44" trail cutter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.swisherinc.com
OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL #:
L122-315001
RC14544CPKA
IMPORTANT
IMPORTANT
Read and follow all
Read and follow all
Safety Precautions
Safety Precautions
and Instructions
and Instructions
before operating this
before operating this
equipment.
equipment.
10/26/2022
20929 REV 22-315
COMMERCIAL PRO
44" COUNTRY CUT
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
PHONE (660) 747-8183 FAX (660) 747-8650
TRAIL CUTTER
Made In The
USA
of US and Global Parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L122-315001 and is the answer not in the manual?

Questions and answers

Related Manuals for Swisher L122-315001

Summary of Contents for Swisher L122-315001

  • Page 1 Instructions and Instructions Repair Parts before operating this before operating this equipment. equipment. Made In The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 10/26/2022 PHONE (660) 747-8183 FAX (660) 747-8650 of US and Global Parts 20929 REV 22-315...

  • Page 2: Limited Warranty

    Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    Thank you for choosing Swisher’s 44” Trail Cutter. Before operating your cutter, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers and cutters can be potentially dangerous if improperly used.
  • Page 4 • Turn off the blades when not cutting. Before leaving the machine, turn off the blades and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the cutter if it has been dropped or damaged in any manner or if the mower vibrates excessively.
  • Page 5 OPERATING YOUR TRAIL CUTTER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any mower produces sound waves that are damaging to the human ear.
  • Page 6 Disengage the blades and shut off the engine. STARTING THE ENGINE See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Cutters equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard “U1” battery. •...

  • Page 7: Cutter Height Adjustment

    • Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle. Always keep safety the first priority.

  • Page 8: Cutter Maintenance

    • Reducing the travel speed will help cut dense growth. This allows the blades the time necessary to make its initial cut, and regain momentum to continue cutting. The engine may stall if you are mowing too fast! • Do not attempt to cut areas that the tow vehicle cannot maneuver through and/or slopes that you do not feel comfortable riding.

  • Page 9: General Troubleshooting

    GENERAL TROUBLESHOOTING The unit is not cutting level. • Level deck. Check air pressure of all tires; make sure they are equal. See tires for maximum inflation. • Without the engine running, make certain blades are installed identically. The engine will not start. •...

  • Page 10: Safety And Operational Decals

    SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. OD29-DANGER DECAL OD129-ENGAGE DECAL OD33-5MPH DECAL OD36-DEFLECTOR DECAL OD45-WARNING DECAL OD55-DANGER DECAL OD99112 LARGE SWISHER LOGO OD28-OFF/RUN/START DECAL...
  • Page 11 UNCRATING & SET-UP DIAGRAM Item # Description Part # Item # Description Part # Washer - 3/4 ID 18 GA NB179 Weldment - Hitch Mount; RC44 21114* Coupler - 2" Ball 7365 Nut - 3/8-16 Lock NB182 Bolt - Hex, 3/8-16 X 3" NB150 Nut - 3/4-10 Lock 21132...

  • Page 12: Hitch Assembly

    FRONT SKIRT ASSEMBLY Item # Description Part # Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524 Rubber Flapper 10384 Washer - Fender, 1/4X1 1/4OD Gr 2 ZY 11520 Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690 Nut - Serr Flange, 1/4-20 Grade 5 ZY NB180 Plate - Harness, Mount 20910*...
  • Page 13 MOTOR BASE, WHEEL & HEIGHT ADJUSTMENT ASSEMBLIES FIGURE 5 Item # Description Part # Item # Description Part # Motor Base 20908* Nut - 5/16-18 Serrated Flange NB170 Cover - Rear, RC14544CPKA 20941* Nut, Push - 5/16 NB117 Belt - B X 56" 20937 Knob Height Adjustment 1/2-13 Nyloc Nut...

  • Page 14: Deck Assembly

    DECK ASSEMBLY Item # Description Part # FIGURE 6 Deck - Weldment 15727* Screw - .312-18 x .75 26X249 Side Gusset - Left 15056* Nut - 5/16-18 Serrated Flange NB170 Side Gusset - Right 15057* Z Bracket, Jack Support 15055* Front Rail/Deck Support 15054* Rail - RT44, Right...
  • Page 15 BLADE DRIVER ASSEMBLY FIGURE 7 Item # Description Part # Nut - Nyloc 1"-8 NB612 Washer - 1" X 2" X 14GA NB738 Pulley - Blade, 10.3125" 4846 Spacer - Pulley 21344 Bearing - Blade 4845 Shaft - Blade 18844 NB281 Nut - Nyloc 1/2"-13 Washer - USS Flat, 1/2"...
  • Page 16 ENGINE PULLEY/BELT ASSEMBLY FIGURE 8 Item # Description Part # Engine (Reference Model Shown) Washer - Split Lock, 3/8 ZY, Medium NB711 Bolt - 3/8-16 X 1 1/4 GR5 ZY NB618 Spacer - 1.25OD X 1.032 ID X .90 Txt Blk 20572* Nut - Nyloc 5/16-18 ZY NB181...

  • Page 17: Console Assembly

    CONSOLE ASSEMBLY FIGURE 10 † Items 1, 2, 3 & 7 can be purchased as Key Switch Kit 21329. When mounting the console assembly it may be necessary to mount it directly to the hitch tube depending on the vehicle you are towing it with. Some vehicle configurations will allow the console to be mounted to the vehicle (i.e.

  • Page 18: Repair Parts

    REPAIR PARTS Your 44’’ Trailcutter has been produced with components designed specific to this machine. Although standard V-belts, springs, bearings, blades, pulleys, hardware, etc. look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials. Mowers equipped with a 14.5HP engine have a separate 2.5 gallon fuel tank.
  • Page 19 BATTERY HOLDER CONFIGURATION Mower require a U1 battery (not included). Lid Opened Position Lid Closed Position FIGURE 14 Note: Use Thumbscrew [item #3] to hold lid in the open position as shown in illustration above. Item # Description Part # Guard - Battery Box Lid 21211* Bushing - .33 ID x .493 OD x .135...
  • Page 20 BATTERY CABLE ASSEMBLY Mower require a U1 battery (not included). Item # Description Part # Cable - Black 10" Nut - M8 x 1.35 Zinc NB718 Bolt - HH M8 x 1.25 NB719 FIGURE 16 Mower not shown for Clarity When ordering replacement parts * = USE PAINT CODE: TK=BLACK...
  • Page 21 RECOMMENDED HITCH CONFIGURATIONS AND POSITIONS FIGURE 17 FIGURE 18 FIGURE 19 FIGURE 20 FIGURE 21 Unlocked Locked...
  • Page 23 All mower parts listed herein may be ordered directly from Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the engine supplied with your mower...
