Owner's
Manual
Acreage Rake
ACR-5212V
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
Before Operating this
Equipment.
Made In CHINA
1602 CORPORATE DRIVE , PO BOX 67, WARRENSBURG, MISSOURI 64093
PH 660. 747. 8183 FAX 660. 747. 8650
www.swisherinc.com
14764
REV. 09-190
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher ACR-5212V
Summary of Contents for Swisher ACR-5212V
- Page 1 MANUFACTURING QUALITY LAWN CARE EQUIPMENT SINCE 1945 Owner’s Manual Acreage Rake ACR-5212V IMPORTANT Read and follow all Safety Precautions and Instructions Before Operating this Equipment. Made In CHINA 1602 CORPORATE DRIVE , PO BOX 67, WARRENSBURG, MISSOURI 64093 PH 660. 747. 8183 FAX 660. 747. 8650 www.swisherinc.com...
- Page 2 Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
- Page 3 Approximate assembly time of this product is 1/2 of an hour. Helpful Tip: Read all instructions before starting to assemble. WARNING: Swisher Mower will not be held liable for any damages, losses or injury, due to the misapplication or misuse of this product or for any other reason.
- Page 4 Bolt M10 x 55 11881 Bolt M10 x 45 OPTIONAL ACCESSORIES: Check with Retailer where you purchased this product for these optional attachments. Or you may call Swisher at (800) 222-8183 for accessories and replacement parts. Part/Item# Description 14570 Replacement Rake Tine Reel...
- Page 5 ASSEMBLING THE ACREAGE RAKE STEP 1: Attach Pneumatic Wheel (#2) to Axle (#1) with Lock Nut M20 x 2 (A). NOTE: Inflation valve stem of the wheel should be facing out. CAUTION: DO NOT over tighten the lock nut, this can result in damage to the bearings in the wheel hub.
- Page 6 OPERATION AND MAINTENANCE SETTTING RAKE TINE WHEELS FOR THATCHING VS. RAKING Rotation Direction Rotation Direction Figure 14 Acreage rake has been assembled for raking. See figure 14. Note the direction of the tine tips. Flip Each Arm 180 degrees 2. To position rake tine wheel assembly for thatching, remove lock pin from both lift arms and remove both rake tine wheel assemblies from rake.
- Page 7 MAINTENANCE AND RECOMMENDATIONS FOR BEST RESULTS Operating Tip: Rake works for picking up Acorns or similar small particles other than grass/leaves. GENERAL OPERATION/MAINTENANCE: • NEVER operate Acreage Rake at speeds higher than 5 MPH. • Follow tire inflation printed on tires. •...
