Swisher POL12544X Owner's Manual

Swisher POL12544X Owner's Manual

44” rough cut trail cutter
Hide thumbs Also See for POL12544X:
Table of Contents

Advertisement

Quick Links

www.swisherinc.com
OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL #:
L112-317001
POL12544X
POL12544XEX
POL14544X
POL14544X-CA
POL14544XEX
RC12544BS
RC12544BSXP
RC14544BS
RC14544BS-CA
RC14544BSXP
IMPORTANT
IMPORTANT
Read and follow all
Read and follow all
Safety Precautions
Safety Precautions
and Instructions
and Instructions
before operating this
before operating this
equipment.
equipment.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
17338 REV 12-317
44" ROUGH CUT
TRAIL CUTTER
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE (660) 747-8183 FAX (660) 747-8650
Made In The
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POL12544X and is the answer not in the manual?

Questions and answers

Related Manuals for Swisher POL12544X

Summary of Contents for Swisher POL12544X

  • Page 1 OWNER’S MANUAL MODEL NO. STARTING SERIAL #: L112-317001 POL12544X POL12544XEX POL14544X POL14544X-CA POL14544XEX 44” ROUGH CUT RC12544BS RC12544BSXP TRAIL CUTTER RC14544BS RC14544BS-CA RC14544BSXP Assembly IMPORTANT IMPORTANT Operation Read and follow all Read and follow all Safety Precautions Safety Precautions...
  • Page 2 Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    Thank you for choosing Swisher’s 44” Trail Cutter. Before operating your cutter, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers, and cutters can be potentially dangerous if improperly used.
  • Page 4 • Turn off the blades when not cutting. Before leaving the machine, turn off the blades and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the cutter if it has been dropped or damaged in any manner or if the mower vibrates excessively.
  • Page 5 OPERATING YOUR TRAIL CUTTER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any mower produces sound waves that are damaging to the human ear.
  • Page 6 Stop cutter. STARTING THE ENGINE See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Cutters equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard “U1” battery. •...
  • Page 7 When offsetting the cutter do so to the side opposite the discharge of the tow vehicle. • Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle. Always keep safety the first priority.

  • Page 8: Cutter Maintenance

    • Reducing the travel speed will help cut dense growth. This allows the blades the time necessary to make its initial cut, and regain momentum to continue cutting and discharging debris properly. The engine may stall if you are mowing too fast! •...

  • Page 9: General Troubleshooting

    GENERAL TROUBLESHOOTING The unit is not cutting level. • Level deck. Check air pressure of all tires; make sure they are equal. See tires for maximum inflation. • Without the engine running, make certain blades are installed identically. The engine will not start. •...

  • Page 10: Safety And Operational Decals

    SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher. 1-800-222-8183, 8-5 CT M-F OD39-SWISHER FLAG DECAL OD82-44 RUGGED CUT DECAL OD33-5MPH DECAL OD29-DANGER DECAL OD36-DEFLECTOR DECAL OD55-DANGER DECAL OD10-ENGAGE DECAL OD45-WARNING DECAL OD99112 LARGE SWISHER LOGO...
  • Page 11 FRONT SKIRT ASSEMBLY FIGURE 1 Item # Description Part # Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690 Washer - Fender, 1/4X1 1/4OD Gr 2 ZY 11520 Rubber Flapper 10384 Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524 HITCH ASSEMBLY FIGURE 2...
  • Page 12 Item # Description Part # Crank Rod ES214 MOBILITY & COVER Bolt - 1/2-13 X 1 1/2 10046 Single Point Pivot Block 4007* ASSEMBLIES 1/2-13 2-Way Jam Lock Nut NB121 Washer - Bellville, .512x1.26x .138 10291 FIGURE 3 1/2-13 Jam Nut NB118 1/2 NR Mach Bushing 14 GA NB177...

  • Page 13: Deck Assembly

    Item # Description Part # DECK ASSEMBLY Screw - .312-18 x .75 26X249 Side Gusset - Right 15057* FIGURE 4 Nut - 5/16-18 Serrated Flange NB170 Side Gusset - Left 15056* Deck - Weldment; RT44 15727* Bracket - Remote Cable Detent 15606* Weldment - Blade Mount 15005*...
  • Page 14 BLADE DRIVER ASSEMBLY FIGURE 5 Item # Description Part # Nut - Nyloc 1"-8 NB612 Washer - 1" X 2" X 14GA NB738 Pulley - Blade, 10.3125" 4846 Spacer - Pulley BB105SL Bearing - Blade 4845 Shaft - Blade 18844 Nut - Nyloc 1/2"-13 NB281 Washer - USS Flat, 1/2"...
  • Page 15 ENGINE PULLEY ASSEMBLY FIGURE 6 Item # Description Part # Engine B&S NOT ACTUAL 5/16-18 Serrated Flange Nut NB170 NB253 5/16''-18 X 1 1/4'' Serrated Flange Bolt ENGINE USED 5/16'' USS Flat Washer ZP NB556 RT44 Belt Guide 4867 (REF. ONLY) Spacer For Engine Pulley BB105S Bolt - Serr Flange,5/16-18 X1 3/4 ZY Gr5...

  • Page 16: Console Assembly

    CONSOLE ASSEMBLY FIGURE 8 Item # Description Part # Item # Description Part # T Handle for Console 4463* 1/4 SAE Washer NB274 1/4-20 Nylok Nut NB180 Console Mount Plate 4852* 5/16-18 Nyloc Nut NB181 1/4-20 Wing Nut ZP NB608 5/16-18 X 1 1/2 Torx Pan ZP NB591 1/4 X 1 1/2 Clevis Pin...
  • Page 17 WIRING DIAGRAM, 12.5HP ENGINE FIGURE 9 10385 WIRING DIAGRAM, 14.5HP ENGINE FIGURE 10 10299...
  • Page 18 ENGINE TO BLADE PULLEY CONFIGURATION FIGURE 11 P/N 4846 P/N B527 P/N BA50 P/N BB105 Notes...
  • Page 19 REPAIR PARTS Your 44’’ Trailcutter has been produced with components designed specific to this machine. Although standard V-belts, springs, bearings, blades, pulleys, hardware, etc. look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials.
  • Page 20 RECOMMENDED HITCH CONFIGURATIONS AND POSITIONS...
  • Page 22 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
  • Page 23 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
  • Page 24 STARTING SERIAL #: All mower parts listed herein may be ordered directly from L112-317001 Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the POL12544X engine supplied with your mower POL12544XEX...
