Installation and commissioning

General

NOTE!
The following steps are described using the RC Panel Basic as an example,
however the process is the same on all variants of the RC Panel.

Fitting options

Risk of injury and material damage from falling remote control.
▶
Fitting to a bar:
*
Connecting the
1
remote control
to system com-
ponents
SpeedNet connection socket
50
CAUTION!
Always secure the remote control to prevent it from falling down.
*
Cable not provided with RC Panel Basic /BT
Fitting to a hook:
*
1
TMC connection socket
