Summary of Contents for HM Bike Pedelec
- Page 1 Pedelec / E-CITY for battery handling and display function...
- Page 2 Content Battery Handling How the Electrical System works....................- - 1.1 How pedal assist tem (PAS) works..................- . . y .....
- Page 3 BATTERY HANDLING IMPORTANT: PLEASE READ THIS USER MANUAL BEFORE YOUR FIRST BIKE RIDE!!! How the Electrical System works Your e-bike is equipped with a pedal Assist System (PAS) and a motor to propel the bike forward. How the Pedal Assist System works Pedal assist uses a cadence sensor built into the drive train of the bike.
- Page 4 Use only the charger Model AD266 (input: 100-240V),made by WARNING: DONGGUAN ANGDI TECHNOLOGY CO., LTD! Safety Guidelines for charging: Battery is not shipped with a full charge. It should be charged before riding the bike. If ever possible, charge your battery in a room which has a smoke or re detector. When charging the battery which is removed from the bike, please make sure to place or any connections become wet, immediately unplug the charger and thoroughly dry all components.
- Page 5 Battery Installation press gently until it snaps in with a ‚click‘ sound (2). Then turn the key counter-clockwise to remove it. 2.5 Battery Maintenance and Saf ety Charge your battery in a temperature controlled, dry, safe location ideally at room temperature, 10°...
- Page 6 Protect the battery from material that may contaminate the charge port or the output port, such as dirt and sand; the ports may be di cult or impossible to clean out. Never subject the battery to intense physical shock or severe vibrations. Do not disassemble or replace internal components of electrical appliances.
-
Page 7: Table Of Contents
Content D16 Display User Guide Preface ............................Appearance, Size and Material ..................................1.1 Main Materials and Colors ....................... 2.1 Function Summary ....................2.2 Normal Display Figures ......................Note for Users ........................Normal Operation ................................................4.2 Real-time speed/Trip Milage Display Interface ............ -
Page 8: Preface
D16 Display Preface Dear Users, to ensure better performance of your e-bike, please read through the D16 display product introduction carefully before riding it. We will use brief words to inform you of all the details for using our display. Meanwhile, the introduction will also help you clarify possible question and barriers. -
Page 9: Appearance, Size And Material
1. Appearance, Size and material Main Materials and Colors The product adopts the combination of PC + ABS plastic housing, with no sharp angle in its appearance. The appearance e ect is black leather texture treatment. The Working temperature scope of housing material is -20˚C-- 60˚C, and can ensure normal use and good mechanical performance of the products. - Page 10 Mileage data (ODO, single trip, single trip time, max speed, average speed, PAS level 6km/h walk assist Turn on/o headlight, brightness control automatically (According to the light intensity of the external environment) USB charging function, output voltage/max output current: 5V/1A Setting functions: Single Trip Distance Clearance, Backlight Setting, Speed Unit, Factory reset, Automatic shutdown time and customized data showing setting function.
-
Page 11: Normal Display Figures
Normal Display Figures D16 Normal display interface This area shows the current battery remaining power, including the power grid mode progress bar mode This area shows USB status indication This area shows fault status indication This area shows headlight status indication; Including automatic headlight mode manual headlight mode This area shows real-time speed This area shows speed unit... -
Page 12: Note For Users
3. Note for users Be care of the safety use. Don’t attempt to release the connector when battery is on power. Try to avoid hitting. Don’t split the waterproof sticker to avoid a ecting the waterproof performance Don’t modify system parameters to avoid parameters disorder. Have the display repaired by a professional when error code appears. -
Page 13: Real-Time Speed/Trip Milage Display Interface
displayed rst, and then the system will be shut down next. Start-up interface Main interface Shut down interface Locking interface Real-time speed/trip mileage display interface After the display is turned on, the current speed can be refreshed in real time on the main interface, and the mileagerelated data can be viewed at the same time. -
Page 14: Km/H Walk Assist Mode
Real-time speed and Odometer display 6 km/h Walk Assist Mode Enter the 6km/h walk assist mode in the main interface. Press and hold the "WALK" button to activate the walk mode and light up the walk mode sign. After pressing the "WALK" button, you can perform 6km/h assistant function; if you release the "WALK" button, the function will be invalid and will exit the walk mode... -
Page 15: Pas Levels
The display automatically controls the headlight on and o by sensing external light. The light will turn on when the exterior light is dark, and turn o when the exterior light is bright. Manual mode : In automatic mode, long-press the "HEADLIGHT" button to switch to manual mode. - Page 16 TOUR level SPORT level TURBO level BOOST level WALK assist mode - 1 -...
-
Page 17: Battery Power Display
4.6 Battery Power display In the main interface, the battery power display is refreshed in real time. The battery content supports two display modes: progress battery power bar mode (in case of successful communication between battery and display) and battery power grid mode (in case of communication failure or no communication between battery and display). -
Page 18: Usb Charging
USB Charging Plug in the device that needs charging when display is o . After turn on the display, the battery will appear. charge the device through the display, and the USB charging logo on the interface will After the device that needs USB charging is plugged in at the power on state, long press the "PLUS" button in the main interface to activate the USB charging function. -
Page 19: User Settings
" " logo showed in the upper column will disappear synchronously. Please check Error code display interface . User Settings In the information interface, press and hold the "PLUS" and "MINUS" button at the same time to enter the setting interface. Short press the "CONFIRM" button in the setting menu to enter the sub option. -
Page 20: Backlight Setting
Single trip clearance interface .2 Backlight Setting Short press the "MINUS" or "PLUS" button to switch and select the backlight level. Short press the "CONFIRM" button to con rm the currently selected backlight level. Short press the "CONFIRM" button on the "Return" option, to return to the previous interface. Long- press "CONFIRM"... -
Page 21: Speed Unit Setting (Metric / Imperial)
.3 Speed unit setting (Metric / Imperial) Short press the "MINUS" or "PLUS" button to select the speed unit option. Short press the "CONFIRM" button to con rm the currently selected speed unit. Short press the "CONFIRM" button on the "Return" option, to return to the previous interface. Long press "CONFIRM"... -
Page 22: Automatic Shutdown Time Setting
Automatic shutdown time setting Short press the "MINUS" or "PLUS" button to select the automatic shutdown time option. Short press the "CONFIRM" button to con rm the currently selected automatic shutdowntime. Short press the "CONFIRM" button on the "Return" option, to return to the previous interface. Long press "CONFIRM"... -
Page 23: Read Only Informtion
press"CONFIRM"button to return to the main interface. Default setting shows all the options. Customized data showing setting interface . Read-only Information In order t o make us ers know more about our w alkas s is t E- bike s ys t em,t he dis play s upport s t o view t he paramet ers of t he w alkas s is t E- bike s ys t em. -
Page 24: Display Read Only Information
Battery read-only information interface Display read-only information Short press the"MINUS"or"PLUS"button to select the read-only information option of the display to be viewed. Short press the"CONFIRM"button on the"Return"option, to return to the previous interface. Long press"CONFIRM"button to return to the maininterface. Display read-only information interface The code printed is according to the requirements of Ananda Drive Techniques (Shanghai) Co.,Ltd. -
Page 25: Faq
. FAQ Why can‘t I turn on the display? A: Please check whether the battery is turned on or the leakage lead wire is broken Q: How to deal with the error code display? A: Contact the e-bike maintenance station in time. . -
Page 26: Cirquit Diagram And Wire Sequence
. Circuit Diagram and wire sequence Standard connector wire sequence: Connecting end with controller Connecting end with buttons Standard connector wire sequence table Standard Wire Color of standard Wire Function Red (VCC) Display power wire Blue(K) Power control wire of controller Black(GND) Instrument Ground wire Green(RX) -
Page 27: Appendix 2 Detail Contents Of Setting Menu
Appendix 1: Error code de nitions Error Code De nition Current abnormal Throttle fault Motor Hall signal fault Brake abnormal Other faults Communication failure Switch button sticky Display working voltage abnormal Display self-check failure 6km Walk assist button sticky Appendix 2 Detail contents of setting menu Level 1 menu Level 2 menu Level 3 menu... - Page 28 Thank you for choosing our bike! HM Bike Consulting SA Alte Selfrangastrasse 2 CH-7250 Klosters www.hmbike.com info@hmbike.com...
