LAUNCH
Trademarks
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. in China and other countries. All other
marks are trademarks or registered trademarks of their respective holders.
Copyright Information
Copyright © 2023 by LAUNCH TECH CO., LTD. (also called LAUNCH for short). All rights reserved. No
part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by
any means, electronic, mechanical, photocopying and recording or otherwise, without the prior written
permission.
Statement: LAUNCH owns the complete intellectual property rights for the software used by this product.
For any reverse engineering or cracking actions against the software, LAUNCH will block the use of this
product and reserve the right to pursue their legal liabilities.
Disclaimer of Warranties and Limitation of Liabilities
All information, illustrations, and specifications in this manual are based on the latest information
available at the time of publication.
The right is reserved to make changes at any time without notice. We shall not be liable for any direct,
special, incidental, indirect damages or any economic consequential damages (including the loss of
profits) due to the use of the document.
Important Safety Precautions
To avoid personal injury, property damage, or accidental damage to the product, read all of the
information in this section before using the tool.
DANGER
• When an engine is operating, keep the service area well-ventilated or attach a building exhaust
removal system to the engine exhaust system. Engines produce various poisonous compounds
(hydrocarbon, carbon monoxide, nitrogen oxides, etc.) that cause slower reaction time and result in
death or serious personal injury.
• Please use the included battery and power adaptor. Risk of explosion if the battery is replaced with an
incorrect type.
• DO NOT attempt to operate the tool while driving the vehicle. Have second personal operate the tool.
Any distraction may cause an accident.
WARNING
 Always perform automotive testing in a safe environment.
 Do not connect or disconnect any test equipment while the ignition is on or the engine is running.
 Before starting the engine, put the gear lever in the Neutral position (for manual transmission) or in the
Park (for automatic transmission) position to avoid injury.
 NEVER smoke or allow a spark or flame in vicinity of battery or engine. Do not operate the tool in
explosive atmospheres, such as in the presence of flammable liquids, gases, or heavy dust.
 Keep a fire extinguisher suitable for gasoline/chemical/electrical fires nearby.
 Wear an ANSI-approved eye shield when testing or repairing vehicles.
 Put blocks in front of the drive wheels and never leave the vehicle unattended while testing.
i

Advertisement

Table of Contents
loading

Related Manuals for Launch X-431 IMMO PAD

Summary of Contents for Launch X-431 IMMO PAD

  • Page 1 LAUNCH Trademarks LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. in China and other countries. All other marks are trademarks or registered trademarks of their respective holders. Copyright Information Copyright © 2023 by LAUNCH TECH CO., LTD. (also called LAUNCH for short). All rights reserved. No...
  • Page 2 LAUNCH  Use extreme caution when working around the ignition coil, distributor cap, ignition wires and spark plugs. These components create hazardous voltage when the engine is running.  To avoid damaging the tool or generating false data, please make sure the vehicle battery is fully charged and the connection to the vehicle DLC (Data Link Connector) is clear and secure.

  • Page 3: Table Of Contents

    LAUNCH Table of Contents 1 Introduction ............................1 1.1 Product Profile ..........................1 1.2 Package List ........................... 1 1.3 Components & Controls ......................... 2 1.3.1 Display Tablet .......................... 2 1.3.2 SmartLink C V2.0 Device ......................4 1.3.3 Docking Station ........................5 1.4 Technical Specifications .........................
  • Page 4 11.2.2 TeamViewer QS ........................46 11.2.3 Wireless Upgrade ........................ 46 11.2.4 File Explorer ........................46 12 J2534 Reprogramming Using SmartLink C ................47 13 FAQ ..............................48 13.1 About X-431 IMMO PAD ......................48 13.2 About SmartLink Diag........................ 49 Warranty .............................. 50...

  • Page 5: Introduction

    LAUNCH 1 Introduction 1.1 Product Profile This Android OS-based, tablet-style diagnostic tool incorporates the best possible coverage of OE-level diagnostics with multitasking capable software. Using the powerful 8-core 2.0GHz processor and a 10.1 inch sunlight readable capacitive touch screen with a resolution of 1920 x 1200 pixels, it delivers quick and complete diagnostic functionalities which technicians need to diagnose, research and repair vehicles in one solution.

  • Page 6: Components & Controls

    LAUNCH 1.3 Components & Controls There are two main components to the diagnostic system: display tablet and SmartLink C V2.0 device. 1.3.1 Display Tablet...
  • Page 7 LAUNCH 1. Memory Card Slot Insert a memory card for storage extension. 2. Data I/O Port • Connect it to the SmartLink C V2.0 device to perform vehicle diagnosis. • Connect it to the add-on module to extend the functions of the diagnostic tablet.

  • Page 8: Smartlink C V2.0 Device

    LAUNCH Produce a flash of artificial light. 12. Rear Camera Snapshot the view in front of the tablet. 13. Audio Speaker Convert an electrical audio signal into a corresponding sound. 14. Charging Slot Align it with the charging slot on the docking station to charge the tablet. Refer to Chapter 1.3.3.

  • Page 9: Docking Station

    LAUNCH 1. DB-15 diagnostic connector Connect it to the vehicle’s DLC (Data Link Connector) port via the diagnostic cable. 2. Touch screen 3. LAN/WAN port Connect it to the modem via the crossover cable. It only applies to the SmartLink Super Remote Diagnostics.

  • Page 10: Technical Specifications

    LAUNCH 1. Charging slot Charge the diagnostic tablet. 2. OBD II socket Store the OBD II adaptor to avoid loss. 3. DC 5V OUT port Reserved for charging other USB devices only. 4. Charging port Use the power adaptor to supply power to the docking station through connection to AC outlet.
  • Page 11 LAUNCH Working voltage: DC 9~36V Power consumption: ≤ 6W Communication: wireless and wired Working temperature: 0℃~ 50℃...

  • Page 12: Initial Setup

    LAUNCH 2 Initial Setup 2.1 Charging the Tablet *Notes: • Only use the included power adaptor to recharge the tablet. Use of any other adaptor will damage the tool. We assume no responsibility for damage or loss resulting from using other similar adaptors other than the specified one.

  • Page 13: Changing Language

    LAUNCH 1. On the home screen, tap Other Modules -> Built-in apps -> Tablet Settings -> Display -> Brightness level. 2. Drag the slider to adjust it. Alternatively, user may also slide the Automatically brightness switch to ON, and the system will automatically adjust the screen brightness.

  • Page 14: Getting Started

    LAUNCH 3 Getting Started 3.1 Register & Update For initial use, the registration is the necessary first procedure to activate the tool. After the tablet is initialized, tap Login on the upper right corner of the screen, the following screen will...

  • Page 15: Home Screen

    LAUNCH Tap OK to navigate to the update center to update all available software. After the registration is successfully complete, the wireless communication between the tablet and the SmartLink C device is automatically established and user has no need to configure it again.
  • Page 16 • Check the historical repair records online. Remote Diagnose: This option aims to help repair shops or technicians launch instant messaging and remote diagnosis, making the repair job getting fixed faster. Remote Diagnose & SmartLink Diag.: The SmartLink system is powerful remote diagnostics SmartLink Diag.

  • Page 17: Connections

    LAUNCH 4 Connections 4.1 Preparation 1. Make sure that the ignition is turned off and vehicle battery voltage range is 9-14V or 18-30V. 2. Find DLC location. For passenger cars, the DLC(Data Link Connector) is usually located 12 inches from the center of the instrument panel, under or around the driver’s side for most vehicles.
  • Page 18 LAUNCH 1. VCI 2. DB15F to HD15F data cable 3. HD15F to OBD16 adaptor 4. Vehicle’s DLC port For non-OBDII vehicles, refer to the above figure to make connection. 1. Select the appropriate adaptor according to the vehicle’s DLC port type (4).

  • Page 19: Key Immobilizer & Immobilizer Programming

    LAUNCH 5 Key Immobilizer & Immobilizer Programming An immobilizer is an anti-theft mechanism that prevents a vehicle’s engine from starting unless the correct ignition key or other device is present. Most new vehicles have an immobilizer as standard equipment. An important advantage of this system is that it doesn’t require the car owner to activate it since it operates automatically.
  • Page 20 LAUNCH 3) Enter the Anti-Theft System, follow the illustration below to connect the VCI, vehicle and X-PROG3/X-PROG (*needs to purchased separately) to perform the next step. 4) If you don't know the type of the Anti-Theft System, tap Intelligent Mode to enter.
  • Page 21 LAUNCH 6) Tap Preprocessing to perform Read Anti-Theft data, Key Matching and more. If it has already been preprocessed, here you can perform the relevant functions. The ECU will be upgraded in this process, and files need to be downloaded online.
  • Page 22 LAUNCH 11) Read and display the password, and tap OK. 12) Place a new key close to vehicle coil, tap OK, and wait for the key to generate. 13) After the dealer key is successfully generated, please try to start the vehicle.

  • Page 23: Immobilizer Programming (Immo Prog)

    LAUNCH 5.2 Immobilizer Programming (IMMO PROG) The X-PROG 3 is required when performing this operation. It has the following functions: 1). Read transponder data (including Mercedes Benz infrared smart key), and generate exclusive keys. 2). Read/write on-board EEPROM chip data, and read/write MCU/ECU chip data.

  • Page 24: Diagnosis

    LAUNCH 6 Diagnosis 6.1 Intelligent Diagnose Through simple wireless communication between the tablet and VCI, you can easily get the VIN (Vehicle Identification Number) information of the currently identified vehicle. Once the VIN is successfully identified, the system will retrieve it from the remote server and then guide you to vehicle information page without performing the step-by-step manual menu selection.

  • Page 25: Local Diagnose

    • Tap to launch the VIN recognition module. Place the VIN inside the viewfinder rectangle to scan it. The most recognizable location for this number is in the top left corner on the vehicle’s dashboard. Other locations include the driver’s door or post, and the firewall under the hood.
  • Page 26 LAUNCH 1. VINSCAN enables you to access it more quickly. In this case, Camera Scan and Enter VIN are available. Camera Scan: Scan the VIN automatically. Enter VIN: Input the vehicle VIN manually. If the tablet successfully identifies the vehicle model, it will directly enter the diagnostic function selection menu.

  • Page 27: Health Report (Quick Test)

    LAUNCH 5). Turn the ignition key to ON: Set the ignition switch to on. 6.2.1 Health report (Quick Test) This function varies from vehicle to vehicle. It enables you to quickly access all the electronic control units of the vehicle and generate a detailed report about vehicle health.
  • Page 28 LAUNCH *Note: Diagnostic report is classified into three categories: Pre-Repair report, Post-Repair report and Diagnostic Scan. To facilitate the comparison of the pre-repair and post-repair reports and get accurate test result, please make sure you saved the right type of the diagnostic report. To save the report as a common diagnostic report, select Diagnostic Scan.

  • Page 29: System Scan

    LAUNCH *Note: Before performing this function, please make sure that: 1) You have saved a pre-repair report of the currently tested vehicle; and 2) You have already made some repairs and service and cleared the DTCs after the pre-repair reported is generated. Otherwise, no differences exist between the pre- and post- repair reports.
  • Page 30 LAUNCH *Note: Different vehicle has different diagnostic menus. A. Version Information This function is used to read the version information of system mode, vehicle VIN, software and ECU. B. Read Fault Code This function displays the detailed information of DTC records retrieved from the vehicle’s control system.
  • Page 31 LAUNCH D. Read Data Stream This option retrieves and displays live data and parameters from the vehicle’s ECU. Caution: If you must drive the vehicle in order to perform a troubleshooting procedure, ALWAYS have a second person help you. Trying to drive and operate the diagnostic tool at the same time is dangerous, and could cause a serious traffic accident.
  • Page 32 LAUNCH  Combine – this option is mostly used in graph merge status for data comparison. In this case, different items are marked in different colors. On-screen Buttons: Graph(Single): Tap to view the parameter in waveform graph. Graph: Tap to view the parameters in waveform graphs.

  • Page 33: Adas Calibration

    • SmartLink C (Customer) - SmartLink Service Subscriber. In the SmartLink system, the SmartLink C needs to perform the following operations. 1). Launch Service Link Platform: Binds SmartLink C dongles and submits remote repair orders. 2). SmartLink C Dongle: Connects to the vehicle’s DLC port for collecting the vehicle data and sends it to the remote SmartLink B.
  • Page 34 • SmartLink B (Business) - SmartLink Service Provider. In the SmartLink system, the SmartLink B needs to perform the following operations. 1). Launch Service Link Platform: Binds SmartLink B dongles and accepts orders from SmartLink C. • If the SmartLink B dongle works with the LAUNCH-specific diagnostic tool equipped with SmartLink module, tap SmartLink to add the SmartLink B device and accepts orders on the diagnostic tool.

  • Page 35: X431 Remote Diagnostics

    For more detailed operations, refer to the User Manual integrated in the SmartLink Platform. 6.3.2 X431 Remote Diagnostics This option aims to help repair shops or technicians launch instant messaging and remote diagnosis, making the repair job getting fixed faster.
  • Page 36 LAUNCH Here you can tap Remote Diagnose to launch remote diagnostics directly or choose to add the partner into the Contacts list. Tap the desired name from the list, the following screen will appear: Tap Add friend to send your request.
  • Page 37 Remote Diagnose: To start a remote diagnostic session. Camera: Open camera to take pictures. Tap Clear to delete all the partner’s dialog logs. 3. Launch Remote Diagnosis (Scanner-To-Scanner) The tool is allowed to initiate remote diagnosis with other diagnostic tools, which are equipped with this module.
  • Page 38 Wait for partner’s confirmation Start connecting after request confirmed Start Diagnosis Generate diagnostic report Cancel To cancel this operation. 4. Launch Remote Diagnosis (Scanner-To-PC) User also can ask for remote control from a PC client technician. Tap Remote, the following screen will appear:...
  • Page 39 LAUNCH 1. Slide the switch to ON so that the partner can connect to your scanner. 2. Notify the partner to visit http://remote.x431.com until the following screen appears on the PC. Note: Before processing remote diagnosis, please make sure the scanner is properly connected to the vehicle.

  • Page 40: Diagnostic History

    LAUNCH 1) You are not suggested to execute any actions. 2) The partner is not allowed to save any diagnostic reports or records on your scanner. Once the session is complete, a remote diagnostic report will be automatically generated. 6.4 Diagnostic History This function enables users to directly get access to the previously tested vehicle’s diagnostic records in...

  • Page 41: Service (Reset) Function

    LAUNCH 7 Service (Reset) Function It offers coding, reset, relearn and more service functions, to help vehicles get back to functional status after repair or replacement. Available tests vary by vehicle manufacturer, year, and model. Due to continuing improvements, the available service functions are subject to change at any time. To...

  • Page 42: Software Update

    LAUNCH 8 Software Update This module enables you to update the diagnostic software & App and frequently used software. 8.1 Update Diagnostic Software & APP Go to Software Update on the Job Menu and tap the Car model tab. The Car model tab displays a list of vehicle diagnostic software.

  • Page 43: Adas (Calibration)

    LAUNCH 9 ADAS (Calibration) This module enables you to effectively and accurately calibrate a wide range of camera-based & radar-based driver assistance systems, e.g. the front camera for the lane departure warning system, the radar sensor for the ACC (Adaptive Cruise Control) or the camera for adaptive headlights. It needs to work with the specific ADAS calibration tool (sold separately).

  • Page 44: Tpms

    LAUNCH 10 TPMS This module allows you to configure the tablet as TPMS activation & diagnostic tool, which provides the ability to trigger TPMS sensor, program TPMS sensor, perform the relearning procedure. It needs to work with the compatible TSGUN device (sold separately).
  • Page 45 LAUNCH...

  • Page 46: Other Modules

    LAUNCH 11 Other Modules 11.1 Common Apps 11.1.1 Vehicle Coverage This option is used to check the vehicle models that the tools covers. 11.1.2 User Info This function allows users to manage personal information and VCI. 1. My Report This option is used to view, delete or share the saved reports.
  • Page 47 The App is compatible with the LAUNCH Wi-Fi Printer (sold separately) and System (external printer). For LAUNCH Wi-Fi printer, refer to the user manual included with the printer to configure it. For other Wi-Fi printers, Before printing, make sure the following conditions are met: •...
  • Page 48 LAUNCH 4. Touch next to Select a printer on the upper left corner of the screen. 5. Select All Printers -> Add printer and enable the installed printer service, the system starts searching for all available Wi-Fi printers of the brand.

  • Page 49: Toolbox

    LAUNCH account. The main account can modify the validity period of the sub-account. There are two types of sub-accounts: one is an existing account and the other is a newly created account. The main account has the functions of adding and removing sub-accounts, the sub-account can also be unbound from the main account.

  • Page 50: Tablet Settings

    LAUNCH 11.2.1 Tablet Settings This module allows you to make some Android’s system settings. 11.2.2 TeamViewer QS This function enables you to receive remote support from technician fellows, colleagues or friends by allowing them to control your tablet on their computer view TeamViewer software.

  • Page 51: J2534 Reprogramming Using Smartlink C

    Except that the SmartLink C acts as a VCI device and a SmartLink dongle, it also can be used as a J2534 PassThru device, working together with the PC installed with the OEM diagnostic software to perform the J2534 reprogramming. In this case, the PC needs to install with the LAUNCH's J2534 tool, which can be downloaded from www.cnlaunch.com.

  • Page 52: Faq

    *Note: Before registration, please make sure the network is properly connected. After the tablet has been successfully reset, follow the steps below to download the App: 1. Launch the browser and the default official Launch website opens (If a blank page pops up, just type www.x431.com in the input bar).

  • Page 53: About Smartlink Diag

    6. How to retrieve the login password? Please follow below steps to proceed in case you forgot the login password: 1. Tap the application icon on the home screen to launch it. 2. Tap the Login button on the upper right corner of the screen.

  • Page 54: Warranty

     Quantity  Part number  Item description Customer Service If you have any questions on the operation of the unit, please contact local dealer, or LAUNCH TECH CO., LTD.: Website: www.x431.com www.cnlaunch.com Tel: +86 755 8455 7891...
