Lifetime IN-GROUND QUICK ADJUST 1008 Assembly Instructions Manual

IN-GROUND
QUICK ADJUST
BASKETBALL SYSTEM
MODEL 1008
BEFORE ASSEMBLY:
• Requires at least 420 lb (≈191 kg) of concrete mix to fi ll
a volume of 3.07 ft (≈0.087 m
3
• Requires, at least, 3 days for concrete to cure, plus
3–4 hours to complete assembly steps. If you have
quick-setting concrete, check the bag for required
cure time.
• At least 3 people recommended for setup.
WATCH THE INSTRUCTIONAL VIDEO ON YOUTUBE
Scan the code, or visit go.lifetime.com/1008-fullassembly
YouTube and the YouTube logo are trademarks of Google, LLC.
®
Save this instruction in the event that the manufacturer has to be contacted for replacement parts.
TOOLS REQUIRED (NOT INCLUDED)
1/2" (≈13 mm) 7/16" (≈11 mm)
(x2)
(x1)
Concrete Mix
(x1)
60-lb Bag (x7)
(x1)
(420 lb (≈191 kg))
QUESTIONS?
CONTACT LIFETIME
Dial 1-800-225-3865
(English, French, Spanish)
).
3
9/16" (≈14 mm)
(x2) (x2)
(x1)
(x1)
Bricks (x4–6)
CUSTOMER SERVICE:
®
Live Chat:
www.lifetime.com/customerservice/home
(click on "LIVE CHAT" tab)
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
®
3/4" (≈19 mm)
(x2)
(x1)
(x1)
(x1)
For Customer Service in Mainland Europe
and the United Kingdom,
E-mail: csinternational@lifetime.com
TABLE OF CONTENTS
Icon Legend...................................................4
Warnings & Notices......................................5
Initial Setup..................................................6
(x1)
Pole Assembly.............................................12
Backboard-to-Rim Assembly.....................15
Backboard-to-Pole Assembly.....................22
Parts Identifi er...........................................i–iv
(x1)
Final Assembly............................................29
Height Adjustment.....................................35
Maintenance.............................................36
Warning Sticker...........................................37
Registration..............................................40
Warranty....................................................41
(x1)
Model Number: 1008
Product ID:
