www.swisherinc.com
OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL #:
L122-091001
RC15544BS
IMPORTANT
IMPORTANT
Read and follow all
Read and follow all
Safety Precautions
Safety Precautions
and Instructions
and Instructions
before operating this
before operating this
equipment.
equipment.
9/8/2022
17338 REV 22-091
44" COUNTRY CUT
TRAIL CUTTER
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
PHONE (660) 747-8183 FAX (660) 747-8650
Made In The
USA
of US and Global Parts
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher Country Cut RC15544BS
Summary of Contents for Swisher Country Cut RC15544BS
- Page 1 Instructions and Instructions Repair Parts before operating this before operating this equipment. equipment. Made In The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 9/8/2022 PHONE (660) 747-8183 FAX (660) 747-8650 of US and Global Parts 17338 REV 22-091...
-
Page 2: Limited Warranty
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
Thank you for choosing Swisher’s 44” Trail Cutter. Before operating your cutter, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers and cutters can be potentially dangerous if improperly used. - Page 4 • Turn off the blades when not cutting. Before leaving the machine, turn off the blades and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the cutter if it has been dropped or damaged in any manner or if the mower vibrates excessively.
- Page 5 OPERATING YOUR TRAIL CUTTER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any mower produces sound waves that are damaging to the human ear.
- Page 6 See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Cutters equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard lawn and garden size “U1” with 240 CCA or greater battery.
-
Page 7: Cutter Height Adjustment
• Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle. Always keep safety the first priority. -
Page 8: Cutter Maintenance
• Reducing the travel speed will help cut dense growth. This allows the blades the time necessary to make its initial cut, and regain momentum to continue cutting. The engine may stall if you are mowing too fast! • Do not attempt to cut areas that the tow vehicle cannot maneuver through and/or slopes that you do not feel comfortable riding. -
Page 9: General Troubleshooting
GENERAL TROUBLESHOOTING The unit is not cutting level. • Level deck. Check air pressure of all tires; make sure they are equal. See tires for maximum inflation. • Without the engine running, make certain blades are installed identically. The engine will not start. •... -
Page 10: Safety And Operational Decals
SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. 19976-SWISHER FLAG DECAL OD33-5MPH DECAL OD29-DANGER DECAL OD36-DEFLECTOR DECAL OD55-DANGER DECAL OD10-ENGAGE DECAL OD45-WARNING DECAL OD99112 LARGE SWISHER LOGO OD28-OFF/RUN/START DECAL... -
Page 11: Hitch Assembly
FRONT SKIRT ASSEMBLY FIGURE 1 Item # Description Part # Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524 Rubber Flapper 10384 Washer - Fender, 1/4X1 1/4OD Gr 2 ZY 11520 Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690 HITCH ASSEMBLY FIGURE 2... - Page 12 MOTOR BASE, WHEEL & HEIGHT ADJUSTMENT ASSEMBLIES FIGURE 3 Item # Description Part # Item # Description Part # Motor Base 10343* Nut - 5/16-18 Serrated Flange NB170 Cover - Rear 20941* Nut, Push - 5/16 NB117 Belt - Blade, 50" 20655 Knob Height Adjustment 1/2-13 Nyloc Nut...
-
Page 13: Deck Assembly
DECK ASSEMBLY Item # Description Part # FIGURE 4 Deck - Weldment 15727* Screw - .312-18 x .75 26X249 Side Gusset - Left 15056* Nut - 5/16-18 Serrated Flange NB170 Side Gusset - Right 15057* Z Bracket, Jack Support 15055* Front Rail/Deck Support 15054* Bracket - Remote Cable Detent... - Page 14 BLADE DRIVER ASSEMBLY FIGURE 5 Item # Description Part # Nut - Nyloc 1"-8 NB612 Washer - 1" X 2" X 14GA NB738 Pulley - Blade, 10.3125" 4846 Spacer - Pulley 21344 Bearing - Blade 4845 Shaft - Blade 18844 NB281 Nut - Nyloc 1/2"-13 Washer - USS Flat, 1/2"...
- Page 15 ENGINE PULLEY ASSEMBLY FIGURE 6 Item # Description Part # Engine B&S NB253 5/16''-18 X 1 1/4'' Serrated Flange Bolt 5/16-18 Serrated Flange Nut NB170 5/16''-18 Nyloc Nut NB181 Bolt - Serr Flange, 5/16-18 X1 3/4 ZY Gr5 NB515 Spacer For Engine Pulley BB105S 1/4'' X 1'' Key Stock 9031...
-
Page 16: Console Assembly
CONSOLE ASSEMBLY FIGURE 8 Item # Description Part # Item # Description Part # T Handle for Console 4463* 1/4 SAE Washer NB274 1/4-20 Nyloc Nut NB180 1/4-20 X 2 1/2 HCC GR2 ZP NB163 5/16-18 Nyloc Nut NB181 1/4-20 X 1 1/4 HCC GR5 ZP NB560 Link for Console 4461*... - Page 17 WIRING DIAGRAM, 15.5HP ENGINE FIGURE 9 PN 10299 ENGINE TO BLADE PULLEY CONFIGURATION FIGURE 10 PN 4846 PN B527 PN 20655 PN BB105...
- Page 18 REPAIR PARTS Your 44’’ Trailcutter has been produced with components designed specific to this machine. Although standard V-belts, springs, bearings, blades, pulleys, hardware, etc. look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials. Mowers equipped with a 15.5HP engine have a separate 2.5 gallon fuel tank.
- Page 19 BATTERY HOLDER CONFIGURATION FIGURE 13 Lid Opened Position Lid Closed Position Note: Use Thumbscrew [item #3] to hold lid in the open position as shown in illustration above. Item # Description Part # Guard - Battery Box Lid 21209* Bolt - Flange 5/16-18 NB743 Thumb Screw - 5/16-18 18802...
- Page 20 RECOMMENDED HITCH CONFIGURATIONS AND POSITIONS FIGURE 15...
- Page 22 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 23 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 24 All mower parts listed herein may be ordered directly from RC15544BS Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the engine supplied with your mower WHEN ORDERING PARTS, PLEASE HAVE THE FOLLOWING INFORMATION AVAILABLE: * PRODUCT –...
