MTS-No.: 31149

1.5 Components of the interior

1 230 V AC power outlet
2 Honeycomb vent with fan
3 USB-interface sockets, type USB 3.2
4 RJ45-interface socket, according PoE++
5 RS-232-interface male-plugs
6 DC voltage connectors
7 Feedthrough for fiber-optic
8 Ground connector
9 Power inlet
1
Illustration 2: Inner view MSB-0605
31149.MANUAL / MSB-0605 / V 1.0 / 2024-03-08
2 3 4 5 6 7 8 9
