RC Panel Stan- The following welding parameters can be set and displayed for TIG welding:
dard TIG wel-
ding parameters
With the left adjusting dial:
(1)
- TIG welding
- STICK manual metal arc (MMA) welding
- CEL manual metal arc (MMA) welding
- JOB - Job Mode
- SP (SP = special program) - Depending on which function package is
enabled, different welding processes can be selected. Press the but-
ton to see the available welding processes shown on the display one
after the other
Mode button
To select the operating mode.
The corresponding LED lights up when an operating mode is selected. The
following modes can be selected by pressing the button:
2 T = 2-step mode
4 T = 4-step mode
Special modes depending on the function package
Main current I1 (AC/DC-)
Uniform thermal input into the base material, whose temperature is raised
by the advancing heat.
