtered by a LWL-changer mechanism, which needs the 230 V
power for working. The interface works with 10 MBit/s, 100 MBit/s or 1000 MBit/s.
This speed is detected automatically.
27894-01.MANUAL / MSB-0403 / V 2.0 / 07 December 2021
MTS Systemtechnik GmbH
Gewerbepark Ost 8
D-86690 Mertingen
Before connecting any data cable, the device and all inner units
have to be shut off!
Check all connections for correct hook up, before turning the power on.
Before starting make sure the Shielding Box is standing safely or is build
in safely.
The operating-temperature of the Shielding Box has to be between
0 °C and +50 °C.
To reach the specified screening of the box, close the cover and fix it
with the one hand mechanism. No objects e. g. measuring lines or the
like are allowed to be between Shielding Box and Shielding Box cover.
Phone +49 (0) 9078 / 91294 – 0
Fax +49 (0) 9078 / 91294 – 70
Page 8 from 13
