Controls and indicators on the RC Panel Standard
TIG

General

NOTE!
See the Operating Instructions of the power source for more details of the wel-
ding parameters listed below.
NOTE!
As a result of firmware updates, you may find that there are functions available
on your device that are not described in these Operating Instructions or vice
versa.
Certain illustrations may also differ slightly from the actual controls on your de-
vice, but these controls function in exactly the same way.

Input options

(1)
(1)
(2)
Turn the adjusting dial
Left adjusting dial with turn/press function
To select elements, set values and scroll through lists
Right adjusting dial with turn/press function
To select elements, set values and scroll through lists
- Select elements in the displays
- Change values
(2)
41
